The SIGMATEK DNC115 is a compact, high-performance programmable logic controller (PLC) from SIGMATEK’s Dali series, designed for small to mid-sized automation tasks in industrial machinery, packaging lines, conveyor systems, and process control applications. Built on a real-time Linux operating system, the DNC115 combines deterministic control performance with modern communication capabilities, offering a powerful yet cost-effective solution for machine builders seeking flexibility without complexity.
Housed in a space-saving DIN-rail enclosure, the SIGMATEK DNC115 integrates a 32-bit ARM processor, onboard digital I/O (8 inputs / 4 outputs), multiple communication interfaces—including Ethernet, RS485, and CANopen—and supports all five IEC 61131-3 programming languages (Ladder Diagram, Structured Text, Function Block Diagram, etc.) via SIGMATEK’s Automation Studio engineering platform. Its built-in web server enables remote monitoring and diagnostics via standard browsers, while optional SD card support allows for data logging, recipe management, and firmware updates in the field.
Designed for reliability, the DNC115 operates across a wide temperature range (-25°C to +60°C), features surge protection on I/O lines, and supports modular expansion through SIGMATEK’s decentralized I/O system—making it scalable from simple standalone machines to networked multi-axis systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | SIGMATEK DNC115 |
| Manufacturer | SIGMATEK GmbH & Co KG (Austria) |
| Controller Type | Compact PLC / Embedded Automation Controller |
| Processor | 32-bit ARM Cortex |
| Operating System | Real-Time Linux |
| Program Memory | 512 kB |
| Data Memory | 256 kB |
| Cycle Time | As low as 1 ms (typical for 1 K instructions) |
| Digital Inputs | 8 x 24 VDC (PNP), sink/source capable |
| Digital Outputs | 4 x Transistor (24 VDC, 0.5 A each) |
| Communication Ports | – 1x Ethernet (10/100 Mbps, Modbus TCP, HTTP, FTP) – 1x RS485 (Modbus RTU, ASCII) – 1x CANopen (Master or Slave, up to 1 Mbps) |
| Programming Software | SIGMATEK Automation Studio (IEC 61131-3 compliant) |
| Supported Languages | LD, FBD, ST, SFC, IL |
| Power Supply | 24 VDC ±20% |
| Power Consumption | ~5 W |
| Mounting | DIN rail (EN 60715) |
| Operating Temperature | -25°C to +60°C |
| Protection | Integrated surge protection on I/O; IP20 rating |
| Expansion | Yes – via CANopen or SIGMATEK decentralized I/O modules |
Main Features and Advantages
✅ Integrated Multi-Protocol Communication
The DNC115 eliminates the need for external gateways by natively supporting Ethernet (Modbus TCP), RS485 (Modbus RTU), and CANopen—enabling seamless integration with HMIs, drives, sensors, and higher-level SCADA systems. The built-in CANopen interface can operate as either master or slave, ideal for motion coordination in multi-axis applications.
✅ Real-Time Performance with Linux Flexibility
Unlike traditional PLCs running proprietary OSes, the DNC115 leverages a hardened real-time Linux kernel, offering both deterministic scan cycles and advanced features like file system access, web services, and remote SSH—without compromising reliability.
✅ Compact Yet Expandable Architecture
Despite its small footprint (approx. 90 x 90 x 60 mm), the DNC115 can be expanded using SIGMATEK’s remote I/O modules over CANopen, supporting hundreds of additional I/O points. This makes it suitable for both standalone machines and distributed control topologies.
✅ User-Friendly Engineering & Diagnostics
Programmed entirely within SIGMATEK Automation Studio, the DNC115 benefits from intuitive debugging, online change capability, and integrated HMI design. The built-in web server displays I/O status, error logs, and system info—accessible from any smartphone or PC on the network.
✅ Robust for Industrial Environments
With wide voltage tolerance, ESD/surge protection, and extended temperature operation, the DNC115 performs reliably in electrically noisy or thermally challenging settings—common in food processing, woodworking, and material handling.
Application Field
The SIGMATEK DNC115 is widely deployed in:
Packaging Machinery: Case erectors, labelers, and fillers requiring precise timing and I/O control.
Conveyor & Sorting Systems: Where CANopen-connected motor modules or photoelectric sensors must be coordinated.
Small CNC Machines & Special Purpose Equipment: Leveraging its fast cycle time and motion-ready architecture.
Building Automation & HVAC Control: Using Modbus TCP/RTU to interface with chillers, valves, and meters.
Renewable Energy Systems: Such as solar tracker controllers or small hydro turbine governors.
Related Products
SIGMATEK DNC125: Enhanced version with more memory, faster CPU, and additional serial ports.
SIGMATEK DAI114: 14-channel digital I/O expansion module (CANopen).
SIGMATEK DAE114: Analog I/O expansion (4 AI / 2 AO).
SIGMATEK HMI Panels (e.g., CSTA series): Fully integrated visualization via Automation Studio.
SIGMATEK Servo Drives (e.g., LCM series): Controlled directly via CANopen from DNC115.
Automation Studio T300: Full development suite for programming, simulation, and HMI design.
Installation and Maintenance
Mounting: Install on standard 35 mm DIN rail in a control cabinet with adequate ventilation.
Wiring: Use shielded cables for digital inputs; ensure 24 VDC power supply has sufficient margin (≥2 A recommended).
Grounding: Connect protective earth to the terminal block to minimize EMI.
Firmware Updates: Performed via SD card or Ethernet using Automation Studio.
Diagnostics: Monitor I/O status via LEDs or web interface (default IP: 192.168.1.100); check event logs for faults.
