The ABB DSDP170 57160001-ADF represents the cutting edge of fieldbus communication technology within ABB’s S800 I/O portfolio, serving as an advanced Profinet IO-Device (slave) communication interface module. This sophisticated module is specifically engineered to provide seamless, high-speed integration of ABB’s robust S800 I/O system into modern Industrial Ethernet networks utilizing the Profinet industrial Ethernet standard. The primary function of the ABB DSDP170 57160001-ADF is to enable real-time data exchange between Profinet IO-Controllers (masters)—which can include PLCs, DCS systems, or PC-based controllers from ABB or any Profinet-compliant vendor—and the comprehensive range of analog, digital, and specialty modules within the S800 I/O family. This module effectively future-proofs automation investments by bridging ABB’s proven I/O technology with the high-performance demands of Industry 4.0 and IIoT applications.

As a dedicated communication gateway, the DSDP170 occupies a critical role in the S800 I/O architecture, managing all data traffic between the Profinet network and the local I/O modules while providing advanced diagnostic and configuration capabilities. It delivers exceptional value by allowing plants to leverage the reliability, density, and precision of ABB’s S800 I/O platform within modern Ethernet-based automation architectures, eliminating the need for protocol converters and reducing system complexity. The deployment of the ABB DSDP170 57160001-ADF ensures deterministic, high-speed communication with update times down to 1ms, which is essential for demanding real-time control applications, while also providing IT integration capabilities for plant-wide data accessibility. Its design emphasizes network resilience, cybersecurity features, and straightforward integration with engineering tools.

DSDP170 57160001-ADF ABB

Technical Specifications

Main Features and Advantages

The ABB DSDP170 57160001-ADF offers superior connectivity and advanced network management capabilities that set it apart from previous generations. A defining feature is its integrated two-port switch functionality, which enables efficient linear network topology without requiring additional external switches, simplifying cabling and reducing installation costs. The module supports Profinet Conformance Class B, providing advanced features such as network diagnostics via SNMP, device replacement without programmer, and support for media redundancy protocols like MRP (Media Redundancy Protocol), which ensures network availability even in case of cable failure. These features make the DSDP170 exceptionally suitable for mission-critical applications requiring maximum network reliability and minimal downtime.

Configuration and maintenance are significantly enhanced through modern engineering tools integration. The module is configured using standard Profinet engineering tools through its GSDML (General Station Description Markup Language) file, ensuring vendor interoperability and simplifying system integration. For ABB-centric environments, it offers seamless integration with Control Builder M, providing a unified engineering experience. The DSDP170 provides extensive diagnostic capabilities through both web-based management access and a comprehensive LED status indication system that displays module status, network activity, link status, and specific error conditions. This multi-level diagnostic approach enables rapid troubleshooting from both local and remote locations, significantly reducing mean time to repair and enhancing overall system availability. Additionally, the module supports advanced Profinet features like prioritized startup and fast device replacement, further reducing maintenance time during device swaps.

Application Field

The ABB DSDP170 57160001-ADF is strategically positioned for modern industrial applications requiring high-speed Ethernet-based communication and integration with Industry 4.0 infrastructure. In advanced manufacturing environments such as automotive production, semiconductor fabrication, and precision machining facilities, the module enables high-speed communication between Profinet-based controllers and ABB’s high-performance S800 I/O system. This allows for precise coordination of robotic systems, motion control applications, and high-speed sequencing operations where fast update times and deterministic behavior are critical for production quality and throughput.

In process industries undergoing digital transformation, including pharmaceutical manufacturing, food and beverage processing, and chemical production, the DSDP170 serves as a bridge between traditional process automation reliability and modern IT integration capabilities. The module enables seamless data exchange between process control systems and manufacturing execution systems (MES) or enterprise resource planning (ERP) systems, facilitating real-time production monitoring, quality tracking, and predictive maintenance initiatives. The ABB DSDP170 57160001-ADF is particularly valuable in greenfield installations or modernization projects where future-proof Ethernet infrastructure is essential, providing a migration path from legacy fieldbus systems while maintaining access to ABB’s comprehensive S800 I/O portfolio.

DSDP170 57160001-ADF ABB

Related Products

ABB S800 I/O Modules: Full range of compatible modules including DSDI110A (digital input), DSAI130A (analog input), and DSDO115A (digital output) modules managed by the DSDP170.

ABB TB811: Power supply and communication terminal unit required for S800 baseplate operation.

ABB CI871: Profinet IO-Controller module for AC 800M controllers, which can act as the network master for the DSDP170.

ABB DSDP140B: Profibus DP slave module for traditional fieldbus applications.

ABB NETA-21: Multi-protocol remote I/O communication interface supporting various network protocols.
