Description

The FOXBORO P0926JM is a Foundation Fieldbus H1 power conditioner module designed for the FOXBORO I/A Series distributed control system, providing both regulated power and intrinsic safety barrier functionality for Fieldbus segments in hazardous industrial environments. As a key enabler of digital field instrumentation networks, the FOXBORO P0926JM delivers clean, stabilized power to up to eight Fieldbus devices while ensuring compliance with explosion protection standards such as ATEX, IECEx, and FM for use in Zone 0/1 or Class I, Division 1 areas. It integrates seamlessly into I/A Series cabinets via the FBM242 or FBM244 Fieldbus interface modules, forming a complete digital communication and power infrastructure.

Positioned as a robust and certified solution for process industries, the FOXBORO P0926JM eliminates the need for external Fieldbus power supplies and discrete barriers, reducing panel complexity and wiring errors. Its galvanic isolation between the host system and field segment protects the DCS from ground loops and electrical transients. By combining power conditioning, signal coupling, and intrinsic safety in a single DIN-rail module, the FOXBORO P0926JM supports reliable, high-integrity communication in applications where safety, availability, and regulatory compliance are non-negotiable—making it indispensable in oil & gas, chemical, and pharmaceutical plants deploying digital field networks.

Technical Specifications

Parameter Name	Parameter Value
Product Model	P0926JM
Manufacturer	FOXBORO (an ABB company)
Product Type	Foundation Fieldbus H1 power conditioner / intrinsic safety barrier
Input Voltage	24 V DC ±10%
Output Voltage	15–18 V DC (nominal, under load)
Maximum Output Current	30 mA per segment (supports up to 8 devices)
Fieldbus Standard	IEC 61158-2 (Foundation Fieldbus H1)
Intrinsic Safety Certification	ATEX, IECEx, FM (Entity parameter compliant)
Isolation	Galvanic isolation between system and field (≥500 V AC)
Mounting	DIN rail in I/A Series FBM24x backplane chassis
Operating Temperature	0°C to +60°C
Hazardous Area Rating	Suitable for Zone 0/1, Class I, Division 1
Communication Interface	Couples to FBM242/244 Fieldbus interface modules via ribbon cable

Main Features and Advantages

Integrated power and safety in one module: The FOXBORO P0926JM uniquely combines Fieldbus power supply, signal coupling, and intrinsic safety barrier functions into a single compact unit. This eliminates external power conditioners and discrete Zener barriers, simplifying design, reducing footprint, and minimizing potential failure points in critical instrument loops.

Certified for the most demanding hazardous areas: Unlike generic Fieldbus power supplies, the P0926JM is fully compliant with Entity parameters under IEC 60079-11, allowing direct connection to IS-certified Fieldbus devices in explosive atmospheres without additional certification work. Its ATEX, IECEx, and FM approvals make it globally deployable in refineries, offshore platforms, and chemical reactors.

Seamless integration with I/A Series architecture: The FOXBORO P0926JM plugs directly into the same backplane as FBM242/244 interface modules, receiving power and status monitoring through the I/A Series chassis. This enables centralized diagnostics—such as overcurrent or short-circuit alerts—via the DCS operator station, improving maintenance response time.

Robust performance under real-world conditions: The P0926JM maintains stable output voltage even with cable lengths up to 1,900 meters and varying device loads. Its low-noise design ensures signal integrity for reliable communication at 31.25 kbps, preventing data collisions or device dropouts that could trigger false alarms or shutdowns in continuous processes.

Application Field

The FOXBORO P0926JM is predominantly deployed in oil & gas upstream and downstream facilities, where Foundation Fieldbus networks connect smart transmitters, valve positioners, and analyzers in classified zones. In offshore platforms, the FOXBORO P0926JM powers Fieldbus segments on wellheads, separators, and flare systems—environments where intrinsic safety is mandatory due to flammable hydrocarbon vapors. Similarly, in LNG terminals and refineries, it supports digital valve marshalling for emergency shutdown (ESD) and fire & gas systems.

Chemical and pharmaceutical plants also rely on the P0926JM for reactor temperature control, batch sequencing, and CIP (Clean-in-Place) monitoring, where precise digital communication reduces calibration drift and improves batch repeatability. Even in power generation, particularly in hydrogen-cooled generator monitoring or ammonia dosing skids, the FOXBORO P0926JM provides a certified, low-maintenance power solution for Fieldbus instruments. Its plug-and-play compatibility with existing I/A Series infrastructure makes it ideal for both greenfield projects and brownfield digital upgrades seeking to leverage smart device diagnostics without compromising safety.

Installation and Maintenance

Pre-installation preparation: Verify that the I/A Series chassis (e.g., FBM207B) is powered and properly grounded before inserting the FOXBORO P0926JM. Confirm that the connected FBM242 or FBM244 module is correctly configured in Control Configuration Studio (CCS). Ensure field cabling uses twisted-pair, shielded Fieldbus cable (e.g., Belden 3105A) with shield grounded at one end only to avoid ground loops. Do not exceed 30 mA total segment current or 1,900-meter trunk length when designing the network.

Maintenance recommendations: Monitor segment health via I/A Series diagnostics—look for “Power Fault” or “Short Circuit” alarms associated with the P0926JM. If communication fails, check for field wiring shorts or excessive device loading before replacing the module. The FOXBORO P0926JM has no user-serviceable parts; if faulty, replace as a complete unit. Keep spares in static-safe packaging and avoid exposure to condensation or extreme temperatures during storage. Regularly inspect terminal blocks for corrosion in humid or marine environments.
