Description

REXROTH VT-MVTW-1-16 D is a high-performance direct acting proportional directional valve belonging to Bosch Rexroth’s proportional valve product line.REXROTH VT-MVTW-1-16 D is designed for hydraulic systems that require precise flow and direction control,especially for applications that require high dynamic response and control accuracy.As a key executing component in automation systems,REXROTH VT-MVTW-1-16D can control the flow direction and flow rate of hydraulic oil proportionally based on the magnitude of electrical signals,thereby achieving precise control of the speed and position of hydraulic cylinders or motors.Its compact structure and reliable performance make REXROTH VT-MVTW-1-16 D perform well in various industrial applications and a key component for achieving precise hydraulic control.

The REXROTH VT-MVTW-1-16 D proportional directional valve is typically used in conjunction with a proportional amplifier or valve integrated electronic device to receive control signals and drive valve spool movement.Its direct acting design ensures fast response time and good dynamic characteristics.REXROTH VT-MVTW-1-16 D has multiple optional functions,such as different valve core functions,electrical connection methods,and manual emergency operations,which can flexibly adapt to different application needs.REXROTH VT-MVTW-1-16 D plays an important role in the field of modern industrial automation due to its precise control performance,reliable operation,and wide applicability.

VT-MVTW-1-16 D REXRTOH

technical specifications

Product model:VT-MVTW-1-16 D

manufacturer:REXROTH(Bosch Rexroth)

Product type:Direct acting proportional directional valve

Specification size:10(compliant with ISO 4401-05-04-0-05)

Maximum working pressure:350 bar

Maximum flow rate:160 l/min(DC power supply)

Electrical connection:Multiple options available(e.g.:DIN EN 17520-804)

Supply voltage:24 VDC(typical value)

Protection level:up to IP65(depending on the electrical connection method)

Installation method:Installation of oil circuit board

Main features and advantages

Accurate proportional control:REXROTH VT-MVTW-1-16 D can accurately control the flow direction and flow rate of hydraulic oil based on the input electrical signal size,achieving precise control of hydraulic actuator speed and position.

Fast dynamic response:REXROTH VT-MVTW-1-16 D adopts a direct acting design,ensuring the fast response of the valve core,thereby improving the dynamic performance and control accuracy of the entire hydraulic system.

Multiple optional functions:REXROTH VT-MVTW-1-16 D provides multiple optional valve core functions,electrical connection methods,and manual emergency operation functions,which can flexibly adapt to different application needs.

Reliable industrial grade design:REXROTH VT-MVTW-1-16 D is designed specifically for industrial applications,with excellent resistance to vibration and impact,and can operate stably and reliably in harsh industrial environments.

Compact structure:REXROTH VT-MVTW-1-16 D adopts a compact structural design,which is easy to integrate into various hydraulic systems and saves installation space.

VT-MVTW-1-16 D REXRTOH

application area

REXROTH VT-MVTW-1-16 D proportional directional valve is widely used in various industrial fields that require precise hydraulic control:

Metal forming machine tool:used to control the hydraulic cylinder movement of equipment such as presses and bending machines,achieving precise machining and forming.

Plastic Machinery:A servo hydraulic system used in injection molding machines,blow molding machines,and other equipment to achieve precise mold control and product molding.

Printing machinery:used to control the pressure and position of printing rollers to ensure high-quality printing results.

Woodworking machinery:applied to CNC woodworking equipment to achieve precise cutting,carving,and feeding control.

Testing equipment:used for various hydraulic testing benches,providing precise force,displacement,and speed control.

Material handling equipment:such as cranes,forklifts,etc.,to achieve precise load control and motion control.

Related products

REXROTH WE series directional valve:Similar to REXROTH VT-MVTW-1-16 D,but an electromagnetic directional valve used for simple directional control.

REXROTH 4WRPEH series proportional valve:with higher performance and integrated electronic devices,suitable for more complex closed-loop control applications.

REXROTH VT-VET series proportional valve amplifier:Used in conjunction with REXROTH VT-MVTW-1-16 D,it provides drive signals and control functions.

REXROTH hydraulic pump:provides power source for hydraulic systems containing REXROTH VT-MVTW-1-16 D.

REXROTH hydraulic cylinder and hydraulic motor:As the actuator of the hydraulic system,controlled by REXROTH VT-MVTW-1-16 D.

VT-MVTW-1-16 D REXRTOH

Preparation before installation:Before installing the REXROTH VT-MVTW-1-16 D proportional directional valve,please carefully read its product manual and relevant hydraulic system drawings to understand the specific installation requirements and safety precautions.Ensure that the cleanliness of the hydraulic system meets the requirements and prevent contaminants from entering the valve body and affecting its performance.Select appropriate cables and connectors according to the electrical connection method,and correctly connect the power and control signal lines according to the wiring diagram.Install REXROTH VT-MVTW-1-16 D onto the oil circuit board that complies with ISO 4401-05-04-0-05 standard and tighten it with suitable bolts.

Maintenance suggestion:To ensure the long-term stable operation of the REXROTH VT-MVTW-1-16 D proportional directional valve,it is recommended to regularly check the quality and cleanliness of the hydraulic oil,and replace the oil according to the maintenance plan of the hydraulic system.Regularly check whether the connecting bolts of the valve body are loose and whether the electrical connections are reliable.Avoid mechanical impact and vibration on the valve body.Follow the maintenance guidelines in the product manual for operation.It is recommended that trained professionals troubleshoot and repair valves.
