Description

The NI SCXI-1104C 32 channel medium voltage input module is a high-performance signal conditioning module belonging to the NI SCXI(Signal Conditioning Expansion Instrument)series.This module is designed specifically for medium voltage measurement applications,providing 32 differential input channels that can accurately measure voltage signals up to±60V.SCXI-1104C has a built-in signal conditioning circuit,including amplification,filtering,and isolation functions,which can effectively improve measurement accuracy and anti-interference ability.This module is suitable for various industrial automation,testing and measurement,and data acquisition applications,playing a key role in data acquisition in automation systems.By working in conjunction with NI data acquisition cards and LabVIEW software,NI SCXI-1104C is able to build flexible and reliable measurement systems.

SCXI-1104C NI

technical specifications

Product model:SCXI-1104C

manufacturer:NI(National Instruments)

Product type:32 channel medium voltage input module

Number of input channels:32 differential channels

Input voltage range:±60V

Input impedance:>10 MΩ

Common mode rejection ratio:>80 dB

Bandwidth:10 kHz

Isolation voltage:250 Vrms

Working temperature range:0°C to 50°C

Size:SCXI module size

Installation method:SCXI chassis installation

Main features and advantages

The NI SCXI-1104C 32 channel medium voltage input module has the following significant features and advantages:

High channel density:Provides 32 differential input channels,suitable for applications that require a large number of channels.

Wide input voltage range:capable of measuring voltage signals up to±60V,meeting the requirements of medium voltage measurement.

High precision measurement:Built in signal conditioning circuit,including amplification,filtering,and isolation functions,improves measurement accuracy and anti-interference ability.

High common mode rejection ratio:effectively suppresses common mode interference and improves measurement accuracy.

Broadband width:10 kHz bandwidth,meeting the requirements of high-speed signal measurement.

Isolation protection:250 Vrms isolation voltage,protecting the measurement system and computer.

Flexible system integration:Used in conjunction with NI data acquisition cards and LabVIEW software to build a flexible and reliable measurement system.

SCXI-1104C NI

application area

The NI SCXI-1104C 32 channel medium voltage input module is widely used in the following fields:

Industrial automation:used for monitoring and controlling voltage signals of industrial equipment.

Test measurement:Used for voltage measurement of various electronic devices.

Data collection:used to collect voltage signals of various physical quantities.

Automotive testing:used for voltage measurement of automotive electronic systems.

Aerospace:Used for voltage measurement in avionics systems.

Power system:used for voltage measurement of power equipment.

Related products

NI SCXI-1303 terminal module:used to connect SCXI-1104C module and on-site signals.

NI SCXI-1000 chassis:used for installing SCXI modules.

NI data acquisition card:used to collect measurement data of SCXI module.

NI LabVIEW software:used for developing data acquisition and analysis applications.

NI SCXI-1125 Isolated Digital Input Module:Used for collecting digital signals.

NI SCXI-1160 Relay Driver Module:Used for controlling relays.

Installation and maintenance

Preparation before installation:Before installing the SCXI-1104C module,please ensure that the SCXI chassis is correctly installed and connected to the power supply.Check if the module is damaged and prepare the necessary installation tools and materials.During installation,please follow ESD protection measures to avoid static electricity damaging the module.

Maintenance suggestion:Regularly check whether the connection of SCXI-1104C module is firm and clean the dust on the module.Regularly inspect cables and connectors for damage.If any faults are found,please contact NI’s technical support in a timely manner.

SCXI-1104C NI

Product Guarantee

NI provides product assurance for the SCXI-1104C module,including quality assurance and technical support.
