The Triconex MA2211-100 is a critical Main Processor Module for Tricon CX Safety Instrumented Systems (SIS), engineered to execute SIL 3-certified safety logic in high-risk industrial processes. As the central processing unit of the Tricon v11 platform, this triple modular redundant (TMR) module synchronizes three independent 32-bit processors running identical safety applications with 2 ms resolution. The MA2211-100 performs continuous hardware/software diagnostics including memory parity checks, bus synchronization verification, and I/O communication validation to achieve >99.999% availability. Designed for extreme reliability in oil/gas, power generation, and chemical processing, it operates at -40°C to +70°C with Class 1 Div 2/ATEX Zone 2 certification. Its TMR architecture ensures fault-masking capability – continuing safe operation despite single or multiple failures while maintaining IEC 61508 compliance.
TRICONEX MA2211-100
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | MA2211-100 |
| Manufacturer | Triconex (Schneider Electric) |
| Product Type | TMR Safety Processor |
| Architecture | Triple Modular Redundant (TMR) |
| Processor | 3x 32-bit RISC (synchronized) |
| Memory | 2 MB SRAM (TMR protected) |
| Logic Execution | 2 ms resolution |
| Diagnostics Coverage | >99.9% (IEC 61508) |
| Safety Certification | SIL 3 (IEC 61508/61511), SC 3 (ISA S84.01) |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Communication Ports | 2x RS-232 (TriStation), 1x Ethernet (TCP/IP Modbus) |
| Backplane Speed | 12.5 Mbps (TMR bus) |
| Power Consumption | 8W @ 5V DC |
| MTBF | >100 years |
| Certifications | ATEX, IECEx, FM, CSA Class 1 Div 2 |
| Hot Swap Support | Yes |
Main Features and Advantages
Fault-Tolerant TMR Architecture: Three parallel processors execute identical logic with 2 ms synchronization. Two-of-three voting masks hardware/software faults without process interruption.
Advanced Diagnostics: Continuous monitoring includes:
Processor heartbeat verification
Memory checksum validation
I/O communication integrity
Power supply deviation detection
Automated fault isolation prevents error propagation.
Deterministic Performance: Guarantees<100>
Seamless Integration: Supports legacy Tricon v9/v10 applications via TriStation 1131. Ethernet port enables Modbus TCP connectivity with DCS/PLC.
Robust Environmental Design: Conformal-coated PCB withstands 95% humidity and corrosive atmospheres. Vibration resistant to 5g @ 10-500 Hz.
Application Field
The MA2211-100 protects critical processes:
Offshore Platforms: Emergency shutdown (ESD) for subsea wells and HIPPS
Refineries: Burner management (BMS) and flare control
Chemical Plants: Reactor overpressure protection and toxic gas detection
Power Generation: Turbine overspeed trips and boiler safety interlocks
Pharmaceutical: Sterilization vessel safety controls under GMP
TRICONEX MA2211-100
Related Products
MP3008: Communication module for Tricon CX
3700E: Analog input module (SIL 3)
3503E: Digital output module
Triconex Trident: Predecessor system upgrade path
TriStation 1131: Configuration software
Foxboro Evo™: Integrated process safety system
HIMA H51q: Comparable SIL 3 processor
Yokogawa ProSafe-RS: Alternative safety platform
Installation and Maintenance
Pre-installation preparation: Verify chassis grounding (<1>
Maintenance recommendations: Perform quarterly diagnostic log review. Replace every 10 years per lifecycle management. Update firmware during planned shutdowns. Test safety logic annually via simulated trips.
