The ABB REM615 HBMCAEAGNNA1BNN1X is a high-performance, multifunction motor protection and control relay from ABB’s Relion® 615 series, specifically engineered for the reliable operation and safeguarding of medium- and low-voltage motors in industrial and utility environments. The alphanumeric suffix HBMCAEAGNNA1BNN1X is ABB’s detailed order code that defines the unit’s exact hardware configuration, communication options, input/output modules, power supply, and regional certifications.
As part of ABB’s digital substation-ready portfolio, the REM615 integrates comprehensive motor protection (including thermal overload, phase imbalance, stall, and bearing protection), precise metering, programmable logic control, and full IEC 61850 compliance—including GOOSE messaging for fast interlocking and tripping. It supports SIL 2 safety integrity per IEC 61508, making it suitable for critical applications such as pump stations, compressors, conveyors, and HVAC systems where unplanned downtime carries significant operational or safety risk.
The HBMCAEAGNNA1BNN1X variant typically includes:
Standard 3-phase current inputs (1 A or 5 A)
Binary I/O for start/stop, trip, and alarm circuits
Dual Ethernet ports with IEC 61850 Ed. 2 support
24–250 VDC / 100–240 VAC universal power supply
Front-panel color graphical display (on newer firmware/hardware revisions)
Technical Specifications
| Parameter | Value |
|---|---|
| Model | REM615 HBMCAEAGNNA1BNN1X |
| Manufacturer | ABB Ltd. (Relion® Series) |
| Primary Function | Motor Protection & Control |
| Standards | IEC 61850 Ed. 2, IEC 61508 SIL 2, IEC 60255, IEEE C37.94 |
| Communication | IEC 61850 (MMS, GOOSE), Modbus TCP/RTU, DNP3, IEC 60870-5-103 |
| Current Inputs | 3-phase + ground (1 A or 5 A CTs, software-selectable) |
| Voltage Inputs | Optional (depends on config; this variant may exclude VTs) |
| Binary Inputs | Typically 8–10 (24 VDC, configurable) |
| Binary Outputs | Typically 6–8 (relay or solid-state, isolated) |
| Trip Time | <25> |
| Thermal Modeling | Built-in RTD or calculated (I²t) thermal replica |
| Display | Monochrome or color LCD (based on hardware revision) |
| Power Supply | 24–250 VDC / 100–240 VAC (dual-range, auto-sensing) |
| Operating Temp | -25°C to +70°C |
| Mounting | 19″ rack or panel mount (with adapter) |
| Certifications | CE, UL, cUL, KEMA, IEC 61850-3, IEEE 1613 |
Key Features & Advantages
✅ Comprehensive Motor Protection Suite
Includes thermal overload (with ambient compensation), phase reversal, undercurrent (dry-run detection), stall/jam, start-up supervision, and bearing protection via optional RTD inputs.
✅ IEC 61850 Native Architecture
Full support for GOOSE enables sub-4 ms peer-to-peer tripping—ideal for coordinating with upstream breakers or other REM615 units without hardwiring.
✅ Integrated Control & Automation Logic
Programmable logic (via PCM600 or Automation Builder) allows implementation of start/stop sequences, interlocks, and automatic restarts—reducing need for external PLCs.
✅ Advanced Diagnostics & Remote Access
Built-in web server (optional) provides real-time current waveforms, event logs, and phasor diagrams via standard browser. Supports secure remote troubleshooting.
✅ Seamless Replacement Capability
When replacing a failed HBMCAEAGNNA1BNN1X, the identical order code ensures plug-and-play compatibility—no re-engineering required if configuration backup exists.
Typical Applications
Oil & Gas: Protecting injection pumps, compressors, and flare gas recovery motors
Water/Wastewater: Safeguarding lift station and treatment plant centrifugal pumps
Mining: Controlling conveyor drives, crushers, and slurry pumps in harsh environments
Manufacturing: Ensuring uptime of extruders, mixers, and robotic actuator motors
Power Generation: Auxiliary motor protection in balance-of-plant systems
Related Products
PCM600: ABB’s engineering tool for configuration, testing, and firmware updates
REF615 / REL615 / RET615: Sister relays for feeder, line, and transformer applications
1MRK008615: Official product manual for REM615 series
ABB NS250 / NS500: Managed Ethernet switches optimized for IEC 61850
RET650: Secondary injection test set for validating REM615 functions
HBMCAEAGNNA1BNN1Y / …Z: Alternate variants with different I/O or comms options
Installation & Maintenance Guidance
? Pre-Installation Checklist:
Confirm exact order code match (HBMCAEAGNNA1BNN1X) to avoid I/O or firmware mismatches.
Back up existing relay configuration (.CID or .CFG file) using PCM600.
Verify CT polarity and ratio settings before energizing.
Ensure Ethernet network supports multicast (for GOOSE) if used.
?️ Maintenance Best Practices:
Perform annual functional tests using secondary injection.
Review thermal history and start counters to predict maintenance needs.
Monitor event logs for repeated phase imbalance or undercurrent alarms—early signs of mechanical wear.
Keep spare unit pre-loaded with site-specific configuration for<1>
