The ABB DAPI100 3AST000929R109 is a specialized Digital Automatic Parallel Interface module engineered for advanced generator synchronization and load-sharing control in mission-critical power systems. As a core component of ABB’s MGC (Modular Generator Control) platform, this module enables precise paralleling of multiple generators or connection to utility grids with <20ms>ABB DAPI100 3AST000929R109 employs adaptive phase-matching algorithms to regulate voltage, frequency, and phase angle during seamless transfer operations, preventing torque shock to prime movers. Designed for demanding applications like hospitals, data centers, and marine vessels, it features dual CAN bus interfaces for deterministic communication with ABB REG670 generator protection relays and PLCs. With its ruggedized construction and conformal-coated circuitry, the ABB DAPI100 3AST000929R109 ensures uninterrupted power availability in harsh environments while complying with IEEE 1547 grid interconnection standards.
ABB DAPI100 3AST000929R109
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | DAPI100 3AST000929R109 |
| Manufacturer | ABB |
| Product Type | Generator Paralleling Controller |
| Input Voltage | 24-48 VDC / 100-240 VAC |
| Synchronization Accuracy | <20> |
| Communication Ports | 2x CAN 2.0B (1Mbps), RS-485 Modbus RTU |
| Load Sharing Accuracy | ±2% of rated power |
| Max Generators | 32 units (cascadable) |
| Operating Temperature | -30°C to +70°C |
| Protections | Over/under frequency, reverse power, out-of-phase |
| Protocol Support | CANopen, J1939, IEC 61850 (via gateway) |
| Certifications | UL 508, DNV GL, ABS, IEC 60092-501 |
Main Features and Advantages
Precision Synchronization: The ABB DAPI100 3AST000929R109 utilizes real-time phase-locked loop (PLL) technology with <0>
Multi-Master Load Sharing:
Isochronous/droop mode switching
kW/kVAR proportional distribution
Cross-current compensation
Black start sequencing
N+1 redundancy support
Robust Communication: Dual-redundant CAN buses maintain control during single-wire failures. The module’s deterministic messaging (4ms cycle time) prioritizes critical commands like load shed signals. Built-in protocol converters eliminate external hardware for MODBUS integration.
Diagnostic Capabilities: Continuous monitoring of:
Harmonic distortion (THDv <3>
Prime mover health via torsional vibration analysis
Breaker contact wear prediction
Fuel efficiency metrics
Application Field
The ABB DAPI100 3AST000929R109 is indispensable for facilities requiring fault-tolerant power. In Tier IV data centers, it orchestrates seamless transfers between utility and diesel generators during grid failures, maintaining UPS runtime. Offshore platforms utilize its DNV GL-certified version for closed-transition paralleling of multiple 2MW+ gensets, preventing blackouts during gas compressor starts.
Marine vessels deploy the ABB DAPI100 3AST000929R109 for dynamic positioning systems where <50ms>
ABB DAPI100 3AST000929R109
Related Products
ABB REG670: Generator protection relay (required for DAPI100 integration)
ABB MGC600: Central controller for DAPI100 networks
ABB CI871: PROFIBUS gateway for DAPI100
ABB UMC100: Multi-function meter for power quality monitoring
ABB PCD231A: Breaker control module
ABB 3AST000900R100: Mounting kit for DAPI100
Installation and Maintenance
Pre-installation preparation: Verify CT ratios match generator nameplate (typically 5A secondary). Calibrate voltage sensing lines within ±0.5% tolerance. Isolate CAN bus cables from VFDs using ferrite cores. Program unique node IDs (1-127) before network commissioning.
Maintenance recommendations: Perform annual synchronization test using calibrated phase-angle meter. Monitor “Sync Deviation” parameter monthly – values >5° indicate CT phase shift. Replace backup supercapacitor every 7 years. Update firmware during planned outages to maintain cybersecurity compliance.
