Description

HAWE HRP 5 V One-Way Valve In Stock Check Valve 500 Bar German Import Ready to Ship

Brand new and in stock (库存现货 / 现货) - ready to ship within 3-5 days.

The HAWE HRP 5 V belongs to the HRP family of check valves with hydraulic release from HAWE Hydraulik SE: a size-5 manifold-mounting valve fitted with pre-release (V = Vorentlastung) to cushion the pressure shock that occurs when a high-pressure, heavily loaded consumer volume is released. Free flow passes from A to B without resistance; in the blocked direction the spring-loaded poppet closes absolutely leak-tight, and pilot pressure at port Z lifts the valve against the load. Because the piston rear is unloaded through the separate leakage port L, opening stays reliable even with residual pressure in the return line. The design is fully steel, with a gas-nitrided body and a hardened, ground poppet for long service life.

Data (per HAWE catalogue D 5116):

• Type: HRP 5 V - check valve with hydraulic release, pre-release version

• Size: 5 | Max flow Qmax: 140 l/min | Max operating pressure pmax: 500 bar

• Release ratio pA/pZ: 4.0 | Dimensions: L 110.5 x B 60 x H 40 mm

• Ports: A, B = consumer | Z = control | L = leakage | Mounting position: any

• Construction: manifold-mounting valve, spring-loaded poppet, leak-free closure; steel, gas-nitrided body

• Pressure medium: hydraulic oil to DIN 51524 part 1-3, ISO VG 10-68; viscosity 4 - 1500 mm²/s

• Temperature: ambient -40 to +80 °C, oil -25 to +80 °C | Cleanliness: ISO 4406 21/18/15 ... 19/17/13

• Brand: HAWE Hydraulik SE (Germany) | Condition: Brand New, Original | Stock: 库存现货, in stock

Product photos shown are for reference; the actual item may differ slightly.

Typical uses: press, injection-moulding and machine-tool hydraulics, load-holding and relief functions on industrial and mobile equipment. Matching types HRP 1 to HRP 7 V, the HRPD 3 V releasable twin check valve and the solenoid-valve-equipped variants (order code e.g. HRP 5 - WH1 - H B 0,4 - G24) are all in our sourcing range - ask with your complete type designation for an exact quote.

Lead Time: IN STOCK, 3-5 days after payment
Delivery: FedEx, SF Express, EMS
Condition: In Stock, Brand New
Payment Method: T/T, 30% deposit, 70% balance of payment
Price: Please contact us for further inquiry. All quotes are based on EXW excluding tax.
Remark: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.

As a professional trader in imported automation industry, we are specialized in selling PLC, DCS, Converters, I/O Modules, and Hydraulic Components. Recently, we have more advantages in ABB, ALLEN BRADLEY, BENTLY, GE, FOXBORO, HIMA, HONEYWELL, TRICONEX, HAWE, REXROTH and MOOG.
