Description

The YOKOGAWA CP461-50 is a high-availability central processing unit (CPU) module designed for use in Yokogawa’s CENTUM VP and CENTUM CS 3000 integrated production control systems. As a next-generation control processor, the YOKOGAWA CP461-50 serves as the intelligent core of the control station, executing real-time process control logic, managing I/O data, and ensuring seamless communication across the plant-wide Vnet/IP network. Engineered for mission-critical applications in the oil & gas, chemical, power, and pharmaceutical industries, the YOKOGAWA CP461-50 delivers superior processing performance, enhanced redundancy, and deterministic control response to maintain operational safety, efficiency, and continuity.

Featuring a powerful industrial-grade processor and expanded memory capacity, the YOKOGAWA CP461-50 supports complex regulatory control, batch sequencing, safety interlocks, and advanced process optimization strategies. It operates in hot-standby redundant configurations, allowing for zero-downtime failover between active and standby CPUs—ensuring uninterrupted control even during hardware faults or maintenance. The module is fully compatible with Yokogawa’s OpreX Control suite and integrates natively with the Vnet/IP control network, enabling high-speed, secure, and redundant communication with operator stations, engineering stations, and field I/O subsystems. With support for IEC 61131-3 programming languages and embedded cybersecurity features, the YOKOGAWA CP461-50 represents a robust, future-ready platform for modernizing legacy systems and deploying new digital automation infrastructure.

YOKOGAWA CP461-50

Technical Specifications

Product Model	CP461-50
Manufacturer	Yokogawa Electric Corporation
Product Type	Central Processing Unit (CPU) Module
Compatible Systems	CENTUM VP (R6.01 and later), CENTUM CS 3000
Control Network	Vnet/IP (Redundant 100 Mbps Ethernet)
Redundancy Support	Hot Standby (Dual CPU Configuration)
Processor	High-performance industrial multi-core CPU
Memory	2 GB RAM, 4 GB Flash Storage (typical)
Control Execution Cycle	Adjustable from 10 ms to 10 s
Max Control Loops per CPU	Up to 5,000 (configuration-dependent)
Programming Languages	Function Block Diagram (FBD), Sequential Function Chart (SFC), Structured Text (ST), Ladder Logic (LD)
Communication Protocols	Vnet/IP, Modbus/TCP, EtherNet/IP (via interface modules), OPC UA (optional)
Operating Temperature	0 °C to +55 °C
Storage Temperature	-25 °C to +80 °C
Humidity Range	20% to 80% RH (non-condensing, no dew)
Power Supply	24 VDC via backplane (from PRM121-S00 or equivalent power module)
Hot-Swap Support	Yes (with redundancy enabled)
Certifications	IEC 61000-6-2 (EMC), IEC 61000-6-4, IEC 62443-3-3 (Cybersecurity), UL, CSA, CE

Main Features and Advantages

High Performance & Scalability

The YOKOGAWA CP461-50 offers significantly enhanced processing power and memory over earlier CPU models like the CP451-10, enabling it to handle larger control strategies, more I/O points, and complex batch or safety logic. This makes it ideal for large-scale plants or systems undergoing digital transformation and integration.

Hot-Standby Redundancy

Equipped with automatic synchronization and failover capabilities, the YOKOGAWA CP461-50 ensures zero process interruption during CPU faults, firmware updates, or hardware replacement. The standby CPU continuously mirrors the active unit’s state, allowing for seamless switchover in milliseconds.

Native Vnet/IP Integration

As a core node on Yokogawa’s Vnet/IP network, the CP461-50 supports deterministic, high-speed communication with up to 128 nodes. Dual-redundant network paths eliminate single points of failure, ensuring data integrity and system availability.

Advanced Programming & Diagnostics

Support for IEC 61131-3 languages (FBD, SFC, ST, LD) provides engineering flexibility for diverse control applications. Built-in diagnostics monitor CPU load, memory usage, communication status, and I/O health, accessible via the Engineering Station or HIS.

Cybersecurity & Compliance

The CP461-50 incorporates security features aligned with IEC 62443, including secure boot, access control, and audit logging. It supports secure firmware updates and integration with network security appliances for defense-in-depth strategies.

Seamless System Integration

Fully interoperable with Exaquantum PIMS, PRM (Plant Resource Manager), and OpreX Asset Health Insights, the CP461-50 acts as a data-rich node in digital plant architectures, enabling predictive maintenance, performance monitoring, and enterprise-wide analytics.

Application Field

The YOKOGAWA CP461-50 is deployed in industrial facilities requiring high reliability, scalability, and real-time control precision:

Oil & Gas Refineries: Controls crude distillation, catalytic reforming, and hydrotreating units with high loop density and safety-critical interlocks.
Chemical Plants: Manages exothermic reactions, polymerization, and solvent recovery systems requiring precise sequencing and batch control.
LNG Facilities: Coordinates liquefaction trains, boil-off gas handling, and emergency shutdown systems under extreme environmental conditions.
Power Generation: Regulates boiler-turbine coordination, emissions control, and auxiliary systems in combined-cycle and cogeneration plants.
Pharmaceuticals & Biotech: Executes FDA-compliant batch processes with full traceability, recipe management, and electronic records.
Water & Wastewater: Manages large-scale pumping, filtration, and disinfection systems with high availability requirements.
