Description

The EATON XV-440-10TVB-1-20 touch panel is a powerful 10.4-inch industrial human-machine interface(HMI)belonging to the EATON XV400 series,designed specifically for harsh industrial environments.This EATON XV-440-10TVB-1-20 touch screen features a high-resolution VGA(640 x 480 pixels)TFT color display screen,combined with intuitive infrared touch technology,providing operators with a clear and easy-to-use interface for monitoring and controlling complex industrial processes.It is worth mentioning that EATON XV-440-10TVB-1-20 is not only an HMI,but its powerful hardware platform also supports upgrading to PLC function through software authorization,achieving perfect integration of control and visualization,simplifying the system architecture and reducing overall costs.In modern industrial automation systems,the EATON XV-440-10TVB-1-20 touch panel has become a key component in improving production efficiency,optimizing process control,and enhancing system reliability due to its rich communication interfaces,robust and durable design,and flexible functional expandability.

XV-440-10TVB-1-20 EATON

technical specifications

Product model:XV-440-10TVB-1-20

manufacturer:EATON

Product type:Touch panel(HMI),can be upgraded to PLC

Display size:10.4 inches

Display type:TFT color LCD

Resolution:VGA(640 x 480 pixels)

Touch Technology:Infrared Touch

Power supply voltage:24 V DC(-15/+20%)

Communication interface:Ethernet(100Base TX/10Base-T),RS232,CAN,USB Host,USB Device

Front panel protection level:IP65

Rear protection level:IP20

Working temperature:0°C to+50°C

Dimensions(W x H x D):270 mm x 206 mm x 93 mm(Equipment)

Main features and advantages

The EATON XV-440-10TVB-1-20 touch panel brings significant advantages to industrial automation applications with its outstanding performance and comprehensive functionality.Its high-resolution 10.4-inch TFT color display screen,combined with infrared touch technology,can provide a clear and intuitive operating experience and reliable touch response even in harsh industrial environments.EATON XV-440-10TVB-1-20 has rich communication interfaces,including high-speed Ethernet,RS232,CAN,USB Host and Device interfaces,which can easily connect various PLCs,drivers and other automation devices,achieving seamless data exchange and system integration.

Flexible Function Expansion:One prominent feature of EATON XV-440-10TVB-1-20 is its upgradable PLC functionality.By purchasing the corresponding software license,users can upgrade the HMI device to a fully functional PLC,thereby achieving dual functions of visualization and control on a hardware platform,reducing system complexity and cost,and reducing the required installation space.Reliable and durable:The front panel of EATON XV-440-10TVB-1-20 has a protection level of up to IP65,which can effectively resist dust and water splashes,задняячастьимеетстепеньзащитыIP20，Ensure stable operation in harsh industrial environments.The wide width(24 V DC-15/+20%)further enhances its adaptability.The compact structural design and convenient panel installation simplify the system integration process.

XV-440-10TVB-1-20 EATON

application area

The EATON XV-440-10TVB-1-20 touch panel is widely used in various industrial automation fields due to its powerful functionality and reliable performance

Machine manufacturing:As a tool for various automated mechanical equipment,it is used for parameter setting,process monitoring,and fault diagnosis.

Packaging industry:Applied to the control and monitoring of packaging machinery,achieving visual management of production lines.

Food and beverage industry:used to control mixing,filling,and packaging processes on food processing and beverage production lines.

Pharmaceutical industry:used to monitor key parameters and control production processes in the pharmaceutical production process,meeting strict industry standards.

Material handling system:used to control and monitor automated warehousing and logistics equipment such as conveyor belts and stackers.

Building automation:applied to centralized monitoring and management of HVAC,lighting,and security systems.

Related products

The products related to EATON XV-440-10TVB-1-20 touch panel include:

Other models of EATON XV400 series:This series offers touch panels with different sizes,display characteristics,and interface configurations,such as XV-440-12TSB-1-10(12.1-inch touch screen),XV-442-57CQB-1-10(5.7-inch compact touch screen),etc.,to meet different application needs.

EATON XC series PLC:EATON’s high-performance programmable logic controller can be used in conjunction with XV-440-10TVB-1-20 to build powerful automation control systems.

EATON EasyE4 series PLC:Suitable for small automation tasks,it can be used as the control backend for XV-440-10TVB-1-20.

EATON GALILEO visualization software:used to create and edit application program interfaces for XV-440-10TVB-1-20 and other EATON HMI devices.

EATON CODESYS programming software:used for program development on XV-440-10TVB-1-20(when upgraded to PLC)and EATON PLC.

EATON Communication Module:Used to expand the communication capabilities of XV-440-10TVB-1-20,such as adding industrial network interfaces such as PROFIBUS DP and PROFINET.

Preparation before installation:Before installing the EATON XV-440-10TVB-1-20 touch panel,please carefully read the product manual and installation guide provided by EATON.Confirm that the installation environment meets the working temperature and humidity requirements of the panel.Prepare power and signal cables that meet the specifications.According to the installation dimensions of the panel,drill holes on the control cabinet or control panel.Check if the appearance of XV-440-10TVB-1-20 is intact and there is no physical damage.Ensure that there is sufficient space around the installation location for wiring and heat dissipation.Before making any electrical connections,be sure to disconnect the power supply.Connect the power supply,communication cable,and grounding wire correctly according to the wiring diagram.Use appropriate fasteners to securely install EATON XV-440-10TVB-1-20 onto the panel.

Maintenance suggestion:To ensure the long-term stable operation of the EATON XV-440-10TVB-1-20 touch panel,it is recommended to perform regular maintenance.Keep the surface of the panel clean and useмягкуюбезворсовуютканьдляудаленияпылизагрязненийAvoid using corrosive cleaning agents.Regularly check whether the connections of power and signal cables are loose or damaged.Ensure good ventilation of the control cabinet and avoid panels working in high temperature environments for extended periods of time.If EATON XV-440-10TVB-1-20 needs to upgrade its PLC functionality,please follow EATON’s guidelines for software licensing and programming.If any abnormal panel operation is found,such as unresponsive touch or display failure,please contact EATON technical support for maintenance in a timely manner.Do not disassemble or repair it yourself.

XV-440-10TVB-1-20 EATON

Product Guarantee

EATON provides comprehensive quality assurance for its XV-440-10TVB-1-20 touch panel.All EATON XV-440-10TVB-1-20 products undergo strict testing and quality control before leaving the factory to ensure their performance and reliability meet industry standards.
