Description

The KOLLMORGEN AKC-PCM-M1-120-00N-00-000 is a compact, high-performance servo drive engineered for precision motion control in industrial automation systems. As part of Kollmorgen’s AKC (Advanced Kollmorgen Compact) series—designed as a modern successor to the legacy AKD-PCM platform—this single-axis amplifier delivers responsive torque control, fast update rates, and seamless integration with EtherCAT®-based motion networks. The KOLLMORGEN AKC-PCM-M1-120-00N-00-000 accepts 120 VAC input and provides up to 1.5 kW continuous output power, making it ideal for small-to-midsize applications requiring dynamic positioning, velocity control, or synchronized multi-axis coordination.

Positioned as a cost-effective yet technologically advanced solution, the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 supports both standard and safety-critical operations through integrated Safe Torque Off (STO) functionality compliant with IEC 61800-5-2. Its native EtherCAT communication enables deterministic real-time control with sub-millisecond cycle times, allowing machine builders to achieve high throughput without sacrificing accuracy. Whether deployed in a robotic arm, labeling station, or CNC auxiliary axis, the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 ensures smooth motion profiles, minimal settling time, and long-term reliability in demanding production environments.

Technical Specifications

Parameter Name	Parameter Value
Product Model	AKC-PCM-M1-120-00N-00-000
Manufacturer	Kollmorgen
Product Type	Single-Axis Servo Drive (Amplifier)
Input Voltage	120 VAC ±10%, single-phase, 50/60 Hz
Continuous Output Power	1.5 kW
Peak Current	12 A (for 1 second)
Continuous Current	6 A
Communication Interface	EtherCAT® (CoE – CAN Application Protocol over EtherCAT)
Feedback Support	EnDat 2.2, BiSS C, incremental encoder, Hall sensors
Safety Functions	Safe Torque Off (STO) per IEC 61800-5-2, SIL 2 / PL d
Operating Temperature	0°C to +45°C (derating above 40°C)
Protection Features	Overcurrent, overvoltage, undervoltage, overheating, short-circuit
Mounting	DIN rail (TS-35/7.5 or 15) or panel mount
Dimensions (W × H × D)	60 mm × 160 mm × 150 mm
Weight	Approx. 1.2 kg
Certifications	CE, UL, cUL, KC, RCM

Main Features and Advantages

Native EtherCAT performance: The KOLLMORGEN AKC-PCM-M1-120-00N-00-000 leverages full EtherCAT protocol stack with distributed clock synchronization, enabling jitter-free motion across multi-axis machines. Cycle times as low as 250 µs allow tight coordination in high-speed packaging or pick-and-place applications.

Integrated safety without add-ons: Unlike competitive drives that require external safety modules, the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 includes dual-channel STO as standard—reducing cabinet space, wiring complexity, and validation effort for ISO 13849 compliance.

Broad motor compatibility: The drive natively supports Kollmorgen’s AKM, TBM, and KBM servo motors via EnDat 2.2 or BiSS C, but also works with third-party motors using incremental or analog feedback—offering flexibility during retrofits or custom builds.

Compact thermal design: Despite its 1.5 kW rating, the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 uses an optimized heatsink and convection cooling to operate reliably in tightly packed control panels. No external fan is required under normal conditions, reducing maintenance and noise.

Plug-and-play commissioning: Using Kollmorgen’s WorkBench software, users can auto-detect the KOLLMORGEN AKC-PCM-M1-120-00N-00-000, tune gains, and validate STO wiring in minutes—accelerating machine startup and reducing engineering overhead.

Robust protection suite: Comprehensive diagnostics monitor DC bus voltage, IGBT temperature, and ground faults in real time. If a fault occurs, the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 logs error codes for rapid troubleshooting—minimizing mean time to repair (MTTR).

Application Field

The KOLLMORGEN AKC-PCM-M1-120-00N-00-000 excels in high-cycle automation where speed, precision, and reliability intersect. In food and beverage packaging lines, it drives delta robots that place lids or sort containers at rates exceeding 120 picks per minute—its fast current loop ensuring consistent path accuracy despite mechanical wear. The integrated STO allows safe access during cleaning cycles without full line shutdown.

In semiconductor handling equipment, the KOLLMORGEN AKC-PCM-M1-120-00-00-000 controls wafer transfer arms requiring sub-micron repeatability. Its low electrical noise and deterministic EtherCAT timing prevent vibration-induced misalignment during delicate movements. Similarly, in medical device assembly, this drive powers precision screwdriving or dispensing axes where torque consistency directly impacts product quality.

Machine tool builders use the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 for auxiliary functions like tool changers, coolant pumps, or rotary tables—applications that benefit from coordinated motion but don’t require full CNC interpolation. Its compact size fits into retrofit kits for legacy mills seeking modern servo performance without cabinet redesign.

Finally, in lab automation and 3D printing, the KOLLMORGEN AKC-PCM-M1-120-00N-00-000 provides quiet, smooth operation essential for sensitive measurements or surface finish quality—proving that high dynamics need not come with audible whine or thermal instability.

Installation and Maintenance

Pre-installation preparation: Before installing the KOLLMORGEN AKC-PCM-M1-120-00N-00-000, ensure adequate clearance (minimum 20 mm above and below) for natural convection cooling. Verify that the 120 VAC supply includes proper grounding and meets harmonic distortion limits per IEC 61000-3-2. Use shielded twisted-pair cables for motor power and feedback, with shields bonded to the drive’s PE terminal to minimize EMI.

Maintenance recommendations: The KOLLMORGEN AKC-PCM-M1-120-00N-00-000 is largely maintenance-free due to its fanless design, but periodic inspection is recommended. Check terminal torque annually (0.5 Nm for signal connectors, 0.6 Nm for power terminals). Monitor operating temperature—if consistently above 50°C, consider derating or improving cabinet airflow. Store spare KOLLMORGEN AKC-PCM-M1-120-00N-00-000 units in anti-static bags at 10–30°C with<60>
