Description

The ABB HVC-02B is a high-voltage coupling capacitor from ABB’s extensive portfolio of power transmission and distribution components. This specialized device is engineered not for power transmission itself, but for critical high-voltage measurement and communication applications. Its primary function is to reliably couple high-frequency carrier signals onto high-voltage power lines while effectively blocking the low-frequency power current. This makes the ABB HVC-02B an indispensable component in Power Line Carrier (PLC) communication systems and capacitive voltage measurement schemes. In PLC systems, the capacitor allows for the transmission of data, teleprotection signals, and telemetry between substations over the existing high-voltage infrastructure, providing a cost-effective and reliable communication channel for grid management and protection. For voltage measurement, it forms part of a capacitive divider, enabling the safe and accurate monitoring of line voltage for metering, relaying, and synchronization purposes. The ABB HVC-02B is designed with a robust, weather-proof, and oil-impregnated paper dielectric construction, ensuring exceptional dielectric strength, long-term stability, and reliable performance under the most demanding environmental and electrical conditions, making it a trusted component in the world’s energy infrastructure.

HVC-02B ABB

Technical Specifications

Main Features and Advantages

Exceptional Dielectric Strength and Reliability: The ABB HVC-02B is engineered with a proven oil-impregnated paper dielectric system, renowned for its high dielectric strength and long-term stability. This construction ensures reliable operation at its full rated voltage and provides high resistance to transient overvoltages, such as those caused by lightning strikes or switching surges. This inherent robustness guarantees a long service life with minimal maintenance, even in harsh outdoor substation environments.

Precision and Stability for Accurate Signal Coupling: The capacitor offers a highly stable and precise capacitance value with a very low loss factor (tan δ). This precision is critical for its function in both communication and measurement applications. In PLC systems, it ensures efficient coupling of high-frequency signals with minimal attenuation and distortion. When used in capacitive voltage dividers, its stable capacitance is essential for achieving accurate and consistent voltage measurement, which is vital for protective relaying and revenue metering.

Robust and Weatherproof Construction: Designed for permanent outdoor installation, the ABB HVC-02B features a resilient porcelain housing that provides excellent resistance to environmental stresses, including UV radiation, wide temperature fluctuations, and moisture. The IP54 protection rating ensures that internal components are safeguarded against dust and water ingress, maintaining performance and safety in all weather conditions. Its design includes provisions for safe mounting and easy connection to the high-voltage line and the coupling device.

Proven Application Performance: The design of the ABB HVC-02B is based on decades of field experience. It is a trusted component for enabling reliable communications for teleprotection, SCADA data transfer, and voice communication over high-voltage lines. Its use ensures the integrity of the power grid’s communication backbone, facilitating rapid fault isolation and minimizing outage times. This proven performance makes it a default choice for utilities and industries worldwide for extending the functionality of their high-voltage assets.

Application Field

The ABB HVC-02B is exclusively deployed in high-voltage electrical transmission and distribution networks, typically at the substation level. Its primary application is in Power Line Carrier (PLC) systems on transmission lines rated from 66kV to 132kV, where it is installed between the phase conductor and the line trap and coupling equipment to inject and extract high-frequency signals for teleprotection, telemetry, and supervisory control and data acquisition (SCADA). This is critical for enabling line differential protection and automated fault isolation, which enhances grid stability and reliability. Secondly, it is used in capacitive voltage transformer (CVT) circuits for measuring line voltage, providing a scaled-down, safe signal for protective relays, synchronizing equipment, and revenue metering instruments. The ABB HVC-02B is fundamental to the safe, efficient, and intelligent operation of modern electrical grids, ensuring both the physical and data-related integrity of power delivery.

HVC-02B ABB

Related Products

ABB HVC-01B: A similar high-voltage coupling capacitor, likely with a different rated voltage or capacitance value.

ABB LINE TRAPS: Also known as wave traps, these are used in series with the line to block the high-frequency signals from entering the substation bus, working in conjunction with the HVC-02B.

ABB Coupling Devices: Units that contain the tuning and protection equipment, connecting between the HVC-02B and the PLC transmitter/receiver.

ABB CVT Units: Complete Capacitive Voltage Transformers that may utilize a capacitor like the HVC-02B as part of their divider stack.

ABB Surge Arresters: Often installed nearby to protect the coupling capacitor and other sensitive equipment from overvoltage transients.
