WOODWARD EASYGEN-3200-5 (8440-2050 D) – Advanced Generator Control & Protection for Standby, Prime & Grid-Support Applications!

The WOODWARD EASYGEN-3200-5 (model number 8440-2050 D) is a high-performance, multifunction generator set controller designed for single or multiple generator applications up to 5 MW per unit. As part of WOODWARD’s renowned EGCP-3 (EasyGen Control Platform) family, the EASYGEN-3200-5 integrates engine management, generator protection, synchronization, load sharing, and utility interface logic into a single ruggedized unit—eliminating the need for separate relays, synchronizers, and PLCs.

Get a Quote
Manufacturer:
Our extensive catalogue, is available now for dispatch to the worldwide.
  • Email: sales@slxytech.com
  • WhatsApp / Wechat：8617062388866
  • Phone：+86 17062388866

Description

The WOODWARD EASYGEN-3200-5 (model number 8440-2050 D) is a high-performance, multifunction generator set controller designed for single or multiple generator applications up to 5 MW per unit. As part of WOODWARD’s renowned EGCP-3 (EasyGen Control Platform) family, the EASYGEN-3200-5 integrates engine management, generator protection, synchronization, load sharing, and utility interface logic into a single ruggedized unit—eliminating the need for separate relays, synchronizers, and PLCs.

Engineered for mission-critical power systems, the EASYGEN-3200-5 supports both isochronous (ISOCH) and droop load-sharing modes, enabling seamless parallel operation with other generators or the utility grid. It features built-in auto-transfer switch (ATS) logic, making it ideal for emergency standby systems in hospitals, data centers, and telecom facilities. With native support for Modbus TCP/IP, CANbus, and optional DNP3, the controller enables full remote monitoring and SCADA integration.

The unit is UL 1008 listed for use in generator control panels and complies with international standards including IEC 60255 (protection relays) and IEEE 1547 (grid interconnection). Its robust design withstands harsh industrial environments—from desert heat to marine humidity—while delivering precise voltage and frequency regulation under dynamic loads.

⚙️ Technical Specifications

ParameterValue
Model NumberEASYGEN-3200-5
Part Number8440-2050 D
ManufacturerWOODWARD, Inc.
Application RangeUp to 5 MW per generator
Control FunctionsEngine start/stop, sync, load share, ATS logic, black start
Protection FeaturesOver/under voltage, over/under frequency, reverse power, overload, ground fault, loss of excitation
CommunicationEthernet (Modbus TCP/IP), RS-485 (Modbus RTU), CANbus (for WOODWARD actuators), optional DNP3
I/O Capacity32 digital inputs, 16 digital outputs, 16 analog inputs (4–20 mA / 0–10 V), 4 analog outputs
DisplayBacklit graphical LCD with keypad (local HMI)
Power Supply10–32 VDC (dual isolated inputs for redundancy)
Operating Temperature-25°C to +70°C
CertificationsUL 1008, CSA C22.2 No. 107.1, IEC 60255, CE, RoHS
MountingPanel mount (IP65 front panel rating)

✅ Key Features & Advantages

  • All-in-One Control: Replaces multiple devices (governor, AVR interface, synchroscope, protective relay) with a single intelligent platform.

  • True Parallel Capability: Automatically synchronizes and shares load among up to 32 generators using WOODWARD’s proprietary load-sharing algorithms.

  • Smart Grid Interaction: Detects utility failure, initiates black-start sequences, and retransfers loads safely upon grid restoration.

  • Integrated Safety & Compliance: Meets NFPA 110 requirements for Level 1 emergency power systems; supports SIL2 safety functions.

  • Field-Configurable Logic: Customizable control sequences via EasyGen Configuration Studio software—no hard-coded firmware changes needed.

  • Remote Diagnostics: View real-time kW/kVAr, engine hours, alarm history, and trend logs via web browser or SCADA.

  • Future-Proof Design: Firmware upgrades add new features (e.g., cyber security, advanced metering) without hardware replacement.

? Typical Applications

  • Emergency Backup Power: Hospitals, airports, and financial institutions requiring<10>

  • Prime Power in Remote Sites: Mining camps, oil fields, and islands using diesel or gas gensets in islanded mode.

  • Grid Support & Peak Shaving: Industrial plants participating in demand-response programs with fast load acceptance.

  • Marine & Offshore: Shipboard power management with redundant generator sets and shore-power interlock.

  • Renewable Hybrid Systems: Microgrids combining solar, battery, and diesel—where EASYGEN-3200-5 acts as the dispatch controller.

? Related Products

  • EASYGEN-3100: Lower-cost variant for single-generator, non-paralleling applications (<2>

  • EASYGEN-3500: Higher-end model for large multi-MW plants with advanced cybersecurity and historian logging.

  • WOODWARD 2301A/EGCP-2: Legacy controllers often replaced by EASYGEN-3200-5 during modernization.

  • ISB-3 Interface Module: Enables communication between EASYGEN and third-party PLCs or HMIs.

  • EasyGen Configuration Studio: Official PC software for programming, simulation, and diagnostics.

  • GAP-3 Generator Actuator Panel: Optional I/O expansion module for additional field wiring.

? Installation & Maintenance Tips

  • Pre-Installation: Verify CT polarity and PT scaling match configuration file. Ensure CANbus terminators (120 Ω) are installed at both ends.

  • Grounding: Use a single-point ground for analog signals to avoid noise-induced measurement errors.

  • Firmware: Always update to the latest stable version via USB or Ethernet before commissioning.

  • Battery Backup: The internal supercapacitor retains clock and event logs during power loss—replace every 7–10 years.

  • Annual Checks: Validate protection settings against coordination studies; test auto-start under simulated utility outage.
