Description

This Telkoor CPCIAC-6U-500 900-7002-10 is not an ordinary power supply that you can easily find on the market. It is a high reliability AC power module designed by Telkoor specifically for the CompactPCI (CPCI) industry standard. Think about it, in industrial control, telecommunications, military or embedded systems that require extremely high power supply stability, the power supply is the “heart” of the entire system. If the heart is not good, everything is useless! The core function of Telkoor CPCIAC-6U-500 900-7002-10 is to convert unstable AC mains power into stable DC voltage required by the system, providing continuous power for various control boards and I/O modules in the CompactPCI chassis.

This Telkoor CPCIAC-6U-500 900-7002-10 is not a vegetarian. It strictly follows the CompactPCI specification and adopts a standard 6U size design. It can be directly plugged into the CompactPCI backplane, making installation and maintenance extremely convenient. In automation systems, it is usually used as the core power unit to supply power to key components such as high-performance controllers, data acquisition cards, and communication modules. Its value lies in ensuring that the entire system can operate stably even in harsh industrial environments, minimizing the risk of downtime caused by power fluctuations or failures. It can be said that by choosing Telkoor CPCIAC-6U-500 900-7002-10, you have injected a “heart stimulant” into your industrial system, making it full of power and worry free to operate!

Telkoor CPCIAC-6U-500 900-7002-10

Telkoor CPCIAC-6U-500 900-7002-10 Technical Specifications

Parameter Name Parameter Value

Product model Telkoor CPCIAC-6U-500 900-7002-10

Manufacturer Telkoor

Product type: CompactPCI AC power module

Architecture 6U CompactPCI

Input voltage 85-264 VAC (wide range AC input)

Input frequency 47-63 Hz (wide frequency range)

Output power 500 W

Output voltage+5V,+3.3V,+12V, -12V (multiple output, revised according to model)

Active Power Factor Correction (PFC)

Working temperature -40 ° C to+70 ° C (wide temperature range)

Typical efficiency>85%

Protection level IP20 (usually)

Size 6U CompactPCI (approximately 233.35mm x 160mm)

MTBF > 300, 000 hours

Cooling method: forced air cooling or conduction cooling (depending on the version)

Features: Hot swappable support, overvoltage/overcurrent/short circuit/over temperature protection

Main features and advantages

The Telkoor CPCIAC-6U-500 900-7002-10 power module can firmly establish itself in the industrial and military fields, relying on absolute hard power! Firstly, its biggest highlight is its excellent power stability. In industrial sites, fluctuations in the power grid are commonplace, with voltage fluctuating between high and low levels, which can knock down ordinary power sources in minutes. But Telkoor CPCIAC-6U-500 900-7002-10, with its wide range AC input and advanced voltage stabilization technology, can ensure stable and pure DC power output under various harsh grid conditions, providing the most reliable “blood” for your CompactPCI system. It’s like putting a layer of “Golden Bell Cover Iron Cloth Shirt” on your device, no matter how big the power grid fluctuations are, they can’t hurt it at all.

Secondly, its high reliability and robustness attributes are beyond words! Telkoo, as a company with extensive experience in the military industry, is known for its strict standards in product design and manufacturing. This Telkoor CPCIAC-6U-500 900-7002-10 not only has a Wide Operating Temperature Range and can operate stably in extreme environments ranging from minus 40 degrees Celsius to over 70 degrees Celsius, but also has a comprehensive protection mechanism, such as overvoltage protection, overcurrent protection, short circuit protection, and overtemperature protection, to comprehensively safeguard your system security. Think about it, in some industrial sites with high vibration, dust, and large temperature differences, this power supply can still work without any changes, which itself is a proof of its strength!

Furthermore, Telkoor CPCIAC-6U-500 900-7002-10 also supports hot swap functionality, which is extremely important in CompactPCI systems! This means that if the power module needs to be replaced or upgraded, you don’t need to shut down the entire system at all, just plug and unplug it online. This is a lifesaver for critical production lines that do not allow for prolonged downtime, greatly improving the maintainability and availability of the system. In summary, the Telkoor CPCIAC-6U-500 900-7002-10 is not just a power source, but also a solid guarantee for the stable operation of your industrial system, a trustworthy “industrial heart”.

The Telkoor CPCIAC-6U-500 900-7002-10 power supply module is a testament to Telkoor’s engineering prowess, specifically designed for mission-critical CompactPCI (CPCI) industrial applications. Its primary advantage lies in its exceptional power conditioning and regulation capabilities. Operating across a wide input voltage range (85-264 VAC), this module ensures a stable and clean DC power output, effectively shielding sensitive electronic components within the CPCI system from grid fluctuations and disturbances. This robust power delivery is vital for maintaining the integrity and continuous operation of high-performance industrial controllers and data acquisition systems in environments prone to unreliable power sources.

Furthermore, the Telkoor CPCIAC-6U-500 900-7002-10 is built to endure the harshest industrial conditions, reflecting Telkoor’s background in military-grade solutions. It boasts an extended operating temperature range, performing reliably from -40 °C to +70° C, and is equipped with comprehensive protection features including overvoltage, overcurrent, short circuit, and overtemperature safeguards. These integrated protections enhance system resilience and longevity by preventing damage from electrical anomalies. A significant feature for industrial settings is its hot-swap capability, which allows for the replacement or upgrade of the power module without interrupting the operation of the entire CompactPCI system. This minimizes costly downtime and maximizes system availability, offering a compelling advantage for critical manufacturing and process control applications. The Telkoor CPCIAC-6U-500 900-7002-10 truly embodies reliability, durability, and operational flexibility,  making it an indispensable component for demanding industrial environments.

application area

The Telkoor CPCIAC-6U-500 900-7002-10 power module is not limited to a small corner, but is widely used in industries that have high requirements for power quality and system reliability. Firstly, in industrial automation control systems, it is the lifeline of many high-performance CompactPCI controllers and embedded PCs. Whether it’s complex robot control, high-speed data acquisition, or critical decision-making units in factory process automation, stable and reliable power sources like Telkoor CPCIAC-6U-500 900-7002-10 are needed to ensure their continuous operation and prevent production line shutdowns or data loss due to power outages.

Secondly, in the field of telecommunications and communication, especially in core infrastructure such as base stations, network switching equipment, and industrial routers, Telkoor CPCIAC-6U-500 900-7002-10 also plays a crucial role. These devices require uninterrupted operation around the clock, and any power failure could result in widespread communication interruption, with unimaginable consequences. Telkoo’s power supply, with its high MTBF (mean time between failures) and strong environmental adaptability, ensures the stability and smoothness of the communication network.

Furthermore, in extremely harsh environments such as military and aerospace, you can also see the presence of Telkoor CPCIAC-6U-500 900-7002-10. These environments have reached the extreme requirements for the anti vibration, shock resistance, and wide temperature working ability of the equipment, which ordinary power supplies are simply unable to handle. Telkoor, with its military grade design and manufacturing standards, enables this power supply to easily cope with the challenges of harsh environments, providing solid power support for airborne equipment, radar systems, ground control stations, and more. In short, as long as it is an application scenario with almost stringent requirements for power reliability and stability, Telkoor CPCIAC-6U-500 900-7002-10 can become your “best partner”!

Related products

The products related to the Telkoor CPCIAC-6U-500 900-7002-10 CompactPCI power module are mainly focused on Telkoor’s CompactPCI power series and CompactPCI chassis/backplane. They are usually used together to form a complete CompactPCI power supply solution.

Telkoor CPCIDC-6U-400: This is another common 6U CompactPCI power module from Telkoor, typically in the DC input version. The main difference from Telkoor CPCIDC-6U-500 900-7002-10 is the input power type (DC vs AC) and output power, which may vary.

Telkoor CPCIAC-3U-300: This is a 3U sized CompactPCI AC power module with relatively low power, suitable for applications that require more compact space. Compared with Telkoor CPCIAC-6U-500 900-7002-10, there are differences in size and power.

Telkoor PSMU-350-3: Sometimes in the second-hand market or specific system configurations, Telkoor CPCIAC-6U-500 900-7002-10 may appear with this model, which may be a sub series or a power management unit with specific redundancy functions.

CompactPCI Backplane (e.g. Telkoo Backplane): A CompactPCI backplane with various slots, serving as the installation carrier for Telkoo CPCIAC-6U-500 900-7002-10, providing power and data connections for modules.

CompactPCI chassis (e.g. Telkoor Chassis): Provides physical protection and heat dissipation environment, and Telkoor CPCIAC-6U-500 900-7002-10 is typically installed in such a chassis.

Various CompactPCI CPU cards, I/O cards, and communication cards: These are the actual power supply objects of Telkoor CPCIAC-6U-500 900-7002-10, and are the functional modules of the entire CompactPCI system.

Telkoor CPCIAC-6U-500 900-7002-10

Installation and maintenance

Preparation before installation: Before installing Telkoor CPCIAC-6U-500 900-7002-10, you need to confirm that the CompactPCI chassis and backplane have been correctly installed, and that there are no foreign objects or damage inside the chassis, ensuring that the physical environment meets the requirements. The input voltage of the power module must match the voltage of the AC power grid on your site. Don’t make any mistakes. Inserting a 220V power supply into a 110V machine may result in insufficient voltage, and in turn, it may directly burn out. It is necessary to ensure that the specifications and interfaces of all connecting cables are correct and error free, especially the grounding connection of the AC input line must be secure, which is related to the safety of the system and personnel. Also, electrostatic protection is of utmost importance. Wear anti-static clothing and wristbands to prevent static electricity from penetrating the internal circuit of Telkoor CPCIAC-6U-500 900-7002-10. Finally, ensure that there is sufficient heat dissipation space inside the chassis and do not block the heat dissipation holes. Although this module is durable, a good heat dissipation environment can greatly extend its lifespan.

Maintenance suggestion: Industrial grade power supplies such as Telkoor CPCIAC-6U-500 900-7002-10 have relatively simple daily maintenance, but key points cannot be taken lightly. Firstly, regularly check the indicator lights of the power module. If there are any abnormal colors or flashing patterns, it indicates that there is a problem and you need to consult the manual or contact the manufacturer as soon as possible. It is necessary to keep the power module and its surrounding environment clean, especially the cooling fan (if any) and cooling holes. Dust accumulation can seriously affect the cooling efficiency, causing the module to overheat and shorten its lifespan. You can use a soft brush or vacuum cleaner to gently remove dust. At the same time, regularly check all cable connections for firmness, signs of looseness, wear, or corrosion, especially the AC input terminals, to ensure good contact and avoid false connections that may cause heating or even fire. Although Telkoor CPCIAC-6U-500 900-7002-10 has a long design life, if the system experiences instability or alarms, the power module is usually one of the priority targets for troubleshooting. Early detection and resolution of problems can avoid greater losses.
