Description

The Watlow Anafaze CLS208 208-C10000CP is a high-reliability digital output module designed for industrial automation and process control applications requiring precise, solid-state switching of low-to-medium power loads. As part of Watlow’s legacy Anafaze CLS (Compact Logic Series) I/O family, the Watlow Anafaze CLS208 208-C10000CP provides eight independent, optically isolated solid-state relay (SSR) outputs, each capable of switching up to 2 A at 24–280 VAC/VDC. This makes it ideal for driving solenoid valves, small contactors, indicator lamps, heater bands, and other control devices without the mechanical wear, arcing, or audible noise associated with electromechanical relays.

Engineered for seamless integration into PLC-based or standalone control panels, the Watlow Anafaze CLS208 208-C10000CP features a compact DIN-rail form factor, 24 VDC logic input interface, and robust electrical isolation between channels and field power. The “208-C10000CP” suffix denotes a specific configuration with common positive logic (sinking inputs) and conformal coating for enhanced protection in humid or corrosive environments. Although originally developed for thermal processing systems—such as ovens, furnaces, and plastic extruders—the Watlow Anafaze CLS208 208-C10000CP has found widespread use across food & beverage, packaging, semiconductor, and water treatment industries due to its long service life, fast switching speed, and immunity to vibration.

Technical Specifications

Main Features and Advantages

Solid-state reliability with zero moving parts:
Unlike traditional electromechanical relay modules, the CLS208 208-C10000CP uses semiconductor switching technology that eliminates contact bounce, mechanical fatigue, and coil failures. This results in millions of switching cycles without degradation—critical for high-frequency applications like pulse-width modulation (PWM) of heaters or rapid valve sequencing in batch processes.

Optical isolation ensures system integrity and noise immunity:
Each output channel on the CLS208 208-C10000CP is protected by high-speed optocouplers, providing 2500 Vrms isolation between the low-voltage control side (PLC) and the high-voltage field side. This prevents ground loops, suppresses EMI from motor drives or VFDs, and safeguards sensitive controllers from voltage transients—a key advantage in electrically noisy industrial plants.

Compact footprint and easy integration:
Measuring just 45 mm wide, the CLS208 208-C10000CP delivers 8 outputs in less than half the space of comparable relay modules. Its screw-terminal design supports 12–24 AWG wire, and status LEDs per channel allow instant visual diagnostics. Because it draws logic power directly from the 24 VDC control bus (no separate supply needed), panel wiring is simplified, reducing both cost and commissioning time.

Application Field

The Watlow Anafaze CLS208 208-C10000CP excels in applications demanding silent, maintenance-free switching with high cycle life. In industrial ovens and curing systems, it controls multiple heating zones by switching SSRs or contactor coils based on temperature feedback from PLCs—ensuring uniform thermal profiles in automotive paint lines or composite manufacturing. In food processing, the CLS208 208-C10000CP actuates steam valves, cooling fans, and conveyor clutches in washdown environments, where its conformal coating resists moisture and cleaning chemicals.

In packaging machinery, the module triggers glue applicators, reject gates, and label dispensers at high speed without mechanical lag. Similarly, in water and wastewater treatment plants, the Watlow Anafaze CLS208 208-C10000CP operates chemical dosing pumps and backwash valves in remote pump stations, benefiting from its resistance to humidity and wide operating temperature range. Even in legacy retrofit projects, engineers select the CLS208 208-C10000CP to replace aging relay racks—extending system life without reprogramming the host controller, thanks to its plug-compatible logic interface.

Related Products

CLS204 204-C10000CP: 4-channel version of the same SSR output module—half the density.
CLS108 108-C10000CP: 8-channel digital input module—complements CLS208 for full I/O expansion.
CLS308: Analog output variant (e.g., 4–20 mA or 0–10 V)—used for proportional control.
DIN-RELAY-8: Electromechanical 8-relay alternative—higher current but shorter lifespan.
Watlow EZ-ZONE RM: Modern thermal controller that can replace older Anafaze-based systems.
PLC-IO-EXTENDER: Generic I/O extender—less integrated than CLS208 but more flexible.

Installation and Maintenance

Pre-installation preparation: Mount the CLS208 208-C10000CP on a standard 35 mm DIN rail with adequate spacing (minimum 10 mm on each side) for heat dissipation, even though it runs cool. Verify that the 24 VDC control source can supply sufficient current for all active inputs (typically<10>

Maintenance recommendations: Although the CLS208 208-C10000CP requires no routine maintenance, periodically inspect terminal tightness and look for discoloration on output terminals—indicative of overloading. If an output fails “on” or “off,” the entire module must be replaced, as SSRs are not field-serviceable. Monitor the per-channel LEDs during operation; a dark LED when the PLC output is active suggests either a blown SSR or incorrect logic polarity. Always keep a spare CLS208 208-C10000CP in inventory—its failure can halt an entire production line, yet replacement takes under five minutes.
