The ABB 5SHX2645L0002 3HB012961R0001 represents ABB’s flagship high-voltage Integrated Gate-Commutated Thyristor (IGCT) power stack with integrated gate driver, engineered for ultra-efficient power conversion in multi-megawatt applications. This cutting-edge solution combines a 6.5kV asymmetric blocking IGCT semiconductor with the intelligent 3HB012961R0001 gate unit, delivering 30% higher power density than previous-generation systems. Designed for ACS 6080 drive platforms and HVDC converters, the 5SHX2645L0002 features enhanced press-pack technology with silicon-carbide hybrid clamping that reduces switching losses by 22% while maintaining 55kA surge withstand capability. The corrosion-resistant titanium-aluminum housing provides military-grade environmental protection, enabling deployment in extreme conditions from Arctic offshore platforms to desert solar farms.
Optimized for three-level NPC (Neutral Point Clamped) topologies, the ABB 5SHX2645L0002 3HB012961R0001 achieves industry-leading efficiency with <3>
ABB 5SHX2645L0002 3HB012961R0001
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | 5SHX2645L0002 3HB012961R0001 |
| Manufacturer | ABB |
| Product Type | Press-Pack IGCT Power Stack with Gate Driver |
| Blocking Voltage | 6.5 kV (Asymmetric) |
| Nominal Current | 3,000 A RMS |
| Max Surge Current | 55 kA (1 ms half-sine) |
| Switching Frequency | 800 Hz (Maximum) |
| Turn-off Time | <3> |
| Gate Unit Supply | 28V DC ±0.25% (Quad-redundant) |
| Control Interface | 4x 850 nm Redundant Optical Channels |
| Thermal Resistance | 0.009 K/W (Junction-to-coolant) |
| Cooling Requirement | Direct Deionized Water: 15 L/min @ ΔT=40K |
| Operating Temperature | -50°C to +150°C (Junction) |
| Short-Circuit Withstand | 15 μs (Full voltage) |
| Isolation Voltage | 12 kV AC (1 min) |
| Dimensions (Stack) | 245 × 165 × 62 mm (W × H × D) |
| Weight | 12.3 kg |
