TURCK BIM-M12E-AG4X Magnetic Field Sensor 90mm M12 Barrel 2-Wire NO In Stock

Stock item - brand new and in stock (库存现货 / 图尔克现货), ships within 3-5 days.

The BIM-M12E-AG4X is a magnetic-inductive proximity switch: it detects permanent magnets through non-ferromagnetic walls such as aluminium, stainless steel, plastic or brass, which makes it the classic end-of-stroke position sensor for pneumatic cylinders (cylinder sensor) and for hidden-position checks where mechanical switches cannot survive. With the DMR31-15-5 actuation magnet it reaches a 90 mm operating distance - far beyond what a plain reed or Hall sensor offers in the same M12 barrel format. The polarized 2-wire DC output (10...65 VDC, NO) wires straight into standard PLC inputs.

Details:

• Model: BIM-M12E-AG4X | Ident-No. 4430200 | magnetic field sensor, magnetic-inductive

• Rated operating distance: 90 mm (with magnet DMR31-15-5) | repeat accuracy ≤ 0.3 %

• Design: threaded barrel M12 x 1, Ø 12 mm, length 64 mm, chrome-plated brass CuZn, active face PBT-GF30

• Output: 2-wire, NO contact, 10...65 VDC, ≤ 200 mA | switching frequency 0.3 kHz

• Cable: 2 m grey PUR, Ø 5.2 mm, 2 x 0.34 mm²

• Protection: IP67 | ambient -25...+70 °C | yellow LED switching indicator | MTTF 2283 years (SN 29500)

• Brand: TURCK (Germany) | Condition: Brand New, Original | Stock: 库存现货, in stock

Lead Time: IN STOCK, 3-5 days after payment
Delivery: FedEx, SF Express, EMS
Condition: In Stock, Brand New
Payment Method: T/T, 30% deposit, 70% balance of payment
Price: Please contact us for further inquiry. All quotes are based on EXW excluding tax.
Remark: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
