TURCK PS040V-504-LI2UPN8X-H1141 Pressure Sensor -1...40 bar IO-Link G1/4 In Stock

Stock item - brand new and in stock (库存现货 / 图尔克现货), ships within 3-5 days.

The PS040V-504-LI2UPN8X-H1141 is a rotatable PS-series pressure sensor with a piezo-resistive ceramic measuring cell: OUT1 works as switching output or IO-Link port, OUT2 as analog output (4-20 mA / 0-10 V) or a second switching output, both freely configurable NO/NC and PNP/NPN. The housing rotates after the process connection is plugged in, so the display and pushbutton always face the operator; a recessed pushbutton with keylock, permanent pressure indication in bar/psi/kPa/MPa and a peak-pressure memory round off the feature set. Accuracy is ± 0.5 % FS with a response time below 3 ms.

Details:

• Model: PS040V-504-LI2UPN8X-H1141 | Ident-No. 6832844 | PS series (rotatable)

• Pressure range: -1...40 bar relative (-0.1...4 MPa) | overpressure ≤ 180 bar | burst ≥ 180 bar

• Outputs: OUT1 switching or IO-Link; OUT2 analog 4-20 mA / 0-10 V or switching | NO/NC, PNP/NPN

• Accuracy: ± 0.5 % FS | response time < 3>

• Supply: 18...30 VDC, ≤ 50 mA | process connection G1/4 male, stainless steel 1.4305, ceramic Al2O3 cell

• Protection: IP67 / IP69K | medium -40...+85 °C, ambient -40...+80 °C | connection M12 x 1

• Brand: TURCK (Germany) | Condition: Brand New, Original | Stock: 库存现货, in stock

Lead Time: IN STOCK, 3-5 days after payment
Delivery: FedEx, SF Express, EMS
Condition: In Stock, Brand New
Payment Method: T/T, 30% deposit, 70% balance of payment
Price: Please contact us for further inquiry. All quotes are based on EXW excluding tax.
Remark: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
