Description

The ABB CI570 3BSE001440R1is a high-performance controller module that serves as the central processing unit (CPU) for the ABB AC 800M controller family, a cornerstone of the ABB Ability™ System 800xA distributed control system (DCS). This powerful processor is engineered to execute complex regulatory control, sequential logic, and advanced process optimization algorithms for critical industrial applications. Its primary role is to gather data from field devices via I/O modules, execute the control program, and communicate the results to the operator stations and higher-level systems, forming the intelligent core of the automation solution.As a pivotal component in the System 800xA architecture, the ABB CI570 3BSE001440R1delivers the deterministic performance and high availability required for continuous processes. It is designed to handle a vast number of I/O points and complex control loops with a fast and predictable scan time, ensuring consistent and safe plant operation. The value of the ABB CI570 3BSE001440R1lies in its robust processing power, extensive communication capabilities, and seamless integration within the 800xA environment, which together enable enhanced operational efficiency, improved product quality, and maximum asset utilization in the most demanding industrial sectors.

ABB CI570 3BSE001440R1

Technical Specifications

Main Features and Advantages

The ABB CI570 3BSE001440R1is distinguished by its powerful processing capability and high availability design. The module features a high-speed processor and ample memory, allowing it to execute extensive control strategies with very short scan times. This deterministic performance is critical for fast-acting control loops, such as those in compressor control or boiler combustion management, where any delay can impact process stability and efficiency. Furthermore, the CI570 3BSE001440R1supports a fully redundant configuration where two controllers operate in a primary/standby setup. In the event of a fault in the primary controller, a bumpless transfer to the standby unit occurs within milliseconds, ensuring uninterrupted control and maximizing plant availability.Integration and cybersecurity are foundational to its design. The ABB CI570 3BSE001440R1is natively integrated with the System 800xA engineering environment, allowing for seamless configuration, monitoring, and diagnostics. Its multiple communication interfaces enable easy connection to a wide array of I/O subsystems (like S800 I/O) and fieldbus networks, as well as integration with PLCs and other third-party systems. From a security perspective, the controller incorporates features to protect against unauthorized access and cyber threats, which is an increasingly critical requirement for modern industrial control systems. The robust construction of the ABB CI570 3BSE001440R1ensures long-term reliability, making it a dependable investment for critical infrastructure.

Application Field

The ABB CI570 3BSE001440R1is deployed in large-scale, mission-critical process control applications across various industries. A primary application is in power generation, particularly in combined-cycle gas turbine (CCGT) plants. Here, the ABB CI570 3BSE001440R1controller executes the complex control logic for the gas turbine, steam turbine, and balance-of-plant systems, ensuring optimal efficiency and safe operation during rapid load changes. Its high-speed processing is essential for managing the turbine’s fuel and combustion systems, while its redundancy capability guarantees continuous power supply to the grid.In the oil and gas sector, the ABB CI570 3BSE001440R1is often the control core for large offshore platforms or onshore liquefied natural gas (LNG) terminals. It manages critical processes like gas compression, cryogenic heat exchange, and safety shutdown systems. The controller’s ability to handle complex interlocks and regulatory loops with high reliability is paramount for personnel safety, environmental protection, and the economic viability of the facility. Similarly, in chemical and pharmaceutical plants, the CI570 3BSE001440R1ensures precise control of batch processes and continuous reactions, guaranteeing product quality and consistency while complying with strict regulatory standards.

ABB CI570 3BSE001440R1

Related Products

• ABB PM802F / PM803F:Processor modules in the same AC 800M family, with varying performance levels.

• ABB S800 I/O Modules:The various input/output modules (e.g., AI810, DI810, AO810) that connect field devices to the CI570controller.

• ABB SD822 / SD823:Communication modules that provide additional network interfaces for the AC 800M rack.

• ABB TP830:A typical power supply module for the AC 800M baseplate.

• ABB CombiTune Unit:A module used for controller redundancy and bumpless switchover.

• ABB System 800xA Software:The comprehensive engineering and operator station software that configures and interfaces with the CI570.
