WINGREEN 034STM4-00-200-RS Logic Control Unit – Optimize production efficiency and reduce operating costs!

The WINGREEN 034STM4-00-200-RS is a next-generation intelligent valve positioner designed for Industry 4.0 integration, combining HART 7, RS485/Modbus RTU, and wireless IoT connectivity (LoRaWAN/NB-IoT) in a single device. Engineered for critical process control, this positioner delivers ±0.15% accuracy in converting 4–20mA signals to precise pneumatic output (0.2–2.0 MPa) for globe, ball, and butterfly valves. Its embedded edge-computing capability processes valve diagnostics locally, reducing control system load while enabling predictive maintenance. The WINGREEN 034STM4-00-200-RS features an aluminum-stainless hybrid enclosure (IP69K) for extreme washdown/corrosive environments and achieves SIL 2 functional safety certification. As the cornerstone of WINGREEN’s STM4 series, it optimizes energy consumption by 25% through adaptive air-volume control and supports OPC UA for seamless IT/OT convergence.

Get a Quote
Manufacturer:
Our extensive catalogue, is available now for dispatch to the worldwide.
  • Email: sales@slxytech.com
  • WhatsApp / Wechat：8617062388866
  • Phone：+86 17062388866

Description

The WINGREEN 034STM4-00-200-RS is a next-generation intelligent valve positioner designed for Industry 4.0 integration, combining HART 7, RS485/Modbus RTU, and wireless IoT connectivity (LoRaWAN/NB-IoT) in a single device. Engineered for critical process control, this positioner delivers ±0.15% accuracy in converting 4–20mA signals to precise pneumatic output (0.2–2.0 MPa) for globe, ball, and butterfly valves. Its embedded edge-computing capability processes valve diagnostics locally, reducing control system load while enabling predictive maintenance. The WINGREEN 034STM4-00-200-RS features an aluminum-stainless hybrid enclosure (IP69K) for extreme washdown/corrosive environments and achieves SIL 2 functional safety certification. As the cornerstone of WINGREEN’s STM4 series, it optimizes energy consumption by 25% through adaptive air-volume control and supports OPC UA for seamless IT/OT convergence.

WINGREEN 034STM4-00-200-RS

WINGREEN 034STM4-00-200-RS

Technical Specifications

Parameter Name Parameter Value
Product Model 034STM4-00-200-RS
Manufacturer WINGREEN
Product Type IIoT Smart Valve Positioner
Input Signal 4–20mA + HART 7 + RS485/Modbus RTU
Wireless Protocols LoRaWAN, NB-IoT (optional)
Output Pressure 0.2–2.0 MPa (adjustable)
Accuracy ±0.15% full scale
Repeatability ±0.03%
Air Consumption 0.06 Nm³/h (steady state)
Supply Pressure 0.25–2.5 MPa
Response Time < 1>
Enclosure Rating IP69K (high-pressure/steam resistant)
Operating Temperature -40°C to +100°C (-40°F to +212°F)
Safety Certification SIL 2 (IEC 61511), TÜV certified
Cybersecurity IEC 62443-4-2, TLS 1.3 encryption
Edge Computing 800 MHz ARM Cortex-A53, 4GB local storage
Power Options 24V DC or 4–20mA loop-powered

Main Features and Advantages

Multi-Layer Connectivity: The WINGREEN 034STM4-00-200-RS uniquely integrates wired (HART/Modbus RTU) and wireless (LoRaWAN/NB-IoT) communications. This allows real-time valve performance monitoring via DCS/PLC while transmitting predictive analytics to cloud platforms like MindSphere or Azure IoT without additional gateways.

Advanced Diagnostics: Onboard edge processing runs machine learning algorithms to detect stiction, hysteresis, and seal degradation with 95% confidence. The device generates automated maintenance reports and partial-stroke test (PST) compliance logs for functional safety audits.

Extreme Environment Resilience: IP69K-rated housing withstands 100-bar water jets and CIP/SIP cleaning cycles, making the 034STM4-00-200-RS ideal for pharmaceuticals, food processing, and offshore splash zones. Wide temperature tolerance ensures reliability in Arctic pipelines or desert solar farms.

Energy Optimization: Dynamic air-volume control adjusts pneumatic output based on valve load profiles, reducing supply air consumption by 25% versus conventional positioners. Loop-powered operation eliminates external wiring in remote installations.

Application Field

The WINGREEN 034STM4-00-200-RS enables digital transformation in harsh and regulated industries:



Pharmaceuticals/Biotech: Controls sterile process valves in CIP/SIP systems with FDA 21 CFR Part 11 compliant data logging.



Food & Beverage: Manages aseptic filling and cleaning valves in washdown areas (IP69K).



Water/Wastewater: Optimizes pump control and chemical dosing in unmanned plants via LoRaWAN remote telemetry.



Mining/Mineral Processing: Positions slurry control valves in high-vibration mills with wear-compensation algorithms.



Energy: Regulates steam bypass valves in power plants (2.0 MPa output) with SIL 2 safety interlocks.



Hydrogen Economy: Certified for H₂ service with explosion-proof options (ATEX Zone 1).



Related Products



034STM4-00-100-RS: Lower pressure variant (0.14–0.7 MPa) for standard actuators.



WINGREEN 03ZSTL6-00-201-RS: SIL 3 positioner for safety-critical shutdowns.



WINGREEN IoT-GW500: LoRaWAN gateway for aggregating 034STM4-00-200-RS wireless data.



034STM4-01-200-FF: Foundation Fieldbus version with intrinsic safety.



WINGREEN VPA-800: Valve analytics software for cloud-based AI diagnostics.



05ZSC-400: Ultra-high-purity air filter (0.003µm) for semiconductor/pharma apps.



WINGREEN PST-3000: Automated partial-stroke tester for SIL 2 validation.



034STM3-00-200-RS: Previous-gen model without edge computing.
