The GE-369-HI-R-M-0-0-0-E is a specialized high-density vibration monitoring relay from GE’s Multilin 369 series, engineered for continuous condition monitoring of critical rotating machinery. Designed as a cost-effective solution for multi-point protection, this module integrates 16 analog inputs (expandable to 32) for simultaneous monitoring of vibration, temperature, and process variables across complex machinery trains. The GE-369-HI-R-M-0-0-0-E features real-time FFT analysis with 800-line resolution, detecting early-stage bearing defects, imbalance, and misalignment in pumps, compressors, and fans. Its rugged IP52-rated enclosure houses programmable relay logic (6 Form-C contacts) for automated shutdown sequences, while dual Ethernet ports support IEC 61850 GOOSE messaging for system-wide coordination. With -40°C to +70°C operation and conformal-coated circuitry, this variant excels in harsh industrial environments where space constraints preclude multiple single-channel monitors.

Get a Quote
Manufacturer:
Our extensive catalogue, is available now for dispatch to the worldwide.
  • Email: sales@slxytech.com
  • WhatsApp / Wechat：8617062388866
  • Phone：+86 17062388866

Description

The GE-369-HI-R-M-0-0-0-E is a specialized high-density vibration monitoring relay from GE’s Multilin 369 series, engineered for continuous condition monitoring of critical rotating machinery. Designed as a cost-effective solution for multi-point protection, this module integrates 16 analog inputs (expandable to 32) for simultaneous monitoring of vibration, temperature, and process variables across complex machinery trains. The GE-369-HI-R-M-0-0-0-E features real-time FFT analysis with 800-line resolution, detecting early-stage bearing defects, imbalance, and misalignment in pumps, compressors, and fans. Its rugged IP52-rated enclosure houses programmable relay logic (6 Form-C contacts) for automated shutdown sequences, while dual Ethernet ports support IEC 61850 GOOSE messaging for system-wide coordination. With -40°C to +70°C operation and conformal-coated circuitry, this variant excels in harsh industrial environments where space constraints preclude multiple single-channel monitors.

GE-369-HI-R-M-0-0-0-E

GE-369-HI-R-M-0-0-0-E

Technical Specifications

Parameter NameParameter Value
Product ModelGE-369-HI-R-M-0-0-0-E
ManufacturerGE (General Electric)
Product TypeHigh-Density Vibration Monitor
Analog Inputs16 channels (8x velocity/accel, 4x 4-20mA, 4x RTD/TC)
Vibration Range0.1–500 mm/s RMS (velocity), 0.1–200 g pk (acceleration)
Frequency Response0.5 Hz to 10 kHz (±1 dB)
Relay Outputs6× Form-C (5A @ 250V AC)
CommunicationDual Ethernet (IEC 61850/Modbus TCP), RS-485 Modbus RTU
Sampling Rate51.2 kS/s per channel
Dynamic Range120 dB
Power Supply24–48V DC / 100–240V AC
Operating Temp-40°C to +70°C
CertificationsUL 508, IEC 60255, API 670
EnclosureIP52 (144×144×160 mm)

Main Features and Advantages

High-Channel Density: The GE-369-HI-R-M-0-0-0-E consolidates monitoring of entire machinery trains (e.g., pump + motor + gearbox) in one unit, reducing panel space by 60% versus discrete monitors. Simultaneous multi-parameter capture enables cross-correlation of vibration, temperature, and process data.

Advanced Diagnostics: Embedded order tracking identifies speed-synchronous faults in variable-speed drives. Wavelet transform algorithms detect transient events like belt slippage or cavitation. Custom *ISO 10816/20816 severity bands* trigger alarms based on machine class.

Cybersecurity & Reliability: Hardware-level secure boot and role-based access control meet NERC CIP standards. The triple modular redundancy architecture delivers 99.999% availability. Hot-swappable SSD storage retains 90 days of waveform data.

Application Field

The GE-369-HI-R-M-0-0-0-E protects multi-component rotating systems where footprint matters:

Energy Sector:



Combined-cycle plant auxiliary trains (BFPs, ID fans)



Hydro turbine bearing monitoring



Wind farm gearbox arrays



Oil & Gas:



Offshore platform crude injection pumps



Pipeline compressor stations



Refinery FCCU air blowers



Process Industries:



Pharmaceutical centrifuge farms



Food processing packaging lines



Wastewater treatment aeration blowers



Marine Applications:



Ship engine room monitoring



LNG cargo pump vibration



Related Products



GE-369-HI-0-0-0-0: Base high-input model without relays



GE-369-LO-R-M-0-0-0: Low-channel variant (8 inputs)



GE B30: Ultra-compact vibration monitor



IS420ESWBH3A: Managed Ethernet switch



IC754VSI12CTD: 12″ HMI for local diagnostics



Bently Nevada 3300 XL: Proximity probe system



GE-370: Enhanced machinery protection system

GE-369-HI-R-M-0-0-0-E

GE-369-HI-R-M-0-0-0-E

Installation and Maintenance

Pre-installation preparation: Verify DIN rail mounting clearance (>50mm top/bottom), confirm sensor compatibility (100mV/g IEPE or 4-20mA), and allocate IP addresses via EnerVista software. Ensure independent 24V DC backup.

Maintenance recommendations: Calibrate inputs annually with portable calibrator. Perform monthly relay contact resistance checks. Update GE-369-HI-R-M-0-0-0-E firmware using SecureLoader during outages. Replace cooling fan every 5 years in dusty environments.
