Description

The LAETUS LLS570-05 is a high-precision blue laser distance sensor engineered for critical quality control and inspection tasks in pharmaceutical, packaging, and automotive manufacturing. As part of Laetus’ advanced LLS500 series, this non-contact sensor delivers micron-level accuracy (up to ±0.01mm resolution) for measuring object dimensions, positions, and surface profiles in high-speed production lines. The LLS570-05 utilizes a 405nm blue laser stripe technology that excels on reflective, transparent, or dark surfaces – overcoming limitations of traditional red lasers. Integrated real-time algorithms filter environmental noise while its rugged IP67 housing withstands dust, moisture, and mechanical shocks. The module features dual GigE Vision and RS-485 interfaces for seamless integration with PLCs, vision systems, and Laetus’ proprietary inspection software platforms like TIMMS. For blister pack inspection, vial filling verification, or weld seam monitoring, the LAETUS LLS570-05 sets industry benchmarks in repeatability and reliability under demanding conditions.

LAETUS LLS570-05

Technical Specifications

Main Features and Advantages

Blue Laser Superiority: Unlike red lasers, the 405nm blue light of the LLS570-05 penetrates transparent materials (e.g., glass vials) and maintains focus on dark/reflective surfaces, achieving stable measurements where competitors fail.
Real-Time Noise Suppression: Advanced DSP filters ambient light interference and vibration artifacts, ensuring <0> Plug-and-Play Integration: Pre-configured measurement profiles for pharma blisters, tablet dimensions, and cap alignment accelerate deployment. GigE Vision support enables direct connectivity with Cognex Keyence, or Allen-Bradley systems.
Regulatory Compliance: Built-in audit trail functionality and electronic signatures meet FDA 21 CFR Part 11 requirements for pharmaceutical serialization and medical device traceability.
Ruggedized Design: Hermetically sealed optics resist fogging in washdown areas, while stainless-steel housing endures chemical exposure in battery manufacturing.

Application Field

The LLS570-05 dominates precision inspection applications requiring sub-millimeter accuracy. In pharmaceutical production, it verifies tablet/capsule counts in blister cavities and measures fill levels in syringes. Packaging lines deploy it for carton flap alignment, tamper-evident seal gap detection, and label position validation. Automotive manufacturers rely on the LLS570-05 for battery electrode thickness profiling, brake pad dimensional checks, and exhaust weld seam consistency monitoring. Electronics assembly uses it for PCB component coplanarity and connector pin height verification. Food & beverage applications include can seam integrity scanning and pouch seal width inspection. The sensor’s immunity to ambient light makes it ideal for printing registration control in flexographic presses.

Related Products

LLS570-10: Extended 100–500mm range variant for larger objects.

LLS550-R: Red laser sensor for cost-sensitive non-reflective surfaces.

TIMMS Software: Laetus’ inspection platform for LLS570-05 data analysis.

LSP-2000: Profile projector for manual measurement validation.

GLS-6000: Green laser scanner for ultra-high-speed (>30kHz) applications.

LVS-800 Series: Vision system complementing LLS570-05 for 2D defect detection.

LAETUS LLS570-05

Installation and Maintenance

Pre-installation preparation: Ensure stable mounting (vibration <0> Maintenance recommendations: Clean optics monthly with anhydrous ethanol using lint-free swabs. Quarterly verify calibration with certified gauge blocks. Monitor internal temperature logs via RS-485; sustained >40°C requires cooling optimization. Replace protective window annually in abrasive environments.
