Description

WINGREEN 034STM4-00-200-RS High Performance Industrial Control Module(PUIM V2.0)is an advanced control and monitoring component designed by WINGREEN specifically for automation systems in harsh industrial environments.As part of the PUIM V2.0 series of WINGREEN 034STM4-00-200-RS,this module has powerful real-time process control and monitoring capabilities,and can be seamlessly integrated into existing industrial infrastructure,significantly improving operational efficiency.The WINGREEN 034STM4-00-200-RS module is designed for applications that require stable and reliable data transmission,supporting RS-485 communication protocol to ensure efficient data exchange between devices.Its sturdy and durable design,as well as a wide operating temperature range,enable WINGREEN 034STM4-00-200-RS to operate stably in various demanding industrial scenarios,making it an ideal choice for building high reliability automation systems.

034STM4-00-200-RS WINGREEN

technical specifications

Product model:034STM4-00-200-RS

Manufacturer:WINGGREEN

Product type:High performance industrial control module

Series/Sub model:PUIM V2.0

Communication protocol:RS-485

Data transmission rate:200 kbps

Power supply voltage:12-24V DC

Working temperature:-20°C to+70°C

Storage temperature:-40°C to+85°C

Humidity range:5%to 95%(non condensing)

Main features and advantages

The WINGGREEN 034STM4-00-200-RS high-performance industrial control module has the following significant features and advantages,making it stand out in the field of industrial automation:

Excellent performance and reliability:WINGREEN 034STM4-00-200-RS is designed to achieve stable and reliable real-time process control and monitoring in harsh industrial environments,ensuring the continuous and efficient operation of the system.

Powerful communication capability:Supports standard RS-485 communication protocol,WINGGREEN 034STM4-00-200-RS can achieve efficient and stable data transmission between devices,making it easy to build complex distributed control systems.

Wide environmental adaptability:WINGREEN 034STM4-00-200-RS has a wide operating voltage range and temperature tolerance,enabling it to adapt to various industrial application scenarios.

Durable industrial grade design:The module adopts a sturdy housing with good dust and moisture resistance,ensuring that WINGREEN 034STM4-00-200-RS can operate stably for a long time even in harsh industrial environments.

Compact size,convenient installation:The WINGREEN 034STM4-00-200-RS module is designed to be compact and lightweight,making it easy to install in space constrained environments.The clearly labeled connectors and intuitive layout simplify the installation process.

Comprehensive technical support and assurance:WINGREEN provides comprehensive technical documentation for 034STM4-00-200-RS,including detailed wiring diagrams and setup instructions,as well as comprehensive warranty and customer support services.

034STM4-00-200-RS WINGREEN

application area

WINGREEN 034STM4-00-200-RS high-performance industrial control module,with its excellent performance and reliability,can be widely used in various industrial fields that require real-time process control and monitoring,including:

Manufacturing industry:suitable for automated production lines,robot control,equipment monitoring,etc.,to improve production efficiency and product quality.

Process control:applied in industries such as chemical,petroleum,and pharmaceutical to achieve precise control and monitoring of key parameters such as temperature,pressure,and flow rate.

Data collection system:used to collect data from various industrial sites,providing a basis for production optimization and decision-making.

Environmental monitoring:can be applied to parameter monitoring and control in harsh industrial environments.

Other automation applications that require robust control and stable communication.

Related products

Based on the product line information of WINGGREEN,products that may be related to WINGGREEN 034STM4-00-200-RS high-performance industrial control module include:

WINGGREEN 03ZSTI4-00-501(ATKB_V5.0_S01):It may be a communication module or analog input card used to expand the system’s input and output capabilities.

WINGREEN 03ZSTI7-00-402-RS(DSPB_V4.0_A02)：Digital signal processing board,used for more complex signal processing and control algorithm calculations.

WINGREEN 03ZSTJ1-00-301-RS(FPB_V3.0_S01):A power supply board that provides stable and reliable power to the system.

WINGGREEN 03ZSTL6-00-201-RS(IPB PCB V2.0_A01):may be an interface or function expansion board used to implement specific functions of the system.

WINGREEN 03ZSTJ3-00-105(FAN_DETECTION V1.0_A05)：Fan detection module,used to monitor the status of the system’s cooling fan and improve system reliability.

These modules and boards together form the complete industrial automation solution of WINGREEN.WINGREEN 034STM4-00-200-RS,as the high-performance control core,can work together with other modules to meet various complex industrial automation needs

Installation and maintenance

Preparation before installation:Before installing the WINGREEN 034STM4-00-200-RS high-performance industrial control module,please carefully read its official product manual to ensure understanding of the correct installation steps and safety precautions.Confirm that the power supply voltage is consistent with the requirements of the module,and prepare power and communication cables that meet the specifications.Install 034STM4-00-200-RS in a well ventilated,dust-free,and dry environment,avoiding extreme temperatures and humidity.Ensure the installation position is stable and avoid vibration and impact.Before making any electrical connections,be sure to disconnect the power supply to ensure safe operation.Connect the power and communication lines correctly according to the wiring diagram in the manual.

Maintenance suggestion:In order to ensure the long-term stable operation of the WINGREEN 034STM4-00-200-RS high-performance industrial control module,it is recommended to conduct regular preventive maintenance.Regularly check the connection cables of the module for looseness or aging to ensure the reliability of electrical connections.Keep the surface of the module clean and avoid dust accumulation that affects heat dissipation.Regularly check the working status of the module,such as whether the indicator lights are normal,whether there is abnormal heating or noise.Avoid operating in environments that exceed the operating temperature and humidity range of the module.If any abnormal situation is found,the machine should be stopped for inspection in a timely manner and professional technical personnel should be contacted for handling.

034STM4-00-200-RS WINGREEN

Product Guarantee

WINGGREEN provides comprehensive quality assurance for the 034STM4-00-200-RS high-performance industrial control module.
