The DS200SLCCG1AFG is a highly versatile and robust single-channel isolated analog input terminal board manufactured by GE Energy (now part of GE Vernova) for its Mark Vie turbine control system. This board serves as a critical interface between field analog sensors and the central controller, providing precise signal conditioning, electrical isolation, and conversion for accurate data acquisition. Designed for extreme reliability in demanding industrial environments, the DS200SLCCG1AFG ensures the integrity of vital process measurements such as pressure, temperature, flow, and level, which are essential for the safe and efficient operation of gas and steam turbines.
As a core component within the Speedtronic Mark Vie series, this terminal board is engineered to meet the rigorous requirements of power generation applications. The GE DS200SLCCG1AFG receives low-level analog signals from various transmitters, conditions them by filtering noise, and isolates them to protect the sensitive downstream control system from ground loops, voltage transients, and other electrical disturbances prevalent in plant environments. The board then converts the conditioned signal into a standardized format for processing by the main processor boards. Its design emphasizes long-term stability and accuracy, which are non-negotiable for the precise control loops governing turbine speed, temperature, and load.
DS200SLCCG1AFG GE
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | DS200SLCCG1AFG |
| Manufacturer | GE Energy / GE Vernova |
| Product Type | Isolated Analog Input Terminal Board |
| Application Series | Mark Vie Turbine Control System |
| Number of Channels | 1 (Single-channel) |
| Input Signal Type | Analog (typically 4-20 mA, 1-5 V DC, or other ranges via configuration) |
| Isolation | Channel-to-channel and channel-to-logic isolation |
| Input Impedance | 250 ohms (for 4-20 mA signals) |
| Power Requirements | +5 V DC and ±15 V DC (provided via backplane connection) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Board Dimensions | Standard Eurocard format (approx. 233 x 160 mm) |
| Mounting | Installs into a designated slot in a Mark Vie drive tray or I/O enclosure |
| Compatibility | Designed for use with other Mark Vie series boards like DS200TBCAG1AFG (TBCA) |
Main Features and Advantages
Superior signal integrity and noise immunity: The DS200SLCCG1AFG is engineered with high-quality components and advanced filtering circuits that reject electromagnetic interference (EMI) and radio frequency interference (RFI). This ensures that the analog signal received by the controller is a clean and accurate representation of the field measurement, which is critical for maintaining stable and efficient turbine operation. The built-in isolation barriers break ground loops and prevent noise from corrupting the signal, protecting both the field device and the control system.
High reliability and ruggedized design: Built to withstand the harsh conditions of a power generation plant, including wide temperature fluctuations and significant vibration, the DS200SLCCG1AFG is manufactured to industrial-grade standards. Its robust construction ensures continuous operation and minimizes the risk of unscheduled downtime. The board’s design simplifies troubleshooting with clearly labeled test points, allowing technicians to quickly verify signal status and board functionality during maintenance operations.
Configuration flexibility: While a dedicated terminal board, the DS200SLCCG1AFG can often be configured or jumpered to accept different analog input types and ranges, providing a degree of flexibility for various sensor types used within the turbine control scheme. This adaptability makes it a valuable spare part that can serve multiple points within a system, reducing the diversity of spares that need to be stocked on site.
Application Field
The primary application of the DS200SLCCG1AFG is within the power generation industry, specifically in the control and protection systems of GE gas turbines and steam turbines. It is an integral component of the Mark Vie system, which is renowned for its reliability in managing turbine startup, synchronization, acceleration, and load control. The board is typically used to interface with critical sensors that monitor exhaust temperature, fuel flow, compressor pressure, bearing oil temperature, and vibration levels.
In a typical installation, the DS200SLCCG1AFG would be housed in a drive tray or I/O module located in a turbine control panel near the turbine skid. Its role is to provide a trustworthy digital representation of an analog process variable. The accurate data provided by this board enables the Mark Vie controller to execute complex control algorithms and protective trips, ensuring the turbine operates within its safe operating envelope while maximizing efficiency and availability. The GE DS200SLCCG1AFG is therefore not just an I/O card but a key enabler of plant safety, reliability, and profitability.
DS200SLCCG1AFG GE
Related Products
DS200SLCCG1A: The base model number, potentially with slight variations in firmware or manufacturing revision.
DS200TBCAG1AFG: A Termination Board I/O Communication board that often works in conjunction with the SLCC board for signal distribution.
DS200DCFG1AFG: A Distributed Communication Interface Module for network connectivity within the Mark Vie system.
DS200LDCG1AFG: A Load Distribution Control Board involved in managing turbine load sharing.
DS200PCCG1AFG: A Power Distribution Control Board that manages power supplies within the drive tray.
IS200STCIH6AED: A similar analog input terminal board from the later Mark VI series.
IS200STCIS6ABA: Another variant from the Mark VI family, highlighting the evolution of the product line.
DS200SDCCG1AFG: A Sensor Diagnostic Communication Board used for specialized sensor interfaces.
