Description

The ABB HC800 is a compact, cost-effective Human-Machine Interface (HMI) panel engineered for seamless integration with ABB’s CP800 and AC500 PLC series. Designed for space-constrained applications, this 7-inch touchscreen display delivers intuitive visualization and control of industrial processes while reducing cabinet footprint. The ABB HC800 features an embedded CODESYS V3 runtime, enabling local logic execution and alarm management without additional controllers. With IP65-rated front protection and a wide operating temperature range (-30°C to +60°C), it withstands harsh environments like food processing plants or outdoor substations.

Built-in Ethernet (TCP/IP, Modbus TCP) and serial ports (RS-232/485) enable direct connectivity to PLCs, drives, and I/O modules. The panel’s 800×480 WVGA resolution supports dynamic process graphics, trend visualization, and multi-language operator menus. The ABB HC800 also offers secure remote access via integrated web server and VNC support, allowing maintenance teams to diagnose issues off-site. As a unified component in ABB’s automation ecosystem, it simplifies lifecycle management from commissioning to decommissioning.

ABB HC800

Technical Specifications

Main Features and Advantages

Unified engineering environment:
Develop applications in CODESYS IDE using shared libraries with ABB PLCs. Drag-and-drop visualization templates accelerate project deployment. The ABB HC800’s SIL 2-certified runtime enables safety-critical local control like emergency stop acknowledgment.

Robust connectivity and access:
Direct integration with ABB drives via Modbus RTU reduces wiring. Remote diagnostics via built-in web server/VNC allows real-time troubleshooting. SD card slot (max 32 GB) enables data logging and backup restoration in minutes.

Durability and space efficiency:
Stainless-steel front bezel resists chemicals and mechanical impact. -30°C cold-start capability ensures reliability in freezer warehouses. At 45mm depth, it fits shallow control cabinets where conventional HMIs cannot.

Application Field

The ABB HC800 optimizes operator control in compact automation systems. In water/wastewater plants, it visualizes pump pressures and chemical dosing parameters while executing local filter backwash sequences. For packaging machinery, it displays production counters and jam diagnostics while controlling conveyor logic.

Renewable energy sites use it for solar inverter status monitoring and wind turbine brake control. Building management systems deploy it for HVAC scheduling and access control. The ABB HC800 also serves mobile equipment like electric forklifts, providing battery management interfaces in SIL 2 safety loops.

Related Products

ABB CP800: SIL 2 PLC controller for logic integration with HC800

ABB CMA180: 12-inch HMI with higher resolution for complex processes

ABB SD802: Analog input module for CP800 expansion

ABB CI801: PROFIBUS gateway for legacy device connectivity

ABB CP635: Entry-level HMI with basic visualization

ABB 3HAC050443-001: Mounting kit for HC800 panel integration

ABB DSDIO120: Digital I/O extension for local control

ABB HC800

Installation and Maintenance

Pre-installation preparation: Verify panel cutout dimensions (192 x 144 mm ±0.5 mm). Ensure ambient temperature stays within -30°C to +60°C. Use shielded cables (e.g., BELDEN 3076A) for communication ports, grounded at one end. Maintain 50 mm clearance above/below for ventilation.

Maintenance recommendations: Clean screen monthly with isopropyl alcohol (no abrasives). Update firmware annually via SD card. Monitor storage usage (<90>
