Description

The Woodward MRR1-D is a dual-channel redundant relay output module engineered for high-integrity control and protection applications in power generation and industrial turbine systems. Developed by Woodward, Inc.—a global leader in combustion control, turbine governing, and engine management—the Woodward MRR1-D serves as a critical interface between Woodward’s programmable controllers (such as the 505, 505E, and MicroNet families) and field-mounted safety devices like fuel shutoff valves, generator breakers, and alarm annunciators. This module provides two independent, form-C (SPDT) relay contacts rated for both AC and DC loads, enabling direct switching of critical trip and auxiliary circuits without intermediate relays.

Positioned within Woodward’s modular I/O ecosystem, the Woodward MRR1-D supports redundant or non-redundant configurations, making it suitable for both basic machinery protection and SIL-compliant safety instrumented systems (SIS). Its robust design includes galvanic isolation between logic and field sides, conformal coating for humidity resistance, and compliance with industrial EMC standards—ensuring reliable operation in electrically noisy environments near large generators or switchgear. By delivering deterministic, fail-safe relay actuation based on controller commands, the Woodward MRR1-D plays a pivotal role in preventing equipment damage during overspeed, flameout, or loss-of-lube-oil events. The module’s compact form factor allows seamless integration into existing Woodward chassis, preserving panel space while enhancing system resilience.

Technical Specifications

Parameter Name	Parameter Value
Product Model	MRR1-D
Manufacturer	Woodward, Inc.
Product Type	Redundant Relay Output Module
Number of Channels	2 independent SPDT (Form C) relays
Contact Rating	5 A @ 250 V AC / 30 V DC (resistive load)
Contact Material	Silver alloy
Isolation Voltage	2500 Vrms (logic to field)
Operating Temperature	0°C to +60°C
Power Supply	+24 V DC (from backplane)
Mounting	Plug-in module for Woodward I/O chassis (e.g., 505E rack)
Dimensions	Approx. 160 mm × 35 mm × 120 mm
Certifications	CE, UL 508, CSA C22.2 No. 142

Main Features and Advantages

Dual independent relay channels with true redundancy: The Woodward MRR1-D features two fully isolated SPDT relays, each capable of operating independently or in tandem for 1oo2 (one-out-of-two) voting logic. This architecture is essential for turbine trip systems where a single point of failure must be avoided—ensuring that a fault in one channel does not compromise overall safety function integrity.

Direct compatibility with legacy and modern Woodward controllers: Designed as a native I/O module for the 505E electronic governor and MicroNet programmable automation platforms, the Woodward MRR1-D requires no external drivers or protocol converters. It communicates seamlessly over the internal backplane, reducing wiring complexity and eliminating communication latency that could delay critical shutdown sequences.

Robust construction for harsh industrial environments: Encased in a flame-retardant, conformal-coated housing, the Woodward MRR1-D resists moisture, dust, and chemical vapors commonly found in power plants and compressor stations. Its silver-alloy contacts withstand arcing from inductive loads such as solenoid coils, ensuring long service life even under frequent cycling.

Fail-safe design philosophy: In the event of power loss or controller failure, the Woodward MRR1-D’s relays default to a known safe state (typically de-energized), aligning with IEC 61508 functional safety principles. This behavior ensures that protective devices like fuel valves close automatically during emergencies—even if the control system is compromised.

Diagnostic readiness and maintainability: Each relay on the Woodward MRR1-D includes LED status indicators visible through the front panel, allowing operators to verify coil energization at a glance. The module supports hot-swap replacement in compatible chassis, minimizing downtime during maintenance. Its standardized footprint also simplifies spares management across multi-unit facilities.

Application Field

The Woodward MRR1-D is predominantly deployed in power generation and mechanical drive applications where reliable relay-based actuation is required for safety-critical functions. In natural gas-fired turbine plants, it interfaces directly with emergency fuel shutoff valves, lube oil dump valves, and generator circuit breaker trip coils—executing rapid shutdowns during overspeed, high vibration, or loss of flame conditions detected by the 505E governor. Similarly, in steam turbine systems used in cogeneration or district heating, the Woodward MRR1-D triggers condenser vacuum breakers and extraction steam isolation valves to prevent water induction damage.

Compressor stations in oil & gas pipelines also rely on the Woodward MRR1-D to manage anti-surge protection and emergency venting sequences. When integrated with MicroNet controllers, it enables coordinated shutdown of multiple compressors while activating flare systems—maintaining pipeline integrity during upstream disturbances. Hydroelectric facilities use the Woodward MRR1-D to control wicket gate servos and excitation system disconnects during grid faults or bearing temperature excursions.

Beyond energy, the Woodward MRR1-D finds use in marine propulsion systems, where it links engine control units to fire suppression and shaft brake mechanisms. Its ability to operate reliably in high-vibration, salt-laden environments makes it suitable for offshore platforms and LNG carriers. Even in industrial retrofits, aging turbine controls are often upgraded by retaining proven hardware like the Woodward MRR1-D while modernizing only the logic layer—extending asset life without compromising safety.

Installation and Maintenance

Pre-installation preparation: Before installing the Woodward MRR1-D, confirm compatibility with the target I/O chassis (e.g., 505E or MicroNet rack) and ensure the backplane supplies stable +24 V DC. Verify that field wiring uses stranded, shielded cable rated for the connected load voltage, with shields grounded at the controller end only. Label both relay outputs clearly according to the P&ID or logic diagram to avoid miswiring trip circuits. Insert the Woodward MRR1-D firmly into the slot until the retention latch engages, and power cycle the chassis if required for module recognition.

Maintenance recommendations: The Woodward MRR1-D should be inspected annually for signs of contact pitting, terminal corrosion, or LED malfunction. Use a multimeter to check continuity across relay contacts during forced-output tests initiated from the controller. If chatter or delayed actuation is observed, replace the module—relay contacts cannot be serviced in the field. Store spare Woodward MRR1-D units in static-dissipative packaging at controlled temperature to preserve component integrity. Always follow lockout/tagout procedures before removing the module, as its outputs may control hazardous energy sources.
