Description

The ELEMASTER IB3110250 is a highly versatile and robust DIN-rail mounted industrial enclosure, specifically designed as an interface box for the seamless and organized termination of field wiring within control panels and automation cabinets. As a core component of Elemaster’s extensive enclosure system portfolio, this unit serves as a critical junction point, bridging the gap between sensitive control equipment—such as PLCs, drives, and relays—and the sensors, actuators, and field devices on the factory floor. The primary function of the ELEMASTER IB3110250 is to provide a centralized, protected, and easily accessible location for the termination of large numbers of control wires, significantly simplifying the wiring process, enhancing maintenance operations, and improving the overall reliability of the automation system. Its modular design, featuring a transparent cover and a pre-installed DIN rail, allows for the flexible installation of various terminal blocks, signal conditioners, and small components. By offering a secure and structured environment for electrical connections, the ELEMASTER IB3110250 minimizes wiring errors, protects terminals from physical damage and environmental contaminants, and ensures long-term operational integrity, making it an indispensable element in professional control system design.

IB3110250 ELEMASTER

Technical Specifications

Main Features and Advantages

Superior Environmental Protection and Durability: The ELEMASTER IB3110250 is engineered with a high-performance polycarbonate/ABS blend that offers exceptional impact resistance (IK08) and maintains structural integrity across a wide temperature range from -40°C to +100°C. Its IP66 rating guarantees complete protection against dust ingress and powerful water jets, making it perfectly suited for harsh industrial environments, including washdown areas in food and beverage processing or dusty conditions in manufacturing and logistics. The material is also UL 94 V-0 rated, meaning it is self-extinguishing and enhances the overall fire safety of the control panel.

Enhanced Visibility and Maintenance Efficiency: A standout feature of the ELEMASTER IB3110250 is its transparent cover. This allows for immediate visual inspection of all internal components, wiring, and terminal blocks without the need to open the enclosure. This visibility drastically reduces troubleshooting time, enables quick verification of signal status via LEDs on terminal blocks, and helps prevent accidental contact with live parts during inspection. The cover is secured with robust snap-fit latches or screws (model dependent), ensuring the IP rating is maintained while providing easy access for authorized personnel.

Optimized for Modularity and Easy Installation: Designed for maximum flexibility, the enclosure comes pre-equipped with a standard TS35 DIN rail. This allows engineers to quickly and neatly mount a wide array of DIN-rail compatible components, such as fuse holders, isolators, relay modules, and especially a comprehensive range of terminal blocks—including PCB, feed-through, and disconnect types. The ELEMASTER IB3110250 is itself easily mounted on a main cabinet DIN rail, saving panel space and simplifying the overall mechanical layout. This modularity streamlines the assembly process and facilitates future modifications or expansions.

Space-Efficient and Cost-Effective Organization: By consolidating wiring terminations into a single, organized unit, the ELEMASTER IB3110250 eliminates the clutter of individual wires running directly to PLCs and other controllers. This results in a cleaner, more professional panel layout, reduces wiring time and labor costs, and minimizes the potential for connection errors. It effectively acts as a structured intermediary, making system commissioning, debugging, and future maintenance significantly faster and more efficient.

Application Field

The ELEMASTER IB3110250 finds universal application across all industries that utilize automated control systems. It is extensively used in manufacturing and machinery automation as a centralized marshalling cabinet for terminating I/O signals from sensors (proximity, photoelectric, pressure) and actuators (solenoid valves, motor starters, pneumatic valves) before they connect to the main PLC or DCS system. In process industries like food and beverage or pharmaceuticals, its IP66 rating makes it ideal for installation in areas requiring frequent hygiene washdowns. The ELEMASTER IB3110250 is also perfectly suited for building automation systems (BAS) to manage connections for HVAC controls, in renewable energy installations for organizing wiring in solar inverter or wind turbine control cabinets, and in material handling and packaging lines where vibration resistance and reliable connections are paramount. Essentially, any application requiring organized, protected, and accessible field wiring termination benefits from the structured solution provided by the ELEMASTER IB3110250.

IB3110250 ELEMASTER

Related Products

ELEMASTER IB Series: A full range of interface boxes in various sizes (e.g., IB3108125, IB3115370) for different capacity needs.

ELEMASTER Terminal Blocks: A comprehensive portfolio of PCB, barrier, and feed-through terminal blocks designed for installation inside the IB3110250.

ELEMASTER PCB Mounting Sockets: Sockets that allow entire PCBs to be mounted and connected within the enclosure.

ELEMASTER PSB Series: Power distribution blocks for organizing higher-current power wiring.

ELEMASTER DIN-Rail Mountable Circuit Breakers: Small protective devices that can be housed within the interface box.

ELEMASTER SBB Series: Sensor/actuator junction boxes, representing a more specialized solution for device-level networking.
