TURCK BS8141-0 Field-Wireable M12 Connector 4-Pin Male Straight A-Coded In Stock

Brand new and in stock (库存现货 / 现货) - ready to ship within 3-5 days.

The BS8141-0 is a field-wireable eurofast connector for the sensor and actuator side: a straight M12 x 1 male head with 4 A-coded pins that is assembled directly onto the customer cable. The screw/clamp terminals accept conductors from 0.14 to 0.75 mm², the PG7 gland takes cable diameters of 4...6 mm, and the die-cast zinc, nickel-plated coupling nut plus the PA plastic housing give a sealed IP67 joint when mated. Typical uses: site-length sensor cabling, spare connector replacement and cabinet retrofit work.

Details:

• Model: BS8141-0 | Order no. 69010 | field-wireable connector

• Connector: male, M12 x 1, straight, A-coded, 4-pin

• Termination: screw/clamp, PG7 thread, cable Ø 4...6 mm, 0.14...0.75 mm²

• Ratings: 250 V / 4 A | coupling nut die-cast zinc nickel-plated | housing plastic PA

• Protection: IP67 (mated) | -40...+85 °C | > 100 mating cycles | cULus approved

• EAN 4047101458145 | weight 22 g | country of origin DE

• Brand: TURCK (Germany) | Condition: Brand New, Original | Stock: 库存现货, in stock

Third photo shows the same BS-series field-wireable connector family from our TURCK stock for reference.

Lead Time: IN STOCK, 3-5 days after payment
Delivery: FedEx, SF Express, EMS
Condition: In Stock, Brand New
Payment Method: T/T, 30% deposit, 70% balance of payment
Price: Please contact us for further inquiry. All quotes are based on EXW excluding tax.
Remark: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description.
