Description

The Bosch Rexroth PPC-R22.1N-T-NN-P1-NN-FW is a high-performance industrial Panel PC designed for demanding automation environments where reliability, integrated computing, and human-machine interaction converge. As part of Bosch Rexroth’s PPC (Panel PC) series, this 22-inch all-in-one computer combines a rugged front panel with a fully functional embedded PC, enabling seamless integration into machinery, control cabinets, or standalone operator stations. The PPC-R22.1N-T-NN-P1-NN-FW serves as both a visualization terminal and a local control engine—capable of running SCADA applications, soft PLCs (such as CODESYS), or custom Windows-based software directly on the machine.

Built for continuous operation in electrically noisy and mechanically harsh settings, the Bosch Rexroth PPC-R22.1N-T-NN-P1-NN-FW features a fanless design that eliminates moving parts, significantly enhancing long-term reliability in dusty or washdown-prone areas. Its IP65-rated front panel ensures protection against dust ingress and water jets, making it suitable for food & beverage, packaging, and metal processing applications. Equipped with an Intel Celeron processor, solid-state storage, and multiple industrial I/O interfaces, the PPC-R22.1N-T-NN-P1-NN-FW delivers responsive performance for real-time data acquisition, remote diagnostics, and edge computing tasks—bridging the gap between traditional HMI terminals and modern industrial PCs.

Technical Specifications

Main Features and Advantages

Robust mechanical and environmental resilience: The Bosch Rexroth PPC-R22.1N-T-NN-P1-NN-FW is engineered for industrial durability. Its fully sealed front bezel meets IP65 standards, resisting dust, oil mist, and high-pressure cleaning—critical in food processing or pharmaceutical production lines. The fanless architecture not only reduces noise but also prevents particulate buildup that could lead to overheating, ensuring maintenance-free operation for years. The aluminum housing provides excellent EMI shielding and thermal dissipation, even in environments with frequent motor starts or VFD interference.

High-performance embedded computing for edge applications: Unlike basic HMIs limited to visualization, the PPC-R22.1N-T-NN-P1-NN-FW functions as a full-fledged industrial computer. With an Intel Celeron processor, 4 GB RAM, and SSD storage, it can host advanced applications such as predictive maintenance algorithms, OPC UA servers, or even soft PLC runtime environments. This enables decentralized intelligence—reducing dependency on central controllers and improving system responsiveness. The inclusion of dual Gigabit Ethernet ports supports PROFINET, EtherNet/IP, or Modbus TCP communication, facilitating direct integration with PLCs from Siemens, Rockwell, or Schneider.

Flexible integration and future-proof expandability: The Bosch Rexroth PPC-R22.1N-T-NN-P1-NN-FW offers versatile mounting and connectivity options. Standard panel cutout dimensions simplify retrofitting into existing machines, while VESA compatibility allows arm or stand mounting for mobile workstations. The resistive touch screen ensures reliable operation with gloves or styluses—a practical advantage in cold storage or chemical handling facilities. Additionally, Windows 10 IoT Enterprise provides long-term support, security updates, and compatibility with modern development tools like Visual Studio or TIA Portal, protecting the user’s software investment well into the future.

Application Field

The Bosch Rexroth PPC-R22.1N-T-NN-P1-NN-FW is widely deployed in industries requiring robust, intelligent, and locally autonomous machine interfaces. In packaging machinery, it serves as the central operator terminal for form-fill-seal lines, displaying real-time throughput, error logs, and recipe management—while simultaneously running a local soft PLC to coordinate servo drives and vision systems. Its IP65 rating withstands frequent washdowns with caustic cleaners, ensuring hygiene compliance without compromising electronics.

In material handling and intralogistics, the PPC-R22.1N-T-NN-P1-NN-FW powers warehouse control stations for automated guided vehicle (AGV) fleets or conveyor sortation systems. Operators use its large touchscreen to monitor traffic flow, reroute parcels during jams, or initiate emergency stops. The dual Ethernet ports enable one connection to the plant network and another to safety controllers, maintaining separation between operational and safety-critical data streams.

Metal forming and plastics injection molding also benefit from the PPC-R22.1N-T-NN-P1-NN-FW’s resilience. Installed directly on press brakes or extruders, it endures vibration, temperature swings, and electrical noise while providing operators with intuitive access to cycle parameters, tool libraries, and energy consumption dashboards. In all these scenarios, the PPC-R22.1N-T-NN-P1-NN-FW transcends traditional HMI roles by delivering embedded computing power at the machine edge—enhancing productivity, diagnostics, and operational flexibility.

Related Products

PPC-R15.1N-T-NN-P1-NN-FW: 15-inch version of the same series—ideal for space-constrained panels
PPC-R22.1N-C-NN-P1-NN-FW: Identical to PPC-R22.1N-T-NN-P1-NN-FW but with projective capacitive touch for multi-touch gestures
PPC-R22.1N-T-NN-P2-NN-FW: Higher-spec variant with 8 GB RAM and 256 GB SSD for data-intensive applications
IndraControl VEPH: Bosch Rexroth’s alternative industrial PC platform with similar functionality but different form factor
MTX800: Legacy Bosch Rexroth HMI series; PPC-R22.1N offers modern OS and greater computing power
PPC-M22.1N-T-NN-P1-NN-FW: Marine-certified version with extended temperature and anti-corrosion treatment
CSB01.1C-SE-ENS-ENS-L3-S-NN-FW: Bosch Rexroth drive controller often paired with PPC-R22.1N in motion systems

Installation and Maintenance

Pre-installation preparation: Before mounting the Bosch Rexroth PPC-R22.1N-T-NN-P1-NN-FW, verify that the panel cutout matches the specified dimensions (typically 532.5 × 332.5 mm) and that the surrounding area allows for adequate heat dissipation. Ensure the 24 VDC power supply is clean, regulated, and equipped with overcurrent protection. Ground the unit through the provided grounding lug to minimize EMI susceptibility. When connecting communication cables, use shielded industrial-grade Ethernet and serial cables, with shields grounded at the cabinet entry point to prevent ground loops.

Maintenance recommendations: The PPC-R22.1N-T-NN-P1-NN-FW requires minimal routine maintenance due to its fanless, solid-state design. Periodically clean the touchscreen with a non-abrasive, alcohol-free wipe to maintain clarity and touch accuracy. Monitor system health via Windows Event Viewer or third-party tools to track disk usage and temperature trends. Although the SSD has no moving parts, it has a finite write cycle life—enable disk write caching optimization in Windows for extended service life. Keep a system image backup to enable rapid recovery in case of OS corruption. Firmware and driver updates should be applied during scheduled downtimes to ensure compatibility with evolving network protocols and security standards.
