Description

The DALSA CR-GEN0-M6400R3 is a high-performance line scan camera designed for demanding machine vision applications, representing the cutting-edge imaging technology from Teledyne DALSA’s renowned product portfolio. As part of the Genie Nano series, this advanced camera delivers exceptional image quality and processing capabilities with a maximum line rate of 64 kHz, making it suitable for high-speed inspection and measurement applications. The DALSA CR-GEN0-M6400R3 combines sophisticated imaging technology with robust industrial design to ensure reliable performance in various vision inspection scenarios. Its compact form factor and advanced features make it ideal for applications requiring high-resolution imaging, precise measurements, and consistent performance, establishing the DALSA CR-GEN0-M6400R3 as a preferred choice for system integrators and OEMs in industrial automation.

Engineered for seamless integration into modern machine vision systems, the CR-GEN0-M6400R3 supports multiple interface standards including GigE Vision, ensuring compatibility with various vision processors and control architectures. The camera’s advanced image processing capabilities and flexible triggering options enable optimal performance across diverse inspection environments and lighting conditions. The DALSA CR-GEN0-M6400R3 offers significant value through its ability to enhance inspection accuracy, improve production quality control, and increase manufacturing throughput, making it an essential component in applications where precision vision inspection is critical for operational success. With its robust construction and reliable performance, the DALSA CR-GEN0-M6400R3 ensures long-term operational efficiency in the most demanding industrial environments.

Technical Specifications

Main Features and Advantages

Advanced Imaging Performance: The DALSA CR-GEN0-M6400R3 delivers exceptional image quality through its high-resolution 8k CMOS sensor and advanced image processing capabilities. The camera features a maximum line rate of 64 kHz, enabling high-speed inspection of moving materials without compromising image quality. With its 5.0 μm pixel size and excellent sensitivity, the DALSA CR-GEN0-M6400R3 captures detailed images even in challenging lighting conditions. The camera’s advanced features including programmable gain, offset, and gamma correction ensure optimal image quality for various application requirements, providing reliable performance in diverse industrial environments.

Enhanced Connectivity and Integration: The DALSA CR-GEN0-M6400R3 offers seamless integration through GigE Vision interface standard, ensuring compatibility with a wide range of vision processors and software platforms. This standardized interface provides reliable data transmission over long distances using standard Ethernet cables, simplifying

Application Field

The DALSA CR-GEN0-M6400R3 is extensively used in high-speed machine vision applications across various industries where precision inspection, measurement, and quality control are critical. In web inspection applications, the CR-GEN0-M6400R3 performs continuous inspection of moving materials such as paper, plastic films, metals, and textiles, detecting defects, monitoring quality, and ensuring product consistency. The camera’s high resolution and fast line rate make it ideal for applications requiring detailed inspection of wide materials at high production speeds, such as in printing, converting, and roll-to-roll manufacturing processes.

In electronics manufacturing, the DALSA CR-GEN0-M6400R3 provides precise inspection of printed circuit boards, displays, and semiconductor components, identifying defects, verifying assembly quality, and ensuring product reliability. The camera’s high-resolution capabilities enable detection of minute defects and precise measurements critical for electronics quality assurance. The DALSA CR-GEN0-M6400R3 also finds significant application in food and pharmaceutical inspection, where it performs quality control checks, verifies packaging integrity, and ensures compliance with industry regulations. The camera’s robust design and reliable performance make it suitable for cleanroom environments and hygienic production facilities where maintaining product quality and safety is paramount.

system integration and reducing installation costs. The camera features comprehensive digital I/O capabilities with 4 inputs and 4 outputs, enabling flexible triggering and synchronization with external equipment. The CR-GEN0-M6400R3 also supports GenICam protocol, providing a consistent programming interface across different camera models and simplifying application development.

Robust Industrial Design: Engineered for demanding industrial environments, the DALSA CR-GEN0-M6400R3 features a compact, rugged design that ensures reliable operation in harsh conditions. The camera’s metal housing provides excellent durability and thermal performance, while the F-mount lens interface ensures secure lens attachment and precise optical alignment. With its wide operating temperature range and industrial-grade components, the DALSA CR-GEN0-M6400R3 delivers exceptional reliability and long service life, reducing maintenance requirements and downtime. The camera’s comprehensive diagnostic capabilities and status monitoring features enable early detection of potential issues, supporting proactive maintenance strategies and maximizing system availability.

CR-GEN0-M6400R3 DALSA

Related Products

CR-GEN0-M4000R3: 4k resolution model with 40 kHz line rate

CR-GEN0-M3200R3: 3.2k resolution model with 32 kHz line rate

CR-GEN0-C6400R3: Color version with similar specifications

Xcelera-CL PX4: Frame grabber for camera integration

Sapera Processing: Software development toolkit

F-mount lenses: Compatible optical lenses

GigE Vision cables: Certified interface cables

IA-10F0-0000: Industrial light source for illumination
