The IS200DTAOH1ABA is a high-performance Digital Turbine Auxiliary Output Module designed by General Electric as an integral component of the Mark VI Speedtronic turbine control system. This sophisticated module serves as a critical interface between the turbine control processor and various auxiliary output devices, providing reliable command execution for essential turbine support systems. The primary function of the IS200DTAOH1ABA is to convert control signals from the main processor into actionable outputs that operate equipment such as solenoid valves, motor starters, alarm annunciators, and other critical auxiliary devices necessary for safe turbine operation. As part of GE’s comprehensive control architecture, this module ensures precise execution of control commands that maintain turbine stability and operational safety.

Operating within the robust VME bus structure of the Mark VI platform, the IS200DTAOH1ABA demonstrates exceptional reliability in demanding power generation environments. The module features advanced output technology that guarantees accurate command execution while providing comprehensive protection against electrical faults and environmental challenges. The design of the IS200DTAOH1ABA incorporates sophisticated diagnostics and status monitoring capabilities that enable real-time performance verification and early fault detection. This enhanced visibility into output status allows operators to maintain optimal system performance while minimizing the risk of unexpected downtime. The module’s robust construction ensures reliable operation through temperature variations, electrical noise, and mechanical vibration commonly encountered in turbine control applications.

IS200DTAOH1ABA GE

Technical Specifications

Main Features and Advantages

The IS200DTAOH1ABA offers superior output flexibility with its Form C relay contacts that provide both normally open and normally closed configurations for each channel. This versatile contact arrangement enables the module to accommodate various control schemes without requiring external contact converters or additional hardware. Each output channel features heavy-duty relays capable of switching substantial loads directly, eliminating the need for intermediate contactors in many applications. The module incorporates advanced arc suppression technology that extends relay life and improves switching reliability, particularly when controlling inductive loads such as solenoid valves and motor contactors. The IS200DTAOH1ABA also includes sophisticated diagnostics that monitor contact status and detect potential failures before they impact turbine operation.

Enhanced Reliability and Safety Features: A significant advantage of the IS200DTAOH1ABA is its comprehensive safety architecture that includes built-in protection against field-side faults. Each output channel features individual fusing and overload protection that prevents damage from short circuits or excessive current draw. The module’s design incorporates failsafe operation principles that ensure predictable behavior during power loss or system faults. The IS200DTAOH1ABA also includes real-time contact monitoring that verifies actual output status compared to commanded states, providing crucial feedback for critical control applications. These safety features, combined with the module’s robust construction and high-quality components, make the IS200DTAOH1ABA an exceptionally reliable choice for controlling essential turbine auxiliary systems where operational integrity is paramount.

Application Field

The IS200DTAOH1ABA is extensively deployed in power generation facilities utilizing GE’s heavy-duty gas and steam turbines, where it controls critical auxiliary systems essential for safe and efficient operation. The module serves as the primary control interface for lube oil system components, operating auxiliary pumps, cooling fans, and heating elements that maintain proper oil viscosity. In fuel systems, the IS200DTAOH1ABA controls purge valves, drain valves, and safety shutoff devices that ensure proper fuel handling and combustion safety. The module also manages cooling water system components, operating control valves and circulation pumps that maintain optimal operating temperatures throughout the turbine system.

Beyond traditional power generation, the IS200DTAOH1ABA finds important applications in industrial turbine installations for pipeline compression, refinery operations, and large-scale mechanical drive systems. The module’s robust output capabilities make it ideal for controlling hydraulic system components that position inlet guide vanes and other control elements in response to operating conditions. In combined cycle power plants, the IS200DTAOH1ABA coordinates auxiliary equipment between gas turbines, steam turbines, and heat recovery systems, ensuring seamless operation across the entire power generation process. The module’s reliability and diagnostic capabilities also make it suitable for critical infrastructure applications where continuous operation is essential, including district heating systems and industrial cogeneration facilities.
