Description

The Kollmorgen DBL4N00530-0R2-DD0-S40 is a compact, high-performance servo drive from Kollmorgen’s AKD-N series, engineered for demanding industrial motion control applications requiring precision, speed, and reliability. As part of the AKD platform—renowned for its flexibility and advanced control capabilities—the Kollmorgen DBL4N00530-0R2-DD0-S40 delivers up to 5 A continuous output current and 10 A peak current, making it ideal for driving mid-range permanent magnet synchronous motors (PMSMs) in packaging machinery, printing systems, robotic arms, and material handling equipment.

This drive features native EtherCAT communication with CoE (CANopen over EtherCAT) protocol support, enabling deterministic, high-speed multi-axis synchronization with minimal latency. The Kollmorgen DBL4N00530-0R2-DD0-S40 also includes integrated Safe Torque Off (STO) functionality compliant with IEC 61800-5-2 and SIL 3 / PL e safety standards, allowing safe shutdown without cutting main power—critical for collaborative robotics and human-machine interaction zones. Its IP20-rated enclosure and optimized thermal design ensure reliable operation in typical industrial environments, while the shared DC bus architecture (DD0 suffix) supports energy-efficient multi-drive configurations by regenerating braking energy across axes.

Designed for seamless integration, the Kollmorgen DBL4N00530-0R2-DD0-S40 works natively with Kollmorgen’s WorkBench software for auto-tuning, diagnostics, and firmware updates. Despite its compact 60 mm width, it offers full-featured performance, including advanced control loops, real-time oscilloscope, and extensive I/O options—making it a versatile solution for both new machine builds and legacy system upgrades.

Technical Specifications

Main Features and Advantages

Advanced motion performance in a compact form: The Kollmorgen DBL4N00530-0R2-DD0-S40 combines high bandwidth current and velocity control loops with adaptive tuning algorithms to achieve sub-millisecond response times—essential for high-speed pick-and-place or web tensioning applications. Its 5 A continuous rating efficiently drives motors like the AKM2G or AKM3G series, delivering smooth motion even at low speeds thanks to advanced encoder interpolation and disturbance rejection.

Native EtherCAT with safety built-in: Unlike retrofit solutions, the Kollmorgen DBL4N00530-0R2-DD0-S40 integrates EtherCAT and STO at the hardware level. This eliminates the need for external safety relays in many applications and ensures<10>

Energy-efficient multi-axis scalability: The DD0 designation indicates support for shared DC bus architectures. In multi-axis machines (e.g., CNC routers or palletizing robots), this allows regenerative energy from decelerating axes to be reused by accelerating ones—reducing heat dissipation, lowering energy bills, and minimizing the size of braking resistors. The Kollmorgen DBL4N00530-0R2-DD0-S40 can be easily paralleled with other AKD-N drives on the same DC bus, creating highly synchronized, eco-friendly motion systems.

Application Field

The Kollmorgen DBL4N00530-0R2-DD0-S40 excels in industries where precision, speed, and safety are non-negotiable. In packaging machinery, it controls fillers, cappers, and labelers with micron-level accuracy at high cycle rates, while STO ensures operator safety during maintenance. In digital printing and converting, the drive maintains constant web tension across unwind/rewind stations using real-time torque control—preventing material stretch or breakage on thin films or foils.

In industrial robotics, particularly SCARA and 6-axis arms used in assembly or dispensing, the Kollmorgen DBL4N00530-0R2-DD0-S40 enables smooth trajectory tracking and rapid direction changes. Its EtherCAT interface ensures tight coordination with vision systems and end-of-arm tooling. Similarly, in automated guided vehicles (AGVs) and mobile robots, the drive’s compact size and efficient thermal management allow integration into space-constrained drive modules. Across all these applications, the Kollmorgen DBL4N00530-0R2-DD0-S40 delivers the blend of performance, safety, and connectivity that modern smart factories demand.

Related Products

AKD-N Series Drives (e.g., DBL4N01030-0R2-DD0-S40): Higher current variant (10 A) in the same family.
AKM2G / AKM3G Servo Motors: Optimally matched motors for the DBL4N00530-0R2-DD0-S40.
AKD WorkBench Software: Official configuration and tuning tool for AKD-N drives.
AKD-P00306-NBAN-0000: Older AKD-P series equivalent—AKD-N offers smaller size and better EtherCAT support.
S700 Series Drives: Legacy Kollmorgen drives; AKD-N provides modern replacement path.
TB-55 Terminal Block Kit: Optional I/O expansion for additional digital/analog signals.
AKD-NAF-005: AC input filter recommended for compliance with EMC standards.
