The RELIANCE ELECTRIC S-D4041B is a specialized heavy-duty AC drive engineered for applications requiring high-torque braking and rapid deceleration control. As an enhanced variant of the FlexPak® 3000 series (now under Rockwell Automation’s PowerFlex® legacy), this 400V-class drive delivers 41A output (30 kW/40 HP) with integrated dynamic braking transistor technology. The S-D4041B features closed-loop vector control and 200% starting torque for extreme-inertia loads like mine hoists, centrifugal decanters, and high-speed elevators. Its defining capability is native support for 150% continuous braking torque without external modules – enabled by oversized IGBTs and advanced thermal management. Designed for Rockwell-centric ecosystems, the drive includes dual communication slots for real-time synchronization with ControlLogix safety systems. With NEMA 1/IP20 protection and harmonic chokes pre-installed, the S-D4041B ensures reliable stopping performance in metals processing, material handling, and industrial lifting applications.
RELIANCE ELECTRIC S-D4041B
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | S-D4041B |
| Manufacturer | RELIANCE ELECTRIC (Rockwell Automation) |
| Product Type | AC Drive with Integrated Braking |
| Output Current | 41A |
| Output Power | 30 kW (40 HP) @ 400V AC |
| Braking Torque | 150% continuous / 300% peak |
| Input Voltage | 380-480V AC ±10%, 3-phase |
| Control Method | Closed-Loop Vector (Encoder Optional) |
| Overload Capacity | 150% for 60 sec (motoring) |
| Switching Frequency | 2-12 kHz programmable |
| Braking Resistor Support | Up to 50 kW external |
| Communication | Dual 20-COMM slots + RS-485 |
| Enclosure Rating | NEMA 1 / IP20 |
| Dimensions | 320 x 400 x 300 mm (HxWxD) |
| Certifications | UL, CE, cULus, IEC 61800-5-1 |
Main Features and Advantages
Integrated Braking System: Unlike standard drives, the S-D4041B incorporates reinforced braking IGBTs and snubber circuits capable of dissipating 25kW continuously – eliminating external braking modules for most applications.
Precision Deceleration Control: Adaptive braking algorithms prevent DC bus overvoltage during rapid stops, with programmable S-curve profiles for jerk-sensitive loads like glass conveyors.
Enhanced Thermal Design: Oversized heatsinks with temperature-controlled fans maintain braking components ≤85°C during continuous duty cycles.
Safety Integration: STO (Safe Torque Off) input and Safe Speed Monitor outputs meet PLd/SIL 2 requirements for hoisting applications.
Regenerative Energy Management: Optional grid-recovery module (S-D4041B-R) feeds braking energy back to AC supply, reducing operating costs.
Application Field
The S-D4041B excels where controlled deceleration is critical:
Mining: Hoist winch control with regenerative stops during cage descent
Elevators/Escalators: Precision floor-level braking with torque proving
Centrifugal Separation: Rapid deceleration of 2,000+ RPM decanter bowls
Paper Converting: Tension-controlled stops on winders preventing web breaks
Test Rigs: Dynamic load simulation with bidirectional power flow
Crane & Hoist: Load-controlled lowering with anti-sway algorithms
Related Products
S-D4041: Base model without integrated braking
DB-50-480: 50kW braking resistor for S-D4041B
20-COMM-S: Safety communication module
PowerFlex 755TR: Regenerative drive successor
1326AB-B5A40E-K: Brake motor pair
S-D4041B-R: Regenerative grid-feed version
HIM-H6S: Safety-rated HMI with stop log
RELIANCE ELECTRIC S-D4041B
Installation and Maintenance
Pre-installation preparation: Verify braking resistor compatibility (≤0.6Ω for 50kW). Dedicated 60A circuit required. Maintain 500mm clearance above drive for heat dissipation. Separate control/power cables with grounded metal divider.
Maintenance recommendations: Monthly inspection of braking resistor connections. Quarterly thermal imaging of IGBT modules. Calibrate torque feedback annually. Replace DC bus capacitors every 7 years. Monitor braking duty cycle via DriveTools™ SP software.
