Description

GE SLN080 (IC086SLN080-A) is a high-performance 8-channel analog output module belonging to the GE RSTi-EP distributed remote I/O series. This module is designed specifically for automation systems that require precise analog control signal output, and is widely used in process control, DCS systems, remote stations, SCADA, and PLC system integration.

GE SLN080 IC086SLN080-A

?  Product Details

✅  Module model analysis

SLN080: Refers to an 8-channel analog output (AO) module

IC086SLN080-A: GE official material code, commonly used for ordering, selection, and after-sales identification.

The most common application of this type of module is to control analog devices such as frequency converters, regulating valves, and actuators on site, providing a standard analog signal output of 020mA.

?  Technical specifications and specifications

Module model: SLN080/IC086SLN080-A

Series platform: GE PACSystems RSTi EP

Number of channels: 8 channels (independently isolated)

Output type: 020mA configurable

Resolution: 16 bit DAC

Accuracy: ± 0.1% of full scale

Channel isolation: Channel and bus isolation, 500VDC

Between channels: non isolated (shared common end)

Working voltage: 24VDC (± 20%) power supply

Power consumption: approximately 3.5W

Working temperature range: -20 ℃~+60 ℃

Installation method: DIN rail (35mm)

Communication method: Connect to PLC or DCS through the main station module (such as PROFINET or EtherCAT)

Configuration method: via GE PAC Machine Edition software

Size: Extremely compact (width<15mm>

Certification standards: CE, UL, RoHS, ATEX (some batches)

?️  Module features and advantages

?  8-channel independent analog output

One board outputs 8 analog signals, suitable for multi-point control requirements and improving system control density.

?  Voltage/current free switching

Each channel supports 020mA output, with software configuration and strong adaptability.

?  High precision 16 bit output

High resolution DAC ensures output accuracy and meets the requirements of process control systems.

?  Compact structure, space saving

The RSTi EP series module is most suitable for control cabinets, with an ultra-thin design that saves wiring and installation space.

?  Unrelated to the main station protocol, modules are uniformly connected

Combine with GE’s PROFINET, Ethernet/IP, Modbus TCP and other master station modules to build flexible remote I/O sites.

?  Support hot plugging and flexible configuration

Replace modules during runtime without power outage, improving maintenance efficiency; The configuration mode can be automatically recognized and debugged conveniently.

?  Typical application scenarios

Industrial process control (PID control loop output)

Precision speed control (frequency converter/servo control signal output)

Water treatment system (valve simulation control)

SCADA system remote I/O station

Large industrial sites such as petrochemicals, metallurgy, electricity, and papermaking

OEM equipment manufacturers customize control systems

?  Recommended Related Modules

IC086SLI160: 16 channel digital input module

IC086SLO160: 16 channel digital output module

IC086SLI040: 4-channel high-density input module

IC086SLN040: 4-channel analog output module

IC086SLI080: 8-channel analog input module

IC086SLM240: 4-channel thermocouple/temperature input module

IC086SLP100: Power module (for the entire remote station)

?  Installation and maintenance suggestions

Please confirm the power supply, current load, and signal type connected to the module before installation

Distinguish between voltage/current circuits during output wiring to avoid signal short circuits and channel damage

Suggest using the Machine Edition software provided by GE to configure parameters

All RSTi EP modules are connected through a dedicated bus, with the main station on the left and expansion on the right in sequence. The installation order is specific

Please ensure tight connections between modules to prevent virtual connections from causing IO recognition errors
