Description

The IC693DNM200-BD single slot DeviceNet main module from GE is an important communication interface module in its Series 90-30 PLC(Programmable Logic Controller)series.As the master controller of DeviceNet network,GE IC693DNM200-BD module can achieve high-speed and reliable data communication between Series 90-30 PLC system and slave devices(such as sensors,actuators,other controllers,etc.)that comply with DeviceNet protocol.The IC693DNM200-BD module adopts a single slot design,which is easy to integrate into the Series 90-30 PLC motherboard and provides necessary hardware and software interfaces,enabling the PLC to configure,manage,and monitor all nodes on the DeviceNet network.Through the IC693DNM200-BD module,users can build distributed and efficient industrial automation systems to achieve real-time control and data collection of on-site equipment.In industrial applications that require connecting a large number of on-site I/O devices,drivers,and other automation components,the GE IC693DNM200-BD DeviceNet main module is a critical communication bridge.

IC693DNM200-BD GE

technical specifications

Product model:IC693DNM200-BD

Manufacturer:GE/GE Fanuc

Product type:Single slot DeviceNet main module

Belonging series:Series 90-30

Supports DeviceNet specification:version 2.0

Baud rates:125 Kbps,250 Kbps,500 Kbps(configurable)

Maximum number of nodes:63(including the main station)

Scanning mode:Polled I/O,Change-of-State/Cyclic

I/O connection:Explicit Messaging,Polled I/O,Change-of-State/Cyclic I/O

Configuration tools:Logicmaster 90,VersaPro,Proficy Machine Edition(now PAC Machine Edition)

PLC motherboard slot requirements:single standard Series 90-30 I/O slot

Power requirement:5 VDC bus power supply

Connector type:5-pin open style(Phoenix Contact)

indicator light:Module Status(MS),Network Status(NS)

Working temperature:0°C to 60°C(32°F to 140°F)

Storage temperature:-40°C to 85°C(-40°F to 185°F)

Main features and advantages

The GE IC693DNM200-BD single slot DeviceNet main module provides powerful DeviceNet communication capabilities for Series 90-30 PLC systems,with the following significant features and advantages:

Efficient DeviceNet master function:As the master of the DeviceNet network,IC693DNM200-BD can effectively manage and control multiple slave devices on the network,achieving reliable data exchange and real-time device monitoring.

Supports multiple baud rates:configurable baud rates of 125 Kbps,250 Kbps,and 500 Kbps allow users to choose the appropriate communication rate based on the size and performance requirements of the network.

Flexible scanning modes:Supports multiple scanning modes such as Polled I/O and Change of State/Cyclic,optimizing data transmission efficiency and adapting to different application scenarios.

Multiple I/O connection methods:Supports various connection methods such as Explicit Messaging,Polled I/O,and Change of State/Cyclic I/O,providing a flexible data exchange mechanism.

Easy to integrate and configure:The single slot design facilitates module installation and allows for simple and intuitive network configuration and management through GE programming software.

Powerful network diagnostic capability:The onboard LED indicator lights can provide real-time feedback on module and network status,making it convenient for users to diagnose and maintain faults.

Mature and reliable platform:As a member of the Series 90-30 series,IC693DNM200-BD is built on a mature and reliable hardware platform with a wide range of application foundations.

IC693DNM200-BD GE

application area

The GE IC693DNM200-BD single slot DeviceNet main module is widely used in the industrial automation field that requires connecting a large number of on-site I/O devices and automation components,such as:

Automotive manufacturing:used to connect and control body welding robots,spraying equipment,sensors and actuators on conveyor lines.

Material handling:applied to automated warehouses,sorting systems,and conveyor belt control,connecting photoelectric sensors,barcode scanners,and drivers.

Packaging machinery:used to connect and control sensors,cylinders,and motor drivers on packaging machines.

Food and beverage:Applied to production line automation,connecting various sensors,valves,and actuators.

Other discrete manufacturing industries:Any application scenario that requires distributed I/O control and device interconnection can use IC693DNM200-BD to build an efficient control network.

Related products

The products related to the IC693DNM200-BD single slot DeviceNet main module include GE Series 90-30 series CPU modules(such as IC693CPU350 or IC693CPU374),as well as various DeviceNet slave devices,such as:

I/O module:A digital and analog I/O module that complies with the DeviceNet protocol.

Sensors:photoelectric sensors,proximity switches,pressure sensors,etc.that support DeviceNet communication.

Executor:Valves,cylinders,motor drivers,etc.that support DeviceNet communication.

Other controllers:Can serve as PLCs or other automation controllers for DeviceNet slave stations.

DeviceNet network components:cables,connectors,T-joints,terminal resistors,etc.

Users need to use GE programming software such as Logicmaster 90,VersaPro,or Proficy Machine Edition to configure the IC693DNM200-BD module and DeviceNet network.

IC693DNM200-BD GE

Installation and maintenance

Preparation before installation:Before installing the IC693DNM200-BD single slot DeviceNet main module,please carefully read the relevant product manual and installation guide to ensure that the installation environment meets the working temperature,humidity,and electromagnetic compatibility requirements of the module.Check if the packaging of the module is intact and confirm that the model is consistent with the order.Prepare the necessary installation tools,such as screwdrivers,etc.Ensure that the PLC motherboard is correctly installed and powered.Carefully inspect the connectors on the back of the IC693DNM200-BD module to ensure they are clean and free from physical damage.According to the product manual,insert the IC693DNM200-BD module correctly into the idle I/O slot of the PLC motherboard and secure it firmly.When connecting DeviceNet network cables,it is necessary to use cables and connectors that comply with the DeviceNet specifications,and connect them according to the wiring rules of DeviceNet to ensure the correct connection of the main and branch lines,as well as the correct installation of terminal resistors.

Maintenance suggestion:In order to ensure the long-term stable operation of the IC693DNM200-BD single slot DeviceNet main module,regular maintenance is recommended.Regularly check whether the connections of the module in the motherboard are loose,whether the DeviceNet network cables and connectors are connected reliably,and whether there is any damage.Keep the modules and control cabinets clean to prevent dust and foreign objects from entering the interior of the modules,which can affect electrical performance and heat dissipation.Regularly check the LED indicator status on the module,monitor the working status of the module and network.GE programming software can be used for diagnosis and troubleshooting of DeviceNet networks.
