Description

Product Description for GE H201Ti Controller

Detailed Parameter Table

GE H201Ti

Product Introduction

The GE H201Ti is a high-performance Programmable Logic Controller (PLC) from GE Fanuc’s VersaMax Micro/Nano series, designed for compact yet powerful automation applications.

This controller offers advanced functionality in a small footprint, making it ideal for:

• Standalone machine control

• Small-scale process automation

• Remote monitoring and control systems

The H201Ti integrates seamlessly with the VersaMax family of I/O modules, allowing flexible system expansion. It supports a wide range of communication protocols and is programmable using GE’s Logic Developer PLC software, which provides tools for logic programming, HMI integration, and motion control.

It is commonly used in industries such as:

• Packaging

• Material Handling

• Food & Beverage

• Water/Wastewater

• HVAC and Building Automation

Core Advantages and Technical Highlights

✅ Compact Design with Powerful Performance

• Combines a powerful CPU with rich feature set in a small package

• Ideal for space-constrained applications requiring robust performance

✅ Flexible I/O Expansion

• Supports up to 64 digital or 16 analog I/O points

• Compatible with VersaMax GFK-1514 series I/O modules

• Modular design allows easy configuration and scalability

✅ Advanced Communication Capabilities

• Built-in RS-232 serial portfor programming and device communication

• Optional Ethernet connectivityavailable for integration into larger networks

• Supports common industrial protocols like:

• Modbus RTU/TCP

• SNMP

• EtherNet/IP (on compatible models)

• TCP/IP

✅ Integrated Control Features

• High-speed counters and pulse outputs for motion and positioning control

• PID loops for process control applications

• Real-time clock and data logging capabilities

✅ User-Friendly Programming Environment

• Uses Logic Developer PLC(formerly known as Logicmaster or VersaPro)

• Also supported by Proficy Machine Editionsuite for integrated automation projects

• Drag-and-drop configuration and online editing support

✅ DIN Rail Mounting and Industrial Durability

• Designed for use in standard industrial control cabinets

• Operates reliably in temperatures from 0°C to +60°C

• Robust construction suitable for harsh environments

Typical Application Scenarios

? Industrial Automation

• Assembly lines and conveyor systems

• Packaging machines

• Pneumatic/hydraulic machine control

? Water and Wastewater Treatment

• Pump control panels

• Flow and level monitoring systems

• SCADA interface applications

? Food and Beverage Processing

• Filling and capping machines

• Batch control systems

• Conveyor-based sorting systems

? HVAC and Building Systems

• Chiller plant controls

• Air handling unit automation

• Remote environmental monitoring

? Machine Builders and OEMs

• Custom machinery with embedded control

• Retrofitting older PLC systems

• Cost-effective solution for small automation cells

Related Model Recommendations

If you’re using or considering the GE H201Ti, here are some related controllers and modules that may be useful:

• GE H202Ti / H203Ti: Higher-end models with more I/O capacity and advanced features

• GE H401Ti / H601Ti: For larger systems with higher processing demands

• VersaMax I/O Modules:

• GFK-1171 (Discrete Input/Output Modules)

• GFK-1191 (Analog Input/Output Modules)

• GFK-1344 (Communication Modules)

• Programming Software:

• Logic Developer PLC

• Proficy Machine Edition

• Communication Adapters:

• IC693CBL* series cables

• USB-to-RS232 convertersfor modern PCs

GE H201Ti

Installation, Commissioning, and Maintenance Instructions

?️ Before Installation:

• Confirm power supply voltage is 24 VDC

• Ensure all I/O modules are compatible with the H201Ti base unit

• Use proper ESD protection when handling sensitive electronics

? Installation Steps:

1. Mount the H201Tibase unit on a standard DIN rail

2. Connect the 24 VDC power supplyto the terminal block

3. Attach any required I/O modulesto the right-hand side of the base unit

4. Connect programming cable to the RS-232 portfor initial setup

5. Apply power and verify LED indicators show normal status

? Commissioning Steps:

1. Launch Logic Developer PLCor Proficy Machine Edition

2. Connect to the H201Ti via serial or Ethernet connection

3. Download the PLC program and configure communication settings

4. Test I/O functionality and verify correct operation of connected devices

5. Set up any remote communication parameters if needed

? Maintenance Guidelines:

• Regularly check wiring connections and terminal blocks

• Monitor LED indicators for early signs of faults

• Backup PLC programs regularly to prevent data loss

• Replace the unit if persistent errors occur or diagnostics fail
