The SCHNEIDER P3U30-6AAA1BCAA is a high-performance, outdoor-ready network PTZ (Pan-Tilt-Zoom) camera from Pelco by Schneider Electric, designed for demanding video surveillance applications requiring long-range identification and 24/7 reliability. Part of the Sarix Professional series, this integrated dome camera combines a 2-megapixel CMOS sensor with a 30x optical zoom lens (6.0–180 mm), delivering crisp, detailed imagery from wide-area overviews to license plate or facial recognition at distance.
Equipped with powerful Smart Compression (H.265/H.264), built-in 80-meter infrared (IR) illumination, and advanced imaging technologies like Wide Dynamic Range (WDR) and True Day/Night functionality, the P3U30-6AAA1BCAA excels in challenging lighting—from direct sunlight to near-total darkness. It supports multiple streaming profiles, ONVIF Profile S compliance, and legacy Pelco protocols (Pelco-D/P), ensuring seamless integration into both modern IP video management systems (VMS) and hybrid analog-to-IP upgrades.
Housed in a rugged IP66 and IK10-rated enclosure with a sunshield and heater/blower for extreme climates (–40°C to +65°C), the P3U30-6AAA1BCAA is ideal for perimeter security, transportation hubs, utility substations, and industrial sites where environmental resilience and operational continuity are critical.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | P3U30-6AAA1BCAA |
| Brand | Pelco by Schneider Electric |
| Camera Type | Network PTZ Dome (Integrated) |
| Sensor | 1/2.8″ Progressive Scan CMOS |
| Resolution | 1920 × 1080 (Full HD / 2MP) @ 30 fps |
| Lens | 30x Optical Zoom (6.0–180 mm), f/1.6–f/4.5 |
| Digital Zoom | Up to 16x (combined with optical: 480x total) |
| IR Illumination | Built-in, up to 80 meters (262 ft) |
| Minimum Illumination | Color: 0.15 lux; B/W: 0.005 lux; IR On: 0 lux |
| WDR | True WDR (120 dB) |
| Compression | H.265, H.264, MJPEG (dual-stream) |
| Pan/Tilt Range | Pan: 360° continuous; Tilt: –90° to +20° |
| Pan/Tilt Speed | Up to 300°/sec pan, 200°/sec tilt |
| Preset Positions | Up to 256 presets with pattern/tour support |
| Power Supply | 24 VAC ±20% or PoE++ (802.3bt Type 4) |
| Network Interface | 10/100/1000BASE-T Ethernet |
| Protocols | ONVIF Profile S, RTSP, Pelco-D, Pelco-P, HTTP, HTTPS |
| Environmental Rating | IP66 (dust/water), IK10 (impact) |
| Operating Temperature | –40°C to +65°C (–40°F to +149°F) |
| Mounting | Wall, ceiling, pole (bracket included) |
Main Features and Advantages
✅ 30x Optical Zoom with Sharp Imaging
From a 60° wide view to a narrow 2° telephoto, the P3U30-6AAA1BCAA captures fine details at distances exceeding 300 meters—ideal for monitoring large perimeters without blind spots.
✅ All-Weather Reliability
The heavy-duty aluminum housing, corrosion-resistant coating, and integrated climate control (heater + blower) ensure uninterrupted operation in snow, sandstorms, or tropical humidity.
✅ Intelligent Bandwidth Management
With H.265 Smart Compression, the camera reduces bandwidth and storage needs by up to 50% compared to H.264—without sacrificing image quality—lowering total cost of ownership.
✅ Flexible Integration & Control
Supports ONVIF, Pelco-D/P, and Pelco’s VideoXpert VMS, enabling plug-and-play deployment in multi-vendor environments. Also features web-based configuration and mobile viewing.
✅ Advanced Night Vision
Automatic IR cut filter and 80m IR LEDs provide clear monochrome video in complete darkness, while Smart IR prevents overexposure of nearby objects.
✅ Power over Ethernet++ (802.3bt)
Simplifies installation with single-cable power and data via PoE++, eliminating need for local AC outlets—especially valuable in remote tower or mast installations.
Application Field
The SCHNEIDER P3U30-6AAA1BCAA is widely deployed in mission-critical surveillance scenarios:
Transportation: Airports, railway stations, highways (toll plazas, traffic monitoring)
Critical Infrastructure: Power plants, oil refineries, water treatment facilities
Public Safety: City-wide surveillance (Safe City), border patrol, prison perimeters
Industrial Sites: Ports, warehouses, mining operations, manufacturing yards
Commercial Security: Campus security, shopping malls, parking structures
Related Products
P3U20-6AAA1BCAA: 20x zoom variant (6–120 mm) for medium-range coverage
P3U30-6AAA1BCAB: Same as above but with wiper for dusty/rainy environments
VideoXpert VMS: Pelco’s enterprise video management software
SCHNEIDER BBP300: Outdoor wall/ceiling mounting bracket kit
P3B30 Series: Explosion-proof version for hazardous areas (ATEX/IECEx)
SCHNEIDER NVR3000: Network video recorder compatible with P3U30
Pelco DX8100: Hybrid DVR for mixed analog/IP systems
P3U30-6AAA1BCAD: Version with laser-assisted focus for ultra-long-range clarity
Pelco Analytics Suite: Optional onboard video analytics (tripwire, loitering, object left)
SCHNEIDER PSU24VAC: 24VAC power supply for non-PoE installations
Installation and Maintenance
? Installation Tips:
Use Cat6A or better cable for PoE++ to minimize voltage drop over long runs (>60m).
Ensure the mounting surface can support >10 kg (22 lbs) dynamic load during pan/tilt motion.
Configure IP address via Pelco Discovery Tool or DHCP before final mounting.
Enable “Privacy Masks” to comply with GDPR/local privacy laws if covering public areas.
?️ Maintenance Recommendations:
Clean the dome regularly with mild soapy water—avoid solvents that damage anti-reflective coating.
Verify IR performance quarterly in low-light conditions.
Update firmware annually via Pelco Support Portal to access bug fixes and new features.
In coastal/salty environments, inspect seals and gaskets every 6 months for degradation.
