Description

The GE IC698CPE030-GJ is a redundant power supply expansion module designed for the GE Speedtronic Mark VIe turbine control system, which is built on the PACSystems RX3i platform. As part of GE’s advanced, scalable, and safety-certified control architecture for gas and steam turbines, this module plays a critical role in ensuring continuous, fault-tolerant power delivery to I/O modules, terminal boards, and field devices within the Mark VIe chassis.

Unlike standard power supplies, the IC698CPE030-GJ does not generate power itself but acts as a power distribution and redundancy management interface. It accepts dual +24VDC inputs from external redundant power sources (typically via IC698PSDxxx power supply modules or external DIN-rail supplies) and provides isolated, fused, and monitored outputs to multiple I/O slots in the Mark VIe I/O pack. In the event of a primary power failure, it seamlessly switches to the backup source without interrupting control operations—critical for applications requiring high availability, such as combined-cycle power plants, LNG facilities, or black-start capable generators.

The “-GJ” suffix denotes a specific hardware revision or regional configuration compliant with global safety and electromagnetic compatibility (EMC) standards. The module features LED status indicators for input voltage presence, fuse status, and redundancy health, enabling rapid diagnostics during maintenance or commissioning.

GE IC698CPE030-GJ

Technical Specifications

Parameter Name	Parameter Value
Product Model	IC698CPE030-GJ
Manufacturer	General Electric (GE)
Product Type	Redundant Power Expansion Module
Compatible System	GE Mark VIe / PACSystems RX3i
Primary Function	Dual-input +24VDC power distribution with redundancy and monitoring
Input Voltage	+24VDC (dual independent sources, typically 19–32VDC range)
Output	Fused, isolated +24VDC to I/O terminal bases (e.g., IC698TBxx)
Redundancy Support	Yes – automatic failover between primary and secondary inputs
Mounting	Vertical slot in Mark VIe I/O pack (backplane-mounted)
Dimensions	Approx. 254 mm x 178 mm (10″ x 7″)
Operating Temperature	0°C to +60°C (industrial environment rated)
Indicators	LEDs for Input A/B OK, Fuse OK, Redundancy Status
Certifications	CE, UL, cUL, IEC 61508 SIL2 (when used in certified safety applications)
Hot-Swap Capable	Yes (with proper system configuration)

Main Features and Advantages

✅ True Redundant Power Architecture:
The IC698CPE030-GJ enables N+1 or 1:1 redundant power schemes by accepting two independent +24VDC feeds. If one fails, the other instantly takes over—ensuring zero interruption to excitation, fuel valve, or protection circuits.

✅ Integrated Diagnostics & Monitoring:
Onboard circuitry continuously monitors input voltages and fuse integrity. Status is reported to the Mark VIe controller via the backplane, allowing alarms to be triggered in ToolboxST software before a failure impacts operation.

✅ Enhanced System Safety:
By isolating and fusing each output channel, the IC698CPE030-GJ prevents short circuits in one I/O module from cascading to others—critical for SIL-rated turbine trip systems.

✅ Seamless Mark VIe Integration:
Designed specifically for the Mark VIe’s modular I/O packs, the IC698CPE030-GJ requires no external wiring for communication. Configuration is handled automatically through the system’s topology database.

✅ Field-Proven Reliability:
Manufactured under GE’s stringent quality controls, this module operates reliably in high-vibration, high-temperature environments typical of turbine enclosures and offshore platforms.

Application Field

The GE IC698CPE0330-GJ is exclusively used in GE Speedtronic Mark VIe-based turbine control systems, including:

Heavy-duty gas turbines(e.g., 7HA, 9HA, 6B, 7E)
Steam turbinesin fossil and nuclear power plants
Aeroderivative turbinesfor mechanical drive or power generation
Combined heat and power (CHP)installations

In these applications, it powers critical I/O such as:

Vibration and speed sensors (via analog input modules)
Fuel control valve positioners (via HART or analog outputs)
Emergency shutdown solenoids (via digital outputs)
Generator synchronization relays

Its redundancy ensures compliance with grid codes (e.g., NERC, ENTSO-E) that mandate continuous control during auxiliary power disturbances.

GE IC698CPE030-GJ

Installation and Maintenance

Installation Guidelines:

Install theIC698CPE030-GJ in a designated slot within the Mark VIe I/O pack (typically adjacent to powered terminal bases).
Connect two independent +24VDC sources to the terminal block (labeled “A” and “B”). Use appropriately sized wire and torque terminals to spec.
Ensure both power sources are grounded per GE’s grounding guidelines to avoid ground loops.
Verify LED indicators show “A OK” and “B OK” after power-up.

Maintenance Recommendations:

During scheduled outages, inspect fuse cartridges (accessible via front panel) for discoloration or open circuits.
UseToolboxST to review power health logs and check for historical undervoltage events.
Keep a spareIC698CPE030-GJ on-site—replacement takes<10>
Store spares in anti-static, dry conditions (<60>
