The ABB IC660BBA104 6231BP10910 is a highly specialized and critical communication interface module designed for the ABB Freelance 800F and AC 800F Distributed Control System (DCS) platforms. This module functions as a PROFIBUS DP-V1 Master interface, serving as the essential gateway that integrates the powerful ABB controller with a vast ecosystem of PROFIBUS-compatible field devices and remote I/O stations. The core function of the ABB IC660BBA104 6231BP10910 is to manage all data exchange on the PROFIBUS network, a widely adopted international standard (IEC 61158/61784), allowing the AC 800F controller to command and monitor sensors, actuators, drives, and other intelligent devices from hundreds of different manufacturers. By implementing this module, the control system gains immense flexibility and scalability, enabling a hybrid architecture that combines ABB’s robust process control with the cost-effectiveness and variety of the PROFIBUS device market. The ABB IC660BBA104 6231BP10910 is engineered for deterministic and reliable performance, ensuring precise timing for critical control loops and providing comprehensive diagnostic capabilities for the entire network. It is an indispensable component for modernizing and expanding process automation systems, bridging the gap between a high-level DCS and the field device level.
IC660BBA104 6231BP10910 ABB
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | IC660BBA104 6231BP10910 |
| Manufacturer | ABB |
| Product Type | PROFIBUS DP-V1 Master Interface Module |
| Compatible Controller | ABB AC 800F, Freelance 800F |
| Protocol Standard | PROFIBUS DP-V1 (IEC 61158/61784) |
| Data Transfer Rate | Configurable from 9.6 kbit/s to 12 Mbit/s |
| Number of Slaves Supported | Up to 125 slaves (theoretical max, limited by controller resources) |
| Number of I/O Data | Up to 244 bytes of input and 244 bytes of output data |
| Interface | RS-485, 9-pin D-sub female connector |
| Isolation | 500V AC (between PROFIBUS and controller) |
| Power Consumption | 300 mA @ +5V DC (from controller baseplate) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 5 to 95% (non-condensing) |
| Status Indicators | LEDs for Module Status, Bus Activity, and Diagnostics |
Main Features and Advantages
Certified PROFIBUS DP-V1 Master Functionality: The ABB IC660BBA104 6231BP10910 is not just a basic interface; it is a certified DP-V1 master. This provides advanced features beyond standard cyclic data exchange, including acyclic communication for parameterization, diagnostics, and alarm handling with intelligent field devices. This allows for sophisticated device management and integration, unlocking the full potential of modern PROFIBUS devices.
Seamless System Integration and High Performance: The module is designed for deep integration within the ABB Freelance/AC 800F engineering environment. It is configured and commissioned entirely within the ABB Control Builder F engineering tool, providing a unified workflow from system design to device parameterization. Its high-performance processor handles the PROFIBUS protocol efficiently, ensuring deterministic data exchange and minimizing the load on the main controller’s CPU, which is crucial for maintaining fast system scan times.
Comprehensive Diagnostics and Network Management: A key advantage of the ABB IC660BBA104 6231BP10910 is its extensive diagnostic capability. It continuously monitors the health and status of the entire PROFIBUS network, providing detailed information on each connected slave device. Diagnostics are available both via the module’s status LEDs for a quick visual check and in-depth through the engineering software, enabling rapid fault localization and minimizing system downtime.
Unmatched Flexibility and Vendor Interoperability: By implementing the ABB IC660BBA104 6231BP10910, an ABB DCS gains unparalleled flexibility. It can communicate with thousands of different PROFIBUS devices from various vendors, including remote I/O racks, variable frequency drives, motor starters, weighing scales, and analytical instruments. This interoperability allows for optimal device selection, protects against vendor lock-in, and simplifies the integration of specialized equipment into the control strategy.
Application Field
The ABB IC660BBA104 6231BP10910 is deployed in a wide array of process and hybrid automation applications where the integration of third-party equipment into an ABB DCS is required. It is extensively used in chemical processing plants to connect PROFIBUS-enabled analytical instruments, smart valve positioners, and packaged equipment. In water and wastewater treatment facilities, it integrates remote I/O panels spread across the plant and drives on sludge processing equipment. The ABB IC660BBA104 6231BP10910 is also fundamental in manufacturing applications, such as automotive paint shops or food processing lines, where it connects to PROFIBUS network sensors and actuators on machinery. Any industry seeking to leverage the power and reliability of the ABB AC 800F controller while utilizing the extensive choice and cost-effectiveness of the PROFIBUS device ecosystem will find this module to be an essential enabling technology.
IC660BBA104 6231BP10910 ABB
Related Products
ABB AC 800F Controller (e.g., PM864AK): The main processor unit that hosts the IC660BBA104 module.
ABB CI854 / CI855: Communication interfaces for the AC 800M controller, providing similar functionality for a different controller family.
ABB S800 I/O with PROFIBUS Interface: Remote I/O stations that can be connected as slaves to the IC660BBA104 master.
ABB Drives with PROFIBUS DP (e.g., ACS550, ACS880): Variable frequency drives that can be directly controlled and monitored via the PROFIBUS master.
ABB CP635 / CP675: Operator panels that can display diagnostics and status from the PROFIBUS network.
