The TELKOR CPCI-AC-6U-400 is a high-reliability, 400-watt AC-input power supply module designed for 6U CompactPCI (CPCI) systems operating in demanding industrial, defense, and aerospace environments. Compliant with the PICMG 2.11 standard for CPCI power specifications, this 4HP-wide (0.8″ / 20.32 mm) module delivers stable, isolated DC outputs (+3.3V, +5V, +12V, –12V) directly to the CPCI backplane, supporting high-performance embedded computing blades such as single-board computers, FPGA processing cards, and I/O controllers.
Engineered for mission-critical applications, the CPCI-AC-6U-400 accepts a universal AC input range (90–264 VAC, 47–63 Hz), enabling global deployment without manual voltage selection. It features active power factor correction (PFC), overvoltage/overcurrent/short-circuit protection, and intelligent sequencing to ensure safe system startup. With conduction-cooled options available and robust mechanical construction meeting MIL-STD-810 shock/vibration requirements, the TELKOR CPCI-AC-6U-400 is widely deployed in radar signal processors, electronic warfare (EW) systems, mobile command centers, and automated test equipment (ATE).
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Model | CPCI-AC-6U-400 |
| Manufacturer | Telkor (Telkoor) |
| Form Factor | 6U CompactPCI, 4HP (20.32 mm wide) |
| Total Output Power | 400 W continuous |
| Input Voltage | 90–264 VAC, 47–63 Hz (universal) |
| Output Voltages | +3.3V (15A), +5V (20A), +12V (15A), –12V (1A) |
| Efficiency | ≥85% typical at full load |
| Power Factor | >0.98 (with active PFC) |
| Cooling Method | Air-cooled (conduction-cooled variant optional) |
| Operating Temperature | –40°C to +70°C (derating above +50°C) |
| MTBF | >100,000 hours (per MIL-HDBK-217F) |
| Compliance | PICMG 2.11, CE, FCC, RoHS, UL/cUL |
| Safety & Environmental | IEC/EN 60950-1, MIL-STD-810G (shock/vibe) |
| Features | Hot-swap capable, remote inhibit, power good signal, OVP/OCP |
Main Features and Advantages
✅ Universal AC Input & High Efficiency
The CPCI-AC-6U-400 operates from any standard mains supply worldwide (90–264 VAC), eliminating region-specific power configurations. Its active PFC and >85% efficiency reduce harmonic distortion and heat generation—critical for densely packed CPCI chassis.
✅ Full PICMG 2.11 Compliance
Designed strictly to the CompactPCI power specification, it ensures seamless interoperability with backplanes from Kontron, Elma, Schroff, and others. The module provides correct sequencing of +5V standby, main outputs, and Power Good signals per standard timing diagrams.
✅ Ruggedized for Harsh Environments
Built with conformal coating, reinforced connectors, and robust internal potting (in conduction-cooled versions), the CPCI-AC-6U-400 withstands extreme temperature swings, high humidity, and severe mechanical stress—ideal for airborne, shipboard, or field-deployed systems.
✅ Intelligent Protection & Monitoring
Integrated protections include overvoltage (OVP), overcurrent (OCP), short-circuit (SCP), and overtemperature (OTP). A front-panel LED indicates operational status, while the “Power Good” signal enables system-level fault management.
✅ Hot-Swap Ready for High Availability
Supports live insertion/removal in redundant or N+1 power architectures, minimizing downtime during maintenance—a key requirement in telecom and defense CPCI systems requiring 24/7 operation.
Application Field
The TELKOR CPCI-AC-6U-400 is extensively used in applications where reliability, compactness, and stable power delivery are non-negotiable:
Defense & Aerospace: Radar data processing, SIGINT/COMINT platforms, UAV ground control stations
Industrial Automation: High-channel-count data acquisition, real-time machine vision systems
Telecom & Networking: 3G/4G baseband units, network packet brokers using CPCI infrastructure
Test & Measurement: Automated test equipment (ATE) for avionics or semiconductor validation
Transportation: Railway signaling controllers and onboard diagnostic systems (EN 50155 compliant variants available)
Related Products
CPCI-DC-6U-400: 400W DC-input (24/28VDC) version for vehicle/mobile platforms
CPCI-AC-6U-600: Higher-power 600W AC-input variant for GPU or multi-CPU blades
CPCI-RED-6U: Redundancy module for N+1 power sharing between multiple supplies
Elma 6U CPCI Chassis: Compatible enclosures (e.g., Elma 70200 series)
Kontron CP600x Series: Single-board computers often powered by CPCI-AC-6U-400
CPCI-MON-6U: Optional monitoring card for remote power telemetry via IPMI
CPCI-AC-3U-200: 3U form-factor 200W AC supply for space-constrained designs
Telkor CPCI-PSU-Kit: Mounting hardware and EMI gasket kit for conduction cooling
Schroff 6U Backplanes: PICMG 2.11-compliant passive/active backplanes
MIL-COTS Power Solutions: Ruggedized CPCI power modules for military programs
Installation and Maintenance
? Pre-Installation Checklist:
Verify CPCI chassis supports 4HP power slots and meets PICMG 2.11 backplane pinout.
Ensure adequate airflow (≥200 LFM) if using air-cooled version; for conduction-cooled, confirm chassis thermal interface plate contact.
Connect AC input via IEC or terminal block per local safety codes; use shielded power cable grounded at chassis.
Enable hot-swap only if system backplane supports it—otherwise, power down before insertion.
?️ Maintenance Tips:
Periodically inspect air filters (if used) and clean heatsinks to prevent thermal throttling.
Monitor output voltages annually using a calibrated multimeter at test points (if accessible).
In high-vibration environments, check mounting screws and connector retention every 6 months.
Store spares in dry, ESD-safe packaging at room temperature; avoid condensation during cold-to-warm transitions.
