The RELIANCE ELECTRIC S-D4041 is a high-power industrial AC drive engineered for heavy-duty motor control applications requiring robust performance and precision. As a premium model in Reliance Electric’s FlexPak® 3000 series – now part of Rockwell Automation’s PowerFlex® legacy portfolio – this 400V-class drive delivers 41A output current (30 kW/40 HP) with advanced closed-loop vector control for exceptional torque regulation (±0.5% speed accuracy). The S-D4041 features adaptive current-limiting algorithms and 200% starting torque capability, enabling reliable control of extreme-inertia loads like rock crushers, ball mills, and large compressor systems. Its modular design includes integrated DC bus chokes for harmonic suppression (<25>S-D4041 ensures operational stability in mining, cement production, and heavy manufacturing while optimizing energy efficiency through automatic slip compensation and regenerative braking capabilities.
RELIANCE ELECTRIC S-D4041
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | S-D4041 |
| Manufacturer | RELIANCE ELECTRIC (Rockwell Automation) |
| Product Type | AC Variable Frequency Drive |
| Output Current | 41A |
| Output Power | 30 kW (40 HP) @ 400V AC |
| Input Voltage | 380-480V AC ±10%, 3-phase |
| Control Method | Closed-Loop Vector Control |
| Overload Capacity | 150% for 60 sec, 250% for 3 sec |
| Switching Frequency | 2-12 kHz (programmable) |
| Braking Torque | 50% (standard), 150% with DB resistor |
| Communication | Dual expansion slots (RS-485 standard) |
| Enclosure Rating | NEMA 1 / IP20 |
| Operating Temperature | -10°C to +45°C (derated above 40°C) |
| Dimensions | 320 x 400 x 300 mm (HxWxD) |
| Certifications | CE, UL, cULus, IEC 61800-4 |
Main Features and Advantages
High-Torque Precision: Closed-loop encoder feedback enables ±0.5% speed accuracy at 0 RPM with 200% starting torque – critical for ball mill startups and extruder synchronization.
Active Harmonic Control: Integrated DC link chokes reduce input current THDi to<25>Intelligent Thermal Management: Dual variable-speed fans with dust-separating airflow paths maintain IGBT junction temperatures<125>Multi-Network Connectivity: Dual card slots support simultaneous EtherNet/IP and Profibus DP communication for real-time data exchange with PlantPAx® DCS.
Advanced Diagnostics: Built-in oscilloscope function captures torque/speed transients, while sequence-of-events logging identifies trip causes within 10ms resolution.
Application Field
The S-D4041 dominates extreme-duty industrial applications:
Mining: Control of SAG mill motors >500HP with anti-jam detection and torque-proving logic
Cement Production: Kiln drive synchronization maintaining constant torque during material feed fluctuations
Petrochemical: Large compressor control with antisurge algorithms and load-sharing between units
Wastewater Management: High-head pump control featuring dry-run protection and automatic alternation
Heavy Manufacturing: Rolling mill main drives requiring precise tension during coil transitions
Marine: Bow thruster motor control with salt-spray resistant conformal coating option
Related Products
S-D4031: 31A/22kW drive for mid-range applications
S-D4051: 51A/37kW next-step model
20-COMM-P: Profibus DP communication module
PowerFlex 755TR: Modern 40HP regenerative drive successor
1326AB-B5A40E-21: Reliance Severe Duty motor (40 HP)
HIM-H6C: Color graphical interface with data logging
S-D4041-EP: Enhanced protection version for dusty environments (IP54)
RELIANCE ELECTRIC S-D4041
Installation and Maintenance
Pre-installation preparation: Install input harmonic filters when utility short-circuit capacity >100kA. Maintain 400mm vertical clearance for convection cooling. Use symmetrical shielded motor cables with independent conduits for control wiring. Ground drive via dual 2/0 AWG copper conductors to dedicated earth grid (<0>Maintenance recommendations: Quarterly thermal imaging of power terminals. Annually measure DC bus capacitor ESR and leakage current. Verify IGBT gate resistance every 24 months. Replace cooling fans at 40,000 hours; clean heat sinks biannually with non-conductive vacuum.
