Description

The GE Fanuc IC698PSA100 is a high-capacity, 100-watt AC power supply module engineered for the PACSystems RX7i programmable automation controller platform. This module is designed to serve as the primary power source for larger RX7i configurations, delivering robust and reliable DC power to every component within the chassis. The fundamental role of the GE Fanuc IC698PSA100 is to convert the incoming alternating current (AC) from the plant mains into a clean, stable, and regulated +5VDC supply that is distributed via the high-speed PCI backplane to the CPU, I/O modules, and communication interfaces. With its substantial power output, the IC698PSA100 is specifically intended to support fully populated racks with numerous power-demanding modules, ensuring that even the most complex and expansive control systems operate with a solid and unwavering power foundation.

What sets the GE Fanuc IC698PSA100 apart is its ability to power large-scale systems without operating at the upper limits of its capacity. This power headroom is critical for long-term reliability, thermal management, and system stability. The module incorporates advanced filtering to suppress electrical noise and transients from the AC line, protecting sensitive digital electronics within the chassis from potential disruption or damage. The robust design of the GE Fanuc IC698PSA100 ensures consistent performance in typical industrial environments, making it a cornerstone for mission-critical applications in industries such as power generation, water treatment, and large-scale discrete manufacturing, where system uptime is directly tied to productivity and safety.

IC698PSA100 GE

Technical Specifications

Main Features and Advantages

The most significant advantage of the GE Fanuc IC698PSA100 is its high 100-watt power output. This substantial capacity allows it to easily support large RX7i chassis, such as the 17-slot IC698CHS117, when fully loaded with a powerful CPU, high-density I/O modules, and multiple communication coprocessors. By operating well within its maximum rating, the IC698PSA100 runs cooler and experiences less electrical stress, which significantly enhances its mean time between failures (MTBF) and overall service life. The module features a universal input voltage range (85-264 VAC), providing exceptional flexibility for global deployment and inherent resilience against common AC line sags and surges, which eliminates the need for external voltage conditioning in most industrial settings.

Built-in protection is a cornerstone of the IC698PSA100‘s design. It incorporates current-limiting circuitry that instantly protects the module and the valuable backplane components in the event of a short circuit or a catastrophic failure of another module in the rack. This protection is designed to be non-latching, allowing for automatic recovery once the fault condition is cleared, which is crucial for minimizing system downtime. The clear and unambiguous “Power Good” LED provides instant visual feedback on the module’s status, enabling quick diagnostics during startup or troubleshooting. The combination of high capacity, robust protection, and wide input tolerance makes the GE Fanuc IC698PSA100 a supremely reliable choice for ensuring the continuous operation of the most demanding automation systems.

Application Field

The GE Fanuc IC698PSA100 is deployed in large-scale industrial automation applications where the RX7i platform is used to control complex processes with extensive I/O requirements. In major power generation facilities, the IC698PSA100 provides the necessary power for control systems managing turbine sequencing, boiler control, and safety instrumented functions, where system reliability is non-negotiable. Similarly, in oil and gas refineries and offshore platforms, this module powers the controllers for complex continuous processes and emergency shutdown systems, ensuring that the large number of analog and digital points are managed without interruption.

In extensive material handling systems, such as those found in major distribution centers or airport baggage handling networks, the GE Fanuc IC698PSA100 supports the RX7i controllers that coordinate thousands of I/O points across conveyors, sorters, and scanners. The high power capacity is essential for these data-intensive applications. The module is also ideal for large manufacturing facilities, such as automotive assembly plants or steel mills, where the control system integrates numerous high-density I/O racks, motion controllers, and network modules. In these demanding environments, the IC698PSA100 ensures that the core control system has the clean, stable, and abundant power required for 24/7 operation.

Related Products

IC698PSA350: A 350-watt AC power supply, representing an even higher-capacity option for the most demanding systems with extreme power needs.

IC698CPE010: A 50-watt power supply module, suitable for smaller or medium-sized RX7i configurations.

IC698CPE020: A 30-watt power supply module, designed for basic RX7i chassis with modest power requirements.

IC698CHS117: A 17-slot RX7i chassis, which is an ideal form factor to be powered by the high-capacity IC698PSA100.

IC698CMX016: The high-performance RX7i CPU module that often requires the robust power delivery of the IC698PSA100 in a fully loaded system.

IC698ETM001: An Ethernet Interface Module, an example of a communication module that consumes significant backplane power and would be supported by the IC698PSA100.
