Description

The GE IC695CPU320-CF is a high-performance central processing unit (CPU) module designed for use in the GE Fanuc PACSystems RX3i family of programmable automation controllers. This CPU is ideal for complex industrial applications that require fast execution, high-speed I/O handling, and advanced communication capabilities.

It features an onboard CompactFlash (CF) slot, allowing users to store application logic, configuration files, and operating system images for faster startup and data retention without relying on battery-backed memory.

? Technical Specifications

• 1 x RS-232 Serial Port (P2)

• 2 x Ethernet Ports: 10/100 Mbps (RJ45), supports TCP/IP, SNMP, Modbus TCP/IP, SRTP | | I/O Capacity| Up to 512 register-based I/O modules across local and remote racks | | Program Execution Time | ~0.04 µs per instruction | | Real-Time Clock | Yes, with battery backup | | Mounting | Standard 19” rack mountable Eurocard (6U height) | | Power Requirements | Supplied via backplane from power supply module | | Operating Temperature | 0°C to 60°C | | Certifications | CE, UL, cUL, RoHS |

⚠️ The “CF” in IC695CPU320-CF denotes the presence of a CompactFlash socket, which allows for storage of OS, firmware, and user programs, eliminating the need for a battery-backed memory module.

✅ Key Features & Benefits

? High-Speed Processor

• Equipped with a 400 MHz PowerPC processor, delivering fast scan times and improved performance for complex control strategies.

• Supports floating-point math operations, essential for precision control in process applications.

? Onboard Storage with CompactFlash

• Built-in CompactFlash (CF) card slotfor:

• Storing PLC programs and configurations

• Firmware upgrades

• Data logging

• Eliminating reliance on internal batteries for memory retention

? Dual Ethernet Communication

• Two 10/100 Mbps Ethernet portswith support for:

• Modbus TCP/IP

• SNMP (Simple Network Management Protocol)

• SRTP (Serial Real-Time Protocol)

• Web services and OPC UA

• Enables redundant network topologiesand seamless integration into modern industrial networks.

? Advanced Communication Capabilities

• Built-in serial port (RS-232)for programming or connecting serial devices.

• Supports multiple fieldbus protocols through optional communication modules:

• Profibus DP

• CANopen

• DeviceNet

• Ethernet/IP

? Scalable I/O Architecture

• Compatible with RX3i’s extensive I/O library, including analog, digital, specialty, and motion modules.

• Supports distributed I/O systemsvia PROFINET, PROFIBUS, or Genius Bus.

?️ Flexible Programming Environment

• Programmed using Proficy Machine Edition (PME)software suite.

• Supports all IEC 61131-3 programming languages:

• Ladder Diagram (LD)

• Function Block Diagram (FBD)

• Structured Text (ST)

• Instruction List (IL)

• Sequential Function Chart (SFC)

? Robust Industrial Design

• Designed for reliable operation in harsh environments.

• Convection cooling ensures long life with no fan-related failures.

GE IC695CPU320-CF

? Application Fields

? Manufacturing & Assembly

• Used in automotive, packaging, material handling, and discrete manufacturing lines.

⚙️ Process Industries

• Applied in chemical, food & beverage, pharmaceutical, and water/wastewater treatment plants.

? Energy & Utilities

• Deployed in power generation facilities, substation automation, and renewable energy systems.

? Transportation Infrastructure

• Utilized in rail signaling, tunnel ventilation, and traffic control systems.
