Description

The ABB S-073N 3BHB009884R5211 is a high-reliability, DIN-rail mounted 24 VDC power supply unit (PSU) engineered specifically for use in ABB’s AC 800M automation systems, S800 I/O modules, and broader System 800xA control architectures. Delivering a continuous output of 24 VDC at 10 A (240 W), this compact yet robust power module ensures stable, ripple-free voltage for sensitive digital logic, communication interfaces, and field I/O—even under fluctuating line conditions or partial load scenarios.

Designed for industrial environments, the S-073N 3BHB009884R5211 features a universal AC input range (85–264 VAC, 47–63 Hz) and supports DC input (100–370 VDC), making it suitable for both standard utility-fed panels and DC-bus-powered installations (e.g., in substations or marine applications). It includes comprehensive protection mechanisms—overvoltage, overcurrent, short-circuit, and thermal shutdown—with automatic recovery to minimize downtime. The unit operates convection-cooled (no fan), eliminating moving parts and enhancing long-term reliability in dusty or corrosive settings.

A key feature of the S-073N 3BHB009884R5211 is its compatibility with redundant power configurations. When paired with a second S-073N unit and an optional diode redundancy module (e.g., ABB R-073 or third-party equivalents), the system can tolerate a complete power supply failure without interrupting controller or I/O operation—a critical requirement in safety-instrumented or continuous-process applications.

Technical Specifications

Main Features and Advantages

✅ Industrial-grade reliability: Fanless design and wide temperature tolerance ensure years of maintenance-free operation in demanding plants.
✅ Universal input compatibility: Works on global AC grids or high-voltage DC systems—ideal for hybrid or backup-powered installations.
✅ Seamless ABB ecosystem integration: Directly powers AC 800M CPUs, S800 I/O clusters, and communication modules via standard backplane or terminal blocks.
✅ Redundancy-ready: Supports N+1 power architectures using external diode modules for zero-downtime critical systems.
✅ Built-in diagnostics: Clear visual status indication simplifies troubleshooting during commissioning or maintenance.
✅ High surge tolerance: Withstands voltage sags and inrush currents common in motor-heavy facilities without tripping.

Application Field

The S-073N 3BHB009884R5211 is widely used wherever ABB control systems demand clean, uninterrupted low-voltage power:

• Power generation: Supplies logic power to turbine control panels and switchyard I/O in thermal, hydro, and renewable plants.

• Water & wastewater: Powers remote pumping station controllers with immunity to grid fluctuations.

• Oil & gas: Installed in offshore platforms and refineries where fanless, explosion-compatible (via enclosure) PSUs are required.

• Metals & mining: Operates reliably in high-vibration, high-temperature mill environments.

• Manufacturing: Feeds PLC racks and safety I/O in automotive or food processing lines requiring SIL-compliant power integrity.

Related Products

• S-072N (3BHB009883R5211): 5 A / 120 W variant for smaller I/O clusters

• R-073: ABB diode redundancy module for pairing two S-073N units

• TB840A: Termination baseplate compatible with redundant PSU setups

• PM864AK01: AC 800M CPU commonly powered via S-073N

• S800 I/O Modules: Digital/analog modules drawing power from the same PSU

• System 800xA: Engineering and operations platform integrating these components

• Phoenix Contact QUINT4: Third-party alternative (non-ABB) with similar specs

Installation and Maintenance

Pre-installation tips:

• Mount on a grounded DIN rail with ≥20 mm clearance on both sides for heat dissipation.

• Use appropriately sized wiring (min. 1.5 mm² copper) for input and output terminals.

• Torque terminal screws to 0.6 Nm to prevent overheating.

• In redundant setups, ensure both PSUs share identical input sources or isolated feeds to avoid backfeed issues.

Maintenance best practices:

• Inspect the green “Power OK” LED during routine rounds—flickering may indicate aging capacitors or overload.

• Clean dust buildup annually using dry, non-conductive air (never solvents).

• Monitor output voltage periodically with a calibrated multimeter; replace if outside 23.5–24.5 VDC under load.

• In high-humidity environments, consider conformal coating or sealed enclosures to extend service life.
